Schneider Electric GV2RT08 TeSys Deca 3P 2.5-4 A 100 kA Motor Protection Circuit Breaker (MPCB)

% $-53.12
Schneider Electric GV2RT08 TeSys Deca motor circuit breaker - 3P 2.5-4A 100kA MPCB
Schneider Electric GV2RT08 TeSys Deca motor circuit breaker - 3P 2.5-4A 100kA MPCB

Schneider Electric GV2RT08 TeSys Deca 3P 2.5-4 A 100 kA Motor Protection Circuit Breaker (MPCB)

Brand: Schneider Electric
Reference No: GV2RT08
Tariff Code (HS): 853620
Rated Current: 4 A
Power: 1.1-1.5 kW
Rated Voltage: 690 V
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$53.12

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric GV2RT08 is a TeSys Deca (TeSys GV2) motor circuit breaker rated 2.5-4 A at 690 V AC, providing thermal-magnetic protection for 3-phase motors up to 1.1-1.5 kW at 400 V. It trips magnetically at 78 A, delivers a 100 kA breaking capacity at 400 V, and is operated by a toggle rated for 100,000 AC-3 cycles.

Technical Specifications

SKU GV2RT08
Brand Schneider Electric
Range TeSys Deca (TeSys GV2)
Poles 3P
Trip Unit Technology Thermal-magnetic
Utilisation Category Category A (IEC 60947-2), AC-3 (IEC 60947-4-1)
Thermal Protection Adjustment Range 2.5-4 A
Line Rated Current (In) 4 A
Magnetic Tripping Current 78 A
Breaking Capacity (Icu) at 400/415 V 100 kA
Motor Power at 400 V 1.1-1.5 kW
Rated Operational Voltage (Ue) 690 V AC, 50/60 Hz
Rated Insulation Voltage (Ui) 690 V AC, 50/60 Hz
Rated Impulse Withstand Voltage (Uimp) 6 kV
Control Type Toggle
Connections Screw clamp terminals, 1-6 mm²
Mounting 35 mm DIN rail or panel with adaptor plate
Dimensions (W x H x D) 45 x 89 x 78.5 mm
IP Degree IP20

Certifications & Standards

  • CE
  • UKCA
  • CCC
  • cULus
  • EAC
  • EN/IEC 60947-2
  • EN/IEC 60947-4-1

Selection Notes

The 2.5-4 A setting suits motors drawing up to 1.1-1.5 kW at 400 V; move to the adjacent setting in the GV2RT range as the full-load current falls outside this window, since the toggle, terminals and 690 V insulation are identical across the series. The full 100 kA breaking capacity at 400 V holds through this current band, so it can sit directly behind a high fault-current incomer without a separate current-limiter accessory.

Technical Details

Short Description
TeSys Deca (GV2RT) motor circuit breaker, 3P, 2.5-4 A thermal-magnetic, 690 V AC, Icu 100 kA.
Rated Current (Ampere)
4 A
Rated Voltage (VAC)
690 V
Mounting Type
35 mm DIN rail
Protection Type
IP20
Number of Poles
3P
Power (kW)
1.1-1.5 kW
Delivery Date (Days)
30 days
Model Number
GV2RT08
Tariff Code
853620
