- Part number
- 9001KR1BH13
- Model no
- 9001K
Description
About the 9001K
About the 9001K
The Schneider Electric 9001KR1BH13 is a black Harmony 9001K flush push button with a metal guard ring, switching 1 NO + 1 NC on a spring-return octagonal body. Built for 30 mm panel cut-outs, it carries a 3 A AC-15 rating at 240 V and an IP65/IP66 enclosure for heavy-duty industrial control stations.
Certifications & Standards
- UL 508
- NEMA
- IEC 60947-1
- JIS C 4520
- IEC 60947-5-1
- CSA C22.2 No. 14
- JIS C 852
- IEC 60947-5-4
Selection Notes
The 1 C/O contact gives a simultaneous NO and NC signal from one actuation, useful where a start command and an interlock status need to be read from the same button. The metal guard ring around the black flush head protects against accidental activation on crowded panels, which is the reason to pick this guarded variant over the plain flush 9001K push button. Its 3 A AC-15 rating at 240 V covers direct control-relay or contactor-coil switching without an interposing relay.
Specification
Full specification
Main 6
| Range of Product | Harmony 9001K |
|---|---|
| Product or Component Type | Push-button |
| Device short name | 9001K |
| Type of operator | spring return |
| Operator profile | Black flush, unmarked |
| Operator additional information | Metal guard |
Complementary 29
| Bezel material | Metal |
|---|---|
| Mounting diameter | 1.2 in (30 mm) |
| Shape of signaling unit head | Octagonal |
| Contacts type and composition | 1 C/O |
| Connections - terminals | Screw clamp terminals 1 x 0.22...2 x 1.5 mm² IEC 60947-1 |
| Tightening torque | 7.08 lbf.in (0.8 N.m) IEC 60947-1 |
| shape of screw head | Cross slotted |
| Mechanical durability | 5000000 cycles |
| Operating position | Any position |
| [Ie] rated operational current | 3 A 240 V, AC-15, A600-Q600 NEMA, 0.55 A 125 V, DC-13, A600-Q600 NEMA |
| [Ui] rated insulation voltage | 250 V 3)IEC 60947-1 |
| [Uimp] rated impulse withstand voltage | 2.5 kV IEC 60947-1 |
| Contacts material | Silver alloy contacts |
| Contact operation | Standard |
| Positive opening | Without |
| Short-circuit protection | 10 A cartridge fuse IEC 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A |
| [Icm] rated short-circuit making capacity | 12 kA 600 V AC-15, 7200 VA, 15 kA 480 V AC-15, 7200 VA, 30 kA 240 V AC-15, 7200 VA, 60 kA 120 V AC-15, 7200 VA, 0.1 kA 600 V DC-13, 0.27 kA 250 V DC-13, 0.55 kA 125 V DC-13 |
| Rated breaking capacity | 3 kA 240 V AC-15, 720 VA, 6 kA 120 V AC-15, 720 VA, 1.2 kA 600 V AC-15, 720 VA, 1.5 kA 480 V AC-15, 720 VA, 0.1 kA 600 V DC-13, 0.27 kA 250 V DC-13, 0.55 kA 125 V DC-13 |
| Terminals description ISO n°1 | (13-14-11-12)OF |
| CAD overall width | 1.9 in (48 mm) |
| CAD overall height | 1.8 in (45 mm) |
| CAD overall depth | 2.2 in (56 mm) |
| Net Weight | 0.267 lb(US) (0.121 kg) |
| Device presentation | Complete product |
| Cap/operator or lens colour | Black |
| Operator profile | Flush |
| Type of operator | Spring return |
| Size | 30 mm |
Environment 10
| Standards | IEC 60947-1, JIS C 4520, IEC 60947-5-1, CSA C22.2 No 14, JIS C 852, IEC 60947-5-4 |
|---|---|
| Product Certifications | UL 508, NEMA |
| Protective treatment | TC |
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -13…158 °F (-25…70 °C) |
| Vibration resistance | 7 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn IEC 60068-2-27 |
| Electrical shock protection class | Class II conforming to IEC 61140 |
| IP Degree of Protection | IP65/IP66 |
| NEMA degree of protection | NEMA 1, NEMA 12, NEMA 13, NEMA 2, NEMA 3, NEMA 3R, NEMA 4 |
Show all 59 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.
Identification 8
| Part number | 9001KR1BH13 |
|---|---|
| Type designation | 9001K |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 785901066798 |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 5
| Country of origin | MX |
|---|---|
| Shipping weight | 0.121 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 9001KR1BH13
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- UL
- IEC 60947-1
- JIS C 4520
- IEC 60947-5-1
- CSA C22.2 No 14
- JIS C 852
- IEC 60947-5-4
Quick answers
Questions about the 9001K
What is the HS code of 9001K for customs?
The tariff (HS) code on file for 9001K is 853650.
What is the EAN of 9001K?
The EAN (GTIN) of 9001K is 785901066798.
Where does 9001K ship from, and how fast?
9001K ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
