Part number
1SVR427030R0000
Model no
CP-E
$62.38 On request Dispatch — · From TürkiyeGet a Quote
ABB 1SVR427030R0000 CP-E 24/0.75 24VDC 0.75A 18W 100-240VAC Input DC Power Supply
  • CE
  • RoHS
  • UL
  • UKCA
CP-E

ABB 1SVR427030R0000 CP-E 24/0.75 24VDC 0.75A 18W 100-240VAC Input DC Power Supply

Ratings Full specification ↓
Rated current
0.75 A
Rated operational voltage
100–240 V AC
EAN
4016779656863
Other ratings in CP-E All 4 ratings ↓
kW In (A) Part number Stock Price
0.75 1SVR427030R0000This part On request $62.38
5 1SVR427034R0000 Low stock $109.66
10 1SVR427035R0000 Critical stock $149.17
20 1SVR427036R0000 Low stock $234.15
Description

About the CP-E

The ABB CP-E 24/0.75 (SKU: 1SVR427030R0000) is a compact DIN-rail-mounted DC power supply delivering a regulated 24 VDC output at 0.75 A from a wide-range 100–240 V AC input. Rated at 18 W and measuring just 22.5 mm wide, the CP-E 24/0.75 is engineered for space-constrained control panels and industrial automation enclosures where reliable, low-ripple DC power is essential.

Certifications & Standards

  • CE: Conformité Européenne — meets EU safety, health, and environmental requirements
  • UL 60950: UL safety standard for information technology equipment power supplies
  • UL 1310: UL standard for Class 2 power units
  • UL 508: UL standard for industrial control equipment
  • cUL: Canadian UL certification for the Canadian market
  • UKCA: UK Conformity Assessed marking for Great Britain market
  • CAN/CSA C22.2 No. 60950: Canadian standard for IT equipment power supplies
  • CSA C22.2 No. 107: Canadian standard for general use power supplies
  • CSA C22.2 No. 213: Canadian standard for non-incendive electrical equipment
  • CSA C22.2 No. 223: Canadian standard for power supplies with extra-low voltage
  • CSA: Canadian Standards Association approval
  • IEC/EN 63000: Technical documentation for assessing electrical and electronic products with respect to RoHS
  • EN 63000: European harmonised standard for RoHS technical documentation
  • IEC/EN 61000-6: Electromagnetic compatibility — generic emission and immunity standards
  • EN 61000-6: European EMC generic standards for industrial environments
  • IEC 60950-1: Safety of information technology equipment
  • IEC 61000-4: EMC testing and measurement techniques
  • RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
  • REACH: EU regulation on registration, evaluation, authorisation and restriction of chemicals
  • WEEE: Waste Electrical and Electronic Equipment Directive compliance

Applications & Use Cases

  • 24 VDC control circuit supply in industrial automation and PLC panels
  • Powering sensors, solenoid valves, and signal converters in manufacturing lines
  • Building automation and HVAC control panels requiring compact DIN-rail power
  • Low-power instrumentation and I/O module supply in process control systems
  • Machine builder OEM panels where panel width is at a premium (22.5 mm footprint)
Specification

Full specification

71 values · Last verified 30 Oct 2026

Dimensions 4

Product Net Width 22.5 mm
Product Net Height 90 mm
Product Net Depth / Length 114 mm
Product Net Weight 0.143 kg

Technical 25

Function Switch mode power supply
Number of Phases 1-phase
Rated Input Voltage (UIN) 100 ... 240 V AC
Input Voltage (Uin) 90 ... 264 V AC, 120 ... 375 V DC
Rated Frequency (f) 50 Hz
Rated Frequency Limits 47 ... 63 Hz
Characteristic of Output Hiccup-Mode
Rated Output Power 18 W
Output Power 18 W
Rated Output Voltage 24 V DC
Output Voltage (Uout) 24 V DC, 21.6 ...28.8 V DC
Rated Output Current 0.75 A
Output Current 0.75 A
Rated Impulse Withstand Voltage (Uimp) Input Circuit / Output Circuit 4 kV, Input Circuit / PE 2.5 kV, Input Circuit / Relay Contact 4 kV, Output Circuit / PE 0.5 kV
Rated Insulation Voltage (Ui) Input Circuit / Output Circuit 300 V, Input Circuit / PE 300 V, Input Circuit / Relay Contact 300 V, Output Circuit / PE 50 V
Degree of Protection Housing IP20, Terminals IP20
Connecting Capacity Input Circuit Flexible with Ferrule 0.2 ... 2.5 mm², Rigid 0.2 ... 2.5 mm²
Connecting Capacity Output Circuit Flexible with Ferrule 0.2 .... 2.5 mm², Rigid 0.2 ... 2.5 mm²
Tightening Torque Input Circuit 0.6 N·m, Output Circuit 0.6 N·m
Wire Stripping Length Input Circuit 6 mm, Output Circuit 6 mm
Recommended Screw Driver PH1
Minimum Mounting Distance Electrical Conductive Board, Horizontal 25 mm, Electrical Conductive Board, Vertical 25 mm, Other Device Same Type, Horizontal 25 mm, Other Device Same Type, Vertical 25 mm
Mounting Position 1
Mounting on DIN Rail TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Standards ANSI/ISA-12.12, CAN/CSA C22.2 No.107.1, CAN/CSA C22.2 No.213, CAN/CSA C22.2 No.223, CAN/CSA C22.2 No.60950, IEC/EN 63000, IEC 60950-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 1310, UL 508, UL 60950

Technical UL/CSA 3

Connecting Capacity Input Circuit UL/CSA Rigid 24-14 AWG
Connecting Capacity Output Circuit UL/CSA Rigid 24-14 AWG
Tightening Torque UL/CSA Input Circuit 5 in·lb, Output Circuit 5 in·lb
Show all 71 specifications ↓ Show less ↑39 more values in Identification, Electromagnetic Compatibility, Environmental, Material Compliance, External Classifications and Standards, Logistics.

Identification 11

Part number 1SVR427030R0000
Type designation CP-E
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 4016779656863
ETIM class EC002540
eCl@ss 27040701
Minimum Order Quantity 1 piece
Customs Tariff Number 85044095

Electromagnetic Compatibility 6

Electrostatic Discharge (ESD Immunity) acc. to IEC 61000-4-2 Level 4 Air Discharge 15 kV, Level 4 Contact Discharge 8 kV
Radiated Electromagnetic Field Immunity acc. to IEC 61000-4-3 Level 3 10 V/m
Electrical Fast Transient (Burst Immunity) acc. to IEC 61000-4-4 Level 4 Power Supply Port Signal 4 kV
Surge Immunity acc. to IEC 61000-4-5 Level 3 Line-to-Line 2 kV, Level 4 Line-to-Ground 4 kV
Conducted Disturbances Immunity acc. to IEC 61000-4-6 Level 3 10 V
Electromagnetic Compatibility (EMC) Immunity - Class B, Emission - Class B

Environmental 2

Ambient Air Temperature Operation -20 ... +70 °C, Storage -25 ... +85 °C
Maximum Operating Altitude Permissible 5000 m

Material Compliance 6

REACH Declaration 1SVD982001-4501
RoHS Declaration 1SVD982001-4401
RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA 2CMT2023-006535
WEEE B2C / B2B Business To Business
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards 4

ETIM 10 EC002540 - DC-power supply
eClass V11.0 : 27040701
UNSPSC 39121004
E-Number (Sweden) 5218700

Logistics 10

Package Level 1 Width 134 mm
Package Level 1 Depth / Length 157 mm
Package Level 1 Height 39 mm
Package Level 1 Gross Weight 0.212 kg
Package Level 1 EAN 4016779656863
Package Level 1 Units box 1 piece
Shipping weight 0.212 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SVR427030R0000

No documents are on file for this part yet.

Ask us for the datasheet
Other ratings

All 4 ratings in CP-E
Motor power Rated current Part number Model no Stock Dispatch Price
0.75 A 1SVR427030R0000 This part CP-E On request — $62.38 Quote
5 A 1SVR427034R0000 CP-E Low stock $109.66
10 A 1SVR427035R0000 CP-E Critical stock $149.17
20 A 1SVR427036R0000 CP-E Low stock $234.15
Certifications

Certifications and standards
  • CE
  • RoHS
  • UL
  • UKCA
  • ANSI/ISA-12.12
  • CAN/CSA C22.2 No.107.1
  • CAN/CSA C22.2 No.213
  • CAN/CSA C22.2 No.223
  • CAN/CSA C22.2 No.60950
  • IEC/EN 63000
  • IEC 60950-1
  • IEC/EN 61000-6-2
  • IEC/EN 61000-6-3
  • UL 1310
  • UL 508
  • UL 60950
Quick answers

Questions about the CP-E

What is the rated current of CP-E?

The rated current of CP-E is 0.75 A.

Which supply voltage is CP-E rated for?

The rated operational voltage of CP-E is 100–240 V AC.

What is the HS code of CP-E for customs?

The tariff (HS) code on file for CP-E is 85044095.

What is the EAN of CP-E?

The EAN (GTIN) of CP-E is 4016779656863.

Where does CP-E ship from, and how fast?

CP-E ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
