ABB 1SFL587102R1311 AF305-40-11-13 4-Pole 500A 1000V AC-1 160kW Power Contactor AC Switching

The ABB AF305-40-11-13 (SKU: 1SFL587102R1311) is a heavy-duty 4-pole AC power contactor rated at 500 A (AC-1) and 1000 V IEC, designed for demanding industrial switching applications. Delivering 160 kW at 400 V AC under AC-3 duty, the AF305-40-11-13 belongs to ABB's proven AF series and is built to handle high-current motor and resistive load control in automation and power distribution systems.

Technical Specifications

Certifications & Standards

• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — compliant with Great Britain market regulations post-Brexit
• cULus: Underwriters Laboratories certification for Canada and USA markets
• CQC: China Quality Certification — approved for the Chinese market
• DNV: Det Norske Veritas — certified for marine and offshore applications
• KC: Korea Certification mark for the South Korean market
• LR: Lloyd's Register — marine type approval
• PRS: Polski Rejestr Statków — Polish ship classification society approval
• RINA: Registro Italiano Navale — Italian naval register approval for marine use
• CCS: China Classification Society — certified for Chinese marine applications
• IEC 60947-4: International standard for low-voltage switchgear and controlgear — contactors and motor starters
• IEC 60947-1: General rules for low-voltage switchgear and controlgear
• EN 45555: General methods for the assessment of the energy efficiency of networked standby for electrical and electronic household and office equipment
• UL 2799: Standard for Electrical Systems for Certain Electrically Powered Industrial Trucks
• CSA: Canadian Standards Association — certified for North American industrial applications
• REACH: Compliant with EU regulation on Registration, Evaluation, Authorisation and Restriction of Chemicals
• RoHS: Restriction of Hazardous Substances — compliant with EU directive on hazardous materials
• WEEE: Waste Electrical and Electronic Equipment directive compliance for responsible end-of-life disposal

Applications & Use Cases

• High-current motor switching and control in industrial automation systems
• Resistive and inductive load switching in power distribution panels
• Marine and offshore power control (DNV, LR, RINA, PRS, CCS certified)
• Heavy-duty HVAC compressor and pump motor control
• Factory automation, process control, and MCC (Motor Control Centre) assemblies
• Applications requiring 1000 V IEC or 600 V UL rated switching up to 500 A AC-1
