ABB 1SDA067057R1 XT2N 160 Ekip Dip LS/I In=100A 3p F F 3-Pole 100A Fixed Moulded Case Circuit Breaker

The ABB 1SDA067057R1 XT2N 160 Ekip Dip LS/I In=100A 3p F F is a 3-pole, 100A fixed-mount moulded case power circuit breaker from the Tmax XT2 series, designed for protection of transformers, generators, and electrical installations. Featuring the Ekip Dip LS/I electronic trip unit with long-time and instantaneous protection functions, this breaker delivers precise, reliable overcurrent protection in compact 90 × 130 mm format. Weighing just 1.4 kg, it is engineered for demanding industrial control panels and power distribution applications.

Technical Specifications

Certifications & Standards

• IEC 60947-2: Low-voltage switchgear — circuit breakers; primary design and performance standard
• CE: Compliant with applicable EU directives for sale within the European Economic Area
• ATEX: Certified for use in potentially explosive atmospheres
• VDE: Verified by VDE Institute to German/European electrical safety standards
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU: RoHS Directive — restriction of hazardous substances in electrical equipment
• Amendment 2015/863: EU RoHS amendment extending restricted substances list
• UL 2799: UL standard compliance for electrical systems
• WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive for end-of-life recycling

Applications & Use Cases

• Transformer secondary protection in industrial and commercial power distribution panels
• Generator output circuit protection for standby and prime power systems
• Main and sub-distribution board protection in industrial automation and control systems
• Motor feeder protection where precise LS/I tripping characteristics are required
• Installation protection in manufacturing facilities, process plants, and infrastructure projects
