ABB 1SBL177001R1110 AF16-30-10-11 3-Pole 30A 690V 7.5kW Coil 24-60V AC/DC Power Contactor AC Switching

The ABB AF16-30-10-11 power contactor (SKU: 1SBL177001R1110) is a 3-pole AC switching contactor rated at 30 A and 690 V, delivering up to 7.5 kW of motor switching capacity. Part of ABB's AF series, the AF16-30-10-11 features a wide-range coil accepting 24–60 V AC (50/60 Hz) and 20–60 V DC, making it highly versatile for diverse control circuit voltages in industrial automation and control panel applications. Its compact 45 × 86 × 77 mm footprint and 0.27 kg weight simplify panel layout and installation.

Technical Specifications

Certifications & Standards

• CE: European Conformity — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — compliant with UK market regulations post-Brexit
• UL: UL Listed — tested and certified to applicable UL standards
• UL 60947-4-1: UL standard for contactors and motor starters
• UL 60335-2-40: UL standard for heat pump, air conditioner, and dehumidifier safety
• UL 60335-2-40 LZGH2 A2L: UL certification for A2L refrigerant applications
• CSA: CSA certified — meets Canadian Standards Association requirements
• CSA C22.2 No.60947-4-1: CSA standard for contactors and motor starters
• CSA C22.2 No. 60335-2-40: CSA standard for heat pump and air conditioning equipment
• CSA C22.2 No.60335-2-40 LZGH2 A2L: CSA certification for A2L refrigerant applications
• CSA C22.2 No.60335: CSA household and similar electrical appliances standard
• CSA C22.2 No.60947: CSA industrial control equipment standard
• CCC: China Compulsory Certification — required for the Chinese market
• CQC: China Quality Certification — voluntary product quality certification
• ABS: American Bureau of Shipping — certified for marine applications
• BV: Bureau Veritas — internationally recognised type approval
• CB: CB Scheme — IEC-based international safety certification
• IEC 60947-1 / EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4: Contactors and motor starters
• IEC/EN 60947-1: Low-voltage switchgear and controlgear — general rules
• IEC/EN 60947-4: Low-voltage contactors and motor-starters
• IEC 60947-5: Control circuit devices and switching elements
• IEC 60715: Dimensions of low-voltage switchgear and controlgear — DIN rail mounting
• IEC 60529: Degrees of protection provided by enclosures (IP Code)
• IEC 60068-2-27: Environmental testing — shock
• EN 45555: General methods for assessing the energy efficiency of networked standby
• EN 45555-92: Energy efficiency assessment methods — part 92
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• REACH: Registration, Evaluation, Authorisation and Restriction of Chemicals — EU compliant
• WEEE: Waste Electrical and Electronic Equipment Directive — compliant with EU recycling requirements

Applications & Use Cases

• Motor switching and starting in HVAC systems, pumps, fans, and compressors
• Industrial automation and control panels requiring compact, reliable AC switching
• Air conditioning and heat pump control circuits (A2L refrigerant compatible per UL/CSA certifications)
• Machine building applications where wide-range coil voltage simplifies control design
• Marine and offshore installations (ABS and BV approved)
• International projects requiring multi-market certifications (UL, CSA, CE, CCC, UKCA)
