ABB 1SBL177001R1101 AF16-30-01-11 3-Pole 30A 690V 7.5kW 24-60V AC/DC Coil Power Contactor AC Switching

The ABB AF16-30-01-11 (SKU: 1SBL177001R1101) is a 3-pole power contactor designed for AC switching applications in industrial control panels and motor circuits. Rated at 30 A and 690 V with a 7.5 kW motor power rating, the AF16-30-01-11 accepts a wide-range coil voltage of 24–60 V AC (50/60 Hz) and 20–60 V DC, enabling flexible integration across global installations. Compact at 45 mm × 86 mm × 77 mm and weighing just 0.27 kg, this ABB AF Series contactor suits space-constrained enclosures.

Technical Specifications

Certifications & Standards

• CE: European Conformity marking for EU market compliance
• UKCA: UK Conformity Assessed marking for Great Britain market
• UL: Underwriters Laboratories listed for North American safety
• CSA: Canadian Standards Association certified
• CCC: China Compulsory Certification
• CQC: China Quality Certification
• ABS: American Bureau of Shipping type approval
• BV: Bureau Veritas type approval
• CB: International CB Scheme certification
• UL 60335-2-40: UL standard for air-conditioning and heat pump equipment
• UL 60335-2-40 LZGH2 A2L: UL listing for A2L refrigerant applications
• UL 60947-4-1: UL standard for electromechanical contactors and motor starters
• CSA C22.2 No. 60335-2-40: Canadian standard for HVAC/heat pump equipment
• CSA C22.2 No. 60335-2-40 LZGH2 A2L: CSA listing for A2L refrigerant applications
• CSA C22.2 No. 60947-4-1: Canadian standard for contactors and motor starters
• CSA C22.2 No. 60335: Canadian standard series for household and similar apparatus
• CSA C22.2 No. 60947: Canadian standard series for low-voltage switchgear and controlgear
• IEC 60947-1 / EN 60947-1: Low-voltage switchgear and controlgear — general rules
• IEC 60947-4 / EN 60947-4: Contactors and motor starters
• IEC 60947-5: Control circuit devices and switching elements
• IEC/EN 60947-1: Combined IEC/EN general rules for low-voltage switchgear
• IEC/EN 60947-4: Combined IEC/EN standard for contactors and motor starters
• IEC60947-4: IEC standard for contactors and motor starters (consolidated reference)
• IEC60947-5: IEC standard for control circuit devices (consolidated reference)
• IEC60715: Dimensions for DIN rail mounting
• IEC60529 / EN60529: Degrees of protection provided by enclosures (IP code)
• IEC60947-1: General rules for low-voltage switchgear (consolidated reference)
• IEC 60068-2-27: Environmental testing — shock
• EN45555: General methods for assessing the energy efficiency of networked standby
• EN45555-92: Supplementary standard for energy efficiency assessment
• REACH: EU regulation on registration, evaluation and restriction of chemicals
• RoHS: Restriction of Hazardous Substances Directive compliance
• WEEE: Waste Electrical and Electronic Equipment Directive compliance
