ABB 1SBL176001R2110 AF16Z-30-10-21 3-Pole 30A 690V 7.5kW AC/DC Coil Power Contactor AC Switching

The ABB AF16Z-30-10-21 power contactor (SKU: 1SBL176001R2110) is a 3-pole AC switching contactor rated at 30A and 690V, delivering 7.5kW of motor switching capability for industrial automation and control panel applications. Part of ABB's AF Series, the AF16Z-30-10-21 features a wide-range AC/DC coil (24–60V AC 50/60Hz / 20–60V DC) enabling flexible integration across diverse control systems. Its compact 45×86×77mm footprint and 0.31kg weight make it ideal for space-constrained enclosures.

Technical Specifications

Certifications & Standards

• CE: European conformity marking for electrical safety and EMC
• CCC: China Compulsory Certification
• CQC: China Quality Certification Centre
• CSA: Canadian Standards Association approval
• UL: Underwriters Laboratories listing (USA)
• ABS: American Bureau of Shipping marine certification
• BV: Bureau Veritas marine/industrial certification
• CB: IECEE CB Scheme international safety certification
• IEC 60335-2-40: Safety of household and similar electrical appliances — heat pumps, air conditioners
• UL 60335-2-40: UL equivalent of IEC 60335-2-40
• CSA C22.2 No. 60335-2-40: Canadian equivalent of IEC 60335-2-40
• IEC 60947-1 / EN 60947-1: Low-voltage switchgear and controlgear — general rules
• IEC 60947-4 / EN 60947-4: Low-voltage switchgear — contactors and motor starters
• UL 60335-2-40 LZGH2 A2L: UL listing for A2L refrigerant applications
• UL 60947-4-1: UL standard for electromechanical contactors and motor starters
• CSA C22.2 No.60335-2-40 LZGH2 A2L: CSA listing for A2L refrigerant applications
• CSA C22.2 No.60947-4-1: CSA standard for electromechanical contactors and motor starters
• IEC/EN 60947-1: Consolidated low-voltage switchgear general rules
• IEC/EN 60947-4: Consolidated contactors and motor starters standard
• IEC 60947-5: Low-voltage switchgear — control circuit devices and switching elements
• IEC 60947-4 (IEC60947-4): Low-voltage contactors and motor starters
• IEC 60947-5 (IEC60947-5): Control circuit devices and switching elements
• IEC 60947-1 (IEC60947-1): General rules for low-voltage switchgear
• IEC 60068-2-27: Environmental testing — shock
• EN 45555: General methods for the assessment of the ability to recover resources from electrical and electronic equipment
• EN 45555-92: Supplementary standard for resource recovery assessment
• CSA C22.2 No.60335: CSA safety standard series for electrical appliances
• CSA C22.2 No.60947: CSA standard series for low-voltage switchgear and controlgear
• REACH: EU regulation on chemical substance safety
• RoHS: Restriction of hazardous substances in electrical and electronic equipment
• WEEE: Waste electrical and electronic equipment directive compliance
• UKCA: UK Conformity Assessed marking for the UK market

Applications & Use Cases

• Motor switching and control in HVAC systems, compressors, and heat pumps
• Industrial automation control panels requiring compact 3-pole contactors
• A2L refrigerant compressor applications (UL/CSA LZGH2 A2L certified)
• Marine and offshore installations (ABS, BV certified)
• Building services, pumps, fans, and conveyor motor control
• Applications requiring wide-range coil voltage flexibility (24–60V AC/DC)
