ABB 1SBL157001R1301 AF12-30-01-13 3-Pole 12A 690V Coil 100-250V AC/DC Power Contactor AC Switching

The ABB AF12-30-01-13 power contactor (SKU: 1SBL157001R1301) is a 3-pole AC switching contactor rated at 28 A and 690 V, delivering reliable motor switching at up to 5.5 kW. Part of ABB's AF series, the AF12-30-01-13 features a wide-range coil accepting 100–250 V AC/DC (50/60 Hz), making it highly versatile for global industrial automation and control panel applications. Its compact 45 mm × 86 mm × 77 mm footprint and 0.27 kg weight simplify panel design and installation.

Technical Specifications

Certifications & Standards

• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — compliance for Great Britain market
• UL: Underwriters Laboratories listed for North American market
• UL 60947-4-1: UL standard for low-voltage switchgear and controlgear — contactors and motor starters
• UL 60335-2-40: UL standard for safety of household and similar electrical appliances (HVACR)
• UL 60335-2-40 LZGH2A2L: UL file reference for UL 60335-2-40 compliance
• CSA: Canadian Standards Association certified
• CSA C22.2 No. 60335-2-40: CSA standard for HVACR electrical appliances safety
• CSA C22.2 No. 60335-2-40 LZGH2A2L: CSA file reference for C22.2 No. 60335-2-40 compliance
• CSA C22.2 No. 60947-4-1: CSA standard for low-voltage contactors and motor starters
• CSA C22.2 No. 60335: CSA general series for household and similar electrical appliances
• CSA C22.2 No. 60947: CSA general series for low-voltage switchgear and controlgear
• IEC 60947-1 / EN 60947-1: International/European standard — general rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4: International/European standard — contactors and motor starters
• IEC/EN 60947-1: Combined IEC and EN compliance for general low-voltage switchgear rules
• IEC/EN 60947-4: Combined IEC and EN compliance for contactors and motor starters
• IEC 60947-5: IEC standard for control circuit devices and switching elements
• IEC 60068-2-27: Environmental testing — shock resistance
• CB: CB scheme certification for international market acceptance
• CCC: China Compulsory Certification for the Chinese market
• CQC: China Quality Certification — voluntary product certification
• ABS: American Bureau of Shipping — certified for marine applications
• BV: Bureau Veritas — certified for marine and offshore applications
• EN 45555: European standard for general methods for the assessment of the ability to recover materials and energy from electrical and electronic equipment
• EN 45555-92: Supplementary assessment standard for material and energy recovery
• REACH: Compliance with EU REACH regulation — no substances of very high concern above threshold
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• WEEE: Waste Electrical and Electronic Equipment Directive — registered for proper end-of-life disposal
