ABB 1SBL157001R1110 AF12-30-10-11 3-Pole 12A 24-60V AC/DC Coil AF Series Power Contactor AC Switching

The ABB AF12-30-10-11 power contactor (SKU: 1SBL157001R1110) is a 3-pole AC switching contactor from ABB's AF series, rated at 12A with a wide-range coil input of 24–60V AC (50/60Hz) and 20–60V DC. Designed for industrial motor control and automation applications, it delivers reliable switching at up to 690V AC with a 5.5kW power rating, in a compact 45mm × 86mm × 77mm package weighing just 0.27kg.

Technical Specifications

Certifications & Standards

• CE: European Conformity — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — compliant with UK market requirements
• UL: Underwriters Laboratories listed for North American safety compliance
• UL 60947-4-1: UL standard for low-voltage switchgear — AC motor contactors
• UL 60335-2-40: UL standard for safety of heat pumps, air conditioners, and dehumidifiers
• UL 60335-2-40 LZGH2 A2L: UL certification for A2L refrigerant applications
• CSA: Canadian Standards Association certified
• CSA C22.2 No.60947-4-1: CSA standard for AC motor contactors and starters
• CSA C22.2 No. 60335-2-40: CSA standard for HVAC and refrigerant equipment
• CSA C22.2 No.60335-2-40 LZGH2 A2L: CSA certification for A2L refrigerant applications
• CSA C22.2 No.60335: CSA general standard for household and similar electrical appliances
• CSA C22.2 No.60947: CSA general standard for low-voltage switchgear and controlgear
• CCC: China Compulsory Certification for the Chinese market
• CQC: China Quality Certification — voluntary certification for quality assurance
• ABS: American Bureau of Shipping — marine and offshore applications
• BV: Bureau Veritas — international classification and certification
• CB: CB Scheme — international IEC safety certification mutual recognition
• IEC 60947-1 / EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4: Contactors and motor-starters standard
• IEC/EN 60947-1: Consolidated IEC/EN general rules for low-voltage switchgear
• IEC/EN 60947-4: Consolidated IEC/EN standard for contactors and motor-starters
• IEC 60947-5: Control circuit devices and switching elements
• IEC 60715: Dimensions for DIN rail mounting of electrical equipment
• IEC 60529: Degrees of protection provided by enclosures (IP Code)
• IEC 60068-2-27: Environmental testing — shock
• EN 45555: General methods for the assessment of the ability to recycle and recover
• EN 45555-92: End-of-life treatment of electrical and electronic equipment
• REACH: EU regulation on Registration, Evaluation, Authorisation of Chemicals
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• WEEE: Waste Electrical and Electronic Equipment Directive compliant

Applications & Use Cases

• Motor control and starting in industrial automation panels
• HVAC system switching — compatible with A2L refrigerant equipment (UL/CSA 60335-2-40)
• Control panel assembly for machine builders and OEMs
• Pump and fan motor switching in building services
• Marine and offshore installations (ABS/BV approved)
• Applications requiring wide-band coil voltage (24–60V AC/DC) for simplified panel design
