ABB 1SBL157001R1101 AF12-30-01-11 3-Pole 12A 24-60V AC/DC Coil AF Series Power Contactor AC Switching

The ABB AF12-30-01-11 power contactor (SKU: 1SBL157001R1101) is a 3-pole AC switching contactor rated at 28 A and 690 V, delivering 5.5 kW motor power. Part of ABB's proven AF Series, the AF12-30-01-11 features a wide-range coil accepting 24–60 V AC (50/60 Hz) and 20–60 V DC, enabling flexible integration across diverse control panel and industrial automation applications. Compact at 45 × 86 × 77 mm and weighing just 0.27 kg, it is engineered for reliable, space-efficient performance in demanding electrical installations.

Technical Specifications

Certifications & Standards

• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — product compliance for the UK market
• UL: Underwriters Laboratories listed for North American safety compliance
• UL 60947-4-1: UL standard for electromechanical contactors and motor starters
• UL 60335-2-40: UL standard for particular requirements for electrical heat pumps, air conditioners and dehumidifiers (file LZGH2A2L)
• CSA: Canadian Standards Association certified
• CSA C22.2 No.60947-4-1: CSA standard for low-voltage switchgear and controlgear — contactors and motor starters
• CSA C22.2 No.60335-2-40 (LZGH2A2L): CSA standard for heat pumps, air conditioners and dehumidifiers
• CSA C22.2 No.60335: CSA standard for household and similar electrical appliances — safety
• CSA C22.2 No.60947: CSA standard for low-voltage switchgear and controlgear
• CCC: China Compulsory Certification for the Chinese market
• CQC: China Quality Certification Centre voluntary certification
• CB: CB Scheme — international safety certification under IECEx framework
• ABS: American Bureau of Shipping — marine type approval
• BV: Bureau Veritas — marine and offshore type approval
• IEC/EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC/EN 60947-4: Standard for contactors and motor starters
• IEC 60947-5: Control circuit devices and switching elements
• IEC 60715: Dimensions for low-voltage switchgear and controlgear — DIN rail mounting
• IEC 60529: Degrees of protection provided by enclosures (IP Code)
• IEC 60068-2-27: Environmental testing — shock
• EN 45555: General methods for the assessment of the ability to recover resources from electrical and electronic equipment
• EN 45555-92: Supplementary standard for recoverability of electrical and electronic equipment
• REACH: EU regulation on registration, evaluation, authorisation and restriction of chemicals
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• WEEE: Waste Electrical and Electronic Equipment Directive compliant
