MS132| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 6.3 | 1SAM350000R1009 | In stock | $36.27 | |
| 10 | 1SAM350000R1010 | In stock | $39.73 | |
| 12 | 1SAM350000R1012This part | In stock | $44.03 | |
| 16 | 1SAM350000R1011 | In stock | $44.03 | |
| 20 | 1SAM350000R1013 | In stock | $47.55 |
The ABB MS132-12 motor protection circuit-breaker (SKU 1SAM350000R1012) is a 3-pole manual motor starter rated for 8.0–12 A at 400 VAC, delivering an exceptional breaking capacity of 100 kA at 400 VAC. Designed for direct motor protection and switching in industrial control panels, the MS132-12 combines overcurrent, short-circuit, and phase-failure protection in a compact 45 mm wide housing weighing just 0.325 kg.
The ABB MS132-12 is purpose-built for the protection and manual switching of three-phase motors up to 12 A in industrial environments. Typical applications include conveyor drives, pump motor protection, compressor starters, HVAC fan motor control, and machine tool panels. Its 100 kA breaking capacity at 400 VAC makes the MS132-12 suitable for installation in high fault-level distribution systems without additional current limiting fuses. The compact 45 mm DIN rail footprint allows space-efficient motor control centre (MCC) design, while its wide range of approvals — including ATEX and IECEx — enables deployment in hazardous area installations.
| Product Net Width | 45 mm |
|---|---|
| Product Net Height | 97.8 mm |
| Product Net Depth / Length | 86.55 mm |
| Product Net Weight | 0.31 kg |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (230 V AC) 100 kA, (250 V DC) 3 Poles in Series 10 kA, (400 V AC) 100 kA, (440 V AC) 30 kA, (500 V AC) 20 kA, (690 V AC) 3 kA |
|---|---|
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (230 V AC) 100 kA, (400 V AC) 100 kA, (440 V AC) 30 kA, (500 V AC) 20 kA, (690 V AC) 3 kA |
| Rated Instantaneous Short-Circuit Current Setting (Ii) | 180 A |
| Setting Range | 8.0 ... 12 A |
| Rated Operational Power AC-3 (Pe) | (400 V) Three Phase 5.5 kW |
| Rated Operational Power AC-3e (Pe) | (400 V) Three Phase 5.5 kW |
| Rated Operational Voltage | Main Circuit 690 V AC, Main Circuit 250 V DC |
| Rated Operational Current (Ie) | 12 A |
| Rated Operational Current AC-3 (Ie) | 12 A |
| Rated Operational Current AC-3e (Ie) | 12 A |
| Rated Operational Current DC-5 (Ie) | 12 A |
| Rated Frequency (f) | Main Circuit 50 Hz, Main Circuit 60 Hz |
| Operating Frequency (fsw) | 0 ... 400 Hz |
| Rated Impulse Withstand Voltage (Uimp) | Main Circuit 6 kV |
| Rated Insulation Voltage (Ui) | 690 V |
| Power Loss | at Rated Operating Conditions AC-3 per Pole 2.3 W |
| Number of Poles | 3P |
| Conventional Free-air Thermal Current (Ith) | Main Circuit 12 A |
| Degree of Protection | Housing IP20, Main Circuit Terminals IP10 |
| Pollution Degree | 3 |
| Electrical Durability | 50000 cycle |
| Mechanical Durability | Nr. Operations 100000 cycle |
| Terminal Type | Screw Terminals |
| Connecting Capacity Main Circuit | Flexible with Ferrule 1/2x 0.75 ... 6 mm², Flexible with Insulated Ferrule 1/2x 0.75 ... 6 mm², Flexible 1/2x 1 ... 2.5 mm², Flexible 1/2x 2.5 ... 6 mm², Rigid 1/2x 1 ... 2.5 mm², Rigid 1/2x 2.5 ... 6 mm² |
| Tightening Torque | Main Circuit 2 N·m |
| Wire Stripping Length | Main Circuit 10 mm |
| Recommended Screw Driver | Pozidriv 2 |
| Mounting Position | 1 ... 6 |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| Minimum Mounting Distance | Electrical Conductive Board, Horizontal - Up to 400 V 0 mm, Electrical Conductive Board, Horizontal - Up to 690 V 1.5 mm, Electrical Conductive Board, Vertical 75 mm, Other Device Same Type, Horizontal 0 mm, Other Device Same Type, Vertical 150 mm |
| Contact Position Indication | ON / OFF / TRIP |
| Standards | IEC/EN 60947-1, IEC/EN 60947-2, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1, IEC 60335-2-40 A2L |
| Remarks | UL508 Self-Protected Combination Motor Controller (Type E) in combination with feeder block S1-M3-xx |
| Short-Circuit Current Rating (SCCR) UL/CSA | Manual Self-Protected Combination Controllers (Type E), (480Y / 277 V AC) 30 kA, Any UL Listed Fuses or Circuit-Breakers, Group Installations (480 V AC) 35 kA, Any UL Listed Fuses or Circuit-Breakers, Group Installations (600 V AC) 35 kA, Any UL Listed Fuses or Circuit-Breakers, Motor Disconnect (480 V AC) 30 kA, Any UL Listed Fuses or Circuit-Breakers, Motor Disconnect (600 V AC) 18 kA, Any UL Listed Fuses or Circuit-Breakers, Tap Conductor Protection in Group Installations (480Y / 277 V AC) 30 kA, Any UL Listed Fuses or Circuit-Breakers, Tap Conductor Protection in Group Installations (600Y / 347 V AC) 18 kA |
|---|---|
| Maximum Operating Voltage UL/CSA | Main Circuit 600 V AC |
| Horsepower Rating UL/CSA | (200 V AC) Three Phase 3 Hp, (208 V AC) Three Phase 3 Hp, (220 ... 240 V AC) Three Phase 3 Hp, (440 ... 480 V AC) Three Phase 7.5 Hp, (550 ... 600 V AC) Three Phase 10 Hp |
| Full Load Amps Motor Use | (200 V AC) Three Phase 11 A, (208 V AC) Three Phase 10.6 A, (220 ... 240 V AC) Three Phase 9.6 A, (440 ... 480 V AC) Three Phase 11 A, (550 ... 600 V AC) Three Phase 11 A |
| Locked Rotor Amps | (200 V AC) Three Phase 73.6 A, (208 V AC) Three Phase 71 A, (220 ... 240 V AC) Three Phase 64 A, (440 ... 480 V AC) Three Phase 63.5 A, (550 ... 600 V AC) Three Phase 64.8 A |
| General Use Rating UL/CSA | (600 V AC) 12 A |
| Connecting Capacity Main Circuit UL/CSA | Flexible 1/2x 16-8 AWG, Stranded 1/2x 16-8 AWG |
| Tightening Torque UL/CSA | Main Circuit 18 in·lb |
| Part number | 1SAM350000R1012 |
|---|---|
| Type designation | MS132-12 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 4013614400124 |
| ETIM class | EC000074 |
| eCl@ss | 27370401 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362010 |
| Ambient Air Temperature | Around the Enclosure 0 ... +40 °C, Operation -25 ... +70 °C, Operation Compensated -25 ... +60 °C, Storage -50 ... +80 °C |
|---|---|
| Ambient Air Temperature Compensation | Yes |
| Maximum Operating Altitude Permissible | 2000 m |
| Resistance to Shock acc. to IEC 60068-2-27 | 11 ms Pulse 25g |
| Resistance to Vibrations | 5g 3 ... 150 Hz |
| REACH Declaration | 1SAA963005-4502 |
|---|---|
| RoHS Declaration | 1SAA963006-4501 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006539 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| ETIM 10 | EC000074 - Motor protection circuit-breaker |
|---|---|
| eClass | V11.0 : 27370401 |
| UNSPSC | 39121521 |
| E-Number (Sweden) | 3112131 |
| Package Level 1 Units | box 1 piece |
|---|---|
| Package Level 1 Width | 92 mm |
| Package Level 1 Depth / Length | 102 mm |
| Package Level 1 Height | 50 mm |
| Package Level 1 Gross Weight | 0.325 kg |
| Package Level 1 EAN | 4013614400124 |
| Package Level 2 Units | carton 40 piece |
| Package Level 2 Width | 280 mm |
| Package Level 2 Depth / Length | 395 mm |
| Package Level 2 Height | 210 mm |
| Package Level 2 Gross Weight | 13.386 kg |
| Package Level 2 EAN | 4013614409028 |
| Shipping weight | 0.325 kg |
| Ships from | Türkiye |
| Dispatch | 11 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheet| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 0.16 A | 1SAM350000R1001 | MS132-0.16 | In stock | $38.21 | |||
| 0.25 A | 1SAM350000R1002 | MS132-0.25 | In stock | $38.21 | |||
| 0.40 A | 1SAM350000R1003 | MS132-0.4 | Low stock | $36.27 | |||
| 0.63 A | 1SAM350000R1004 | MS132-0.63 | In stock | $36.27 | |||
| 1.0 A | 1SAM350000R1005 | MS132-1.0 | In stock | $36.27 | |||
| 1.6 A | 1SAM350000R1006 | MS132-1.6 | In stock | $36.27 | |||
| 2.5 A | 1SAM350000R1007 | MS132-2.5 | In stock | $36.27 | |||
| 4.00 A | 1SAM350000R1008 | MS132-4.0 | In stock | $36.27 | |||
| 6.3 A | 1SAM350000R1009 | MS132-6.3 | In stock | $36.27 | |||
| 10 A | 1SAM350000R1010 | MS132-10 | In stock | $39.73 | |||
| 12 A | 1SAM350000R1012 This part | MS132-12 | In stock | $44.03 | |||
| 16 A | 1SAM350000R1011 | MS132-16 | In stock | $44.03 | |||
| 20 A | 1SAM350000R1013 | MS132-20 | In stock | $47.55 |
The rated current of MS132-12 is 12 A.
The rated operational voltage of MS132-12 is 400 V AC.
The tariff (HS) code on file for MS132-12 is 85362010.
The EAN (GTIN) of MS132-12 is 4013614400124.
MS132-12 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
