ABB 1SAE351111R0631 ESB63-31N-06 30A 3NO+1NC 230V 3-Pole Installation Contactor for Distribution Board
Brand:
ABB
Reference No:
1SAE351111R0631
Catalog No:
ESB63-31N-06
Series:
ESB63-N
Tariff Code (GTIP):
85365080
Stock: 4
Delivery time: 1 business day(s)
Shipping Origin: Turkey EXW
$85.15
- Description
The ABB ESB63-31N-06 (SKU: 1SAE351111R0631) is a 30A installation contactor from the ESB63-N series, designed for distribution board applications with a 3NO+1NC contact configuration and 230V AC control circuit rated for operation up to 400Hz. The ESB63-31N-06 delivers reliable switching performance in residential, commercial, and light-industrial distribution panels where efficient load control is required.
Technical Specifications
| Catalog Number | ESB63-31N-06 |
| SKU | 1SAE351111R0631 |
| Brand | ABB |
| Series | ESB63-N |
| Rated Current | 30 A |
| Control Voltage | 230 V AC |
| Control Circuit Frequency | 400 Hz |
| Number of Poles | 3 |
| Contact Configuration | 3NO + 1NC |
| Dimensions (W x D x H) | 54 x 65 x 85 mm |
| Weight | 0.405 kg |
| EAN | 4013614519222 |
Certifications & Standards
- CE: Conformité Européenne — meets EU safety, health, and environmental requirements
- UKCA: UK Conformity Assessed — meets Great Britain market requirements post-Brexit
- UL: Underwriters Laboratories listing for North American market safety compliance
- UL 240: UL standard for AC general-use snap switches
- UL 480: UL standard for industrial control equipment
- UL 2799: UL standard for electrical vehicle supply equipment (zero-emission focus)
- CSA: Canadian Standards Association certification for Canadian market compliance
- IEC 60947-1: International standard for low-voltage switchgear and controlgear — general rules
- EN 60947-1: European harmonised standard for low-voltage switchgear and controlgear — general rules
- IEC/EN 60947-1: Combined IEC and EN standard for low-voltage switchgear — general requirements
- IEC/EN 60947-4: Standard for low-voltage contactors and motor starters
- IEC/EN 61095: Standard for electromechanical contactors for household and similar purposes
- IEC 60335-2: Standard for safety of household and similar electrical appliances
- IEC 60068-2: Standard for environmental testing of electrotechnical products
- EN 60947-4: European standard for contactors and motor starters
- EN 61095: European standard for electromechanical contactors for household use
- EN45555: European standard for ecodesign requirements for networked standby equipment
- DNV: Det Norske Veritas certification — marine and offshore industry compliance
- RINA: Registro Italiano Navale — marine classification society certification
- CCC: China Compulsory Certification for the Chinese market
- REACH: EU regulation on Registration, Evaluation, Authorisation and Restriction of Chemicals
- RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
- WEEE: Waste Electrical and Electronic Equipment Directive compliance for responsible end-of-life disposal
Applications & Use Cases
- Residential and commercial distribution board load switching
- Lighting control circuits in building automation systems
- Heating, ventilation, and air conditioning (HVAC) switching
- On/off control of resistive and inductive loads in control panels
- Marine and offshore electrical distribution systems (DNV/RINA certified)
- Energy management and smart metering panel assemblies
Technical Details
Catalog No
ESB63-31N-06
Number of Poles
3
Delivery Date (Days)
1 days
Model Number
ESB63-31N-06
Tariff Code
85365080
