- Part number
- 6GK5992-4AL00-8AA0
- Model no
- MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m.
Siemens has announced the end of 6GK5992-4AL00-8AA0
Once production ends, supply depends on remaining stock.
No replacement announced yet. Tell us the application and we will propose an alternative.
- CE
SCALANCE XSiemens 6GK5992-4AL00-8AA0 SCALANCE X MM992-4 4x 1000 Mbit/s SC Multimode 750 m Media Module
Siemens MM992-4 SCALANCE X media module: four 1000 Mbit/s SC multimode ports, up to 750 m, IP20, 0-60 deg C.
Description
About the MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m.
About the MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m.
The Siemens 6GK5992-4AL00-8AA0 (MM992-4) is a SCALANCE X media module that adds four 1000 Mbit/s SC optical ports for multimode fiber. Each port covers a link of up to 750 m at 850 nm, giving a switch four independent Gigabit fiber segments from one media module slot. It operates from 0 to 60 degrees C, weighs 0.3 kg, and latches into the media module slot.
Certifications & Standards
- CE
- C-Tick
- KC
- BV
- EPD
Selection Notes
The MM992-4 carries four independent 1000 Mbit/s SC ports on one media module, so it fits SCALANCE X switches that need to fan out to four multimode Gigabit fiber runs rather than one. Its 850 nm multimode optics cap the range at 750 m, which suits fiber runs within a building or between nearby cabinets; for longer single-mode spans at the same 1000 Mbit/s rate, the LD single-mode media module in this family is the correct choice instead of this multimode module. Because all four ports sit on one card, a fault on the module takes down all four links together, a factor to weigh against four separate single-port SFPs when link independence matters.
Specification
Full specification
General 2
| product type designation | MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. |
|---|---|
| product brand name | SCALANCE |
Interfaces 10
| number of electrical/optical connections / for network components or terminal equipment / maximum | 4 |
|---|---|
| number of optical interfaces / for network components or terminal equipment / maximum | 4 |
| number of 1000 Mbit/s SC ports (SX) | 4 |
| design of the optical interface / for network components or terminal equipment | SC |
| wavelength / of the optical interface | 850 nm; Multi-mode |
| connectable optical power relative to 1 mW: of the transmitter output / minimum | -9.5 dB |
| connectable optical power relative to 1 mW: of the receiver input / maximum | -3 dB |
| optical sensitivity relating to 1 mW / of the receiver input / minimum | -17 dB |
| attenuation factor / of the FOC transmission link / minimum necessary | 0 dB |
| range / at the optical interface / depending on the optical fiber used | 0 ... 0.75 km |
Ambient conditions 5
| ambient temperature: during operation | 0 ... 60 °C |
|---|---|
| ambient temperature: during storage | -40 ... +85 °C |
| ambient temperature: during transport | -40 ... +85 °C |
| relative humidity / at 25 °C / without condensation / during operation / maximum | 95 % |
| protection class IP | IP20 |
Show all 58 specifications ↓ Show less ↑41 more values in Identification, Design, dimensions and weights, Standards, specifications, approvals, Standards, specifications, approvals / Environmental Product Declaration, Declaration of Con- China RoHS Manufacturer Declara-, Logistics.
Identification 10
| Part number | 6GK5992-4AL00-8AA0 |
|---|---|
| Type designation | MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Phase-out announced by the manufacturer |
| EAN | 4019169233194 |
| ETIM class | EC001099 |
| eCl@ss | 19170301 |
Design, dimensions and weights 6
| design | Media module |
|---|---|
| width | 120.3 mm |
| height | 22.3 mm |
| depth | 275.5 mm |
| fastening method | latched |
| installation in media module slot | Yes |
Standards, specifications, approvals 11
| standard: for safety / from CSA and UL | UL 60950-1, CSA C22.2 No. 60950-1 |
|---|---|
| standard: for emitted interference | EN 61000-6-4 (Class A) |
| standard: for interference immunity | EN 61000-6-2 |
| certificate of suitability | EN 61000-6-2:2005, EN 61000-6-4:2007 |
| CE marking | Yes |
| C-Tick | Yes |
| KC approval | Yes |
| CCC / for hazardous zone according to GB standard | Yes; GB3836.1, GB3836.8 |
| CCC / for hazardous zone according to GB standard / as marking | Ex nA IIC T4 Gc |
| E1 approval | No |
| Marine classification association: French marine classification society (BV) | Yes |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 95.67 kg |
| global warming potential [CO2 eq]: during manufacturing | 10.1 kg |
| global warming potential [CO2 eq]: during operation | 85.47 kg |
| global warming potential [CO2 eq]: after end of life | 0.1 kg |
Declaration of Con- China RoHS Manufacturer Declara- 2
| formity tion | For use in hazard- |
|---|---|
| General Product Approval EMV China RoHS | ous locations |
Logistics 7
| Net weight | 0.457 kg |
|---|---|
| Package dimensions | 127 × 134 × 147 mm |
| Country of origin | DE |
| Shipping weight | 0.957 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6GK5992-4AL00-8AA0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- CE marking
- C-Tick
- KC approval
- French marine classification society (BV)
- Environmental Product Declaration
Quick answers
Questions about the MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m.
What is the HS code of MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. for customs?
The tariff (HS) code on file for MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. is 85176200.
What is the EAN of MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m.?
The EAN (GTIN) of MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. is 4019169233194.
Where does MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. ship from, and how fast?
MM992-4 SCALANCE X accessory; Media module MM992-4; 4x 1000 Mbit/s SC-ports, optical; multimode optical up to max. 750 m. ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
