- Part number
- 6GK5766-1GE00-7TA0
- Model no
- WAM766-1 EEC
Siemens 6GK5766-1GE00-7TA0 SCALANCE WAM766-1 EEC Wi-Fi 6 IP65/IP67 Industrial WLAN Access Point
SCALANCE WAM766-1 EEC IWLAN access point, Wi-Fi 6, 1201 Mbit/s, IP65/IP67, -30 to +75C, railway certified.
Description
About the WAM766-1 EEC
About the WAM766-1 EEC
The Siemens 6GK5766-1GE00-7TA0 SCALANCE WAM766-1 EEC is an IWLAN access point built for expanded environmental conditions, with two 2.4/5 GHz radios supporting IEEE 802.11ax (Wi-Fi 6) at up to 1201 Mbit/s gross per radio. Conformal coating, an IP65/IP67 enclosure, and a -30 to +75 degrees C operating range extend the base WAM766-1 for rolling stock and outdoor duty, with PoE on the M12 Gigabit port plus redundant 24 V DC input.
Certifications & Standards
- CE
- E1
- EN 50155
- EN 50121-4
- EN 45545-2
Selection Notes
Conformal coating and the wider -30 to +75 degrees C range are what separate this EEC variant from the standard WAM766-1 - both target panels exposed to condensation, vibration, or fuel and oil vapor that a standard PCB coating would not survive. The IP65/IP67 rating covers washdown and brief immersion, useful on vehicle roofs or outdoor gantries where the base IP65 unit would need an added enclosure. Eight SSIDs and the same 1201 Mbit/s radio pair as the base model mean throughput is unchanged - only ruggedization differs. Pick the standard WAM766-1 instead for fixed indoor cabinets where the extended temperature range and coating add cost without a use case.
Specification
Full specification
General 3
| product type designation | WAM766-1 EEC |
|---|---|
| product description | IWLAN Access Point IWLAN access point, SCALANCE WAM766-1 EEC, 1 radio, 2.4/5 GHz, 2 N- Connect connections, iFeatures support via CLP, IEEE 802.11ax (Wi-Fi 6), 1201 Mbps (gross) per radio, 1x 10/100/1000 Mbps M12 socket X-encoded with PoE, redundant 24 V DC, M12 socket L-encoded, for expanded environmental conditions, IP65/IP67, -30...+75 °C, , CLP slot, DI/DQ, A-encoded, observe national approvals! CERT ID: MSAX65-W1-M12-E2 FCC ID: LYHMSAX65V1 operation outside of USA/Israel scope of supply: sealing caps for connections |
| product brand name | SCALANCE |
Transfer rate 2
| transfer rate: with WLAN / maximum | 1201 Mbit/s |
|---|---|
| transfer rate: for Industrial Ethernet | 10, 100, 1000 Mbit/s |
Interfaces 7
| number of electrical/optical connections / for network components or terminal equipment / maximum / note | 1 |
|---|---|
| number of electrical/optical connections / for gigabit Ethernet / maximum | 1 |
| number of electrical connections: for network components or terminal equipment | 1 |
| number of electrical connections: for power supply | 1 |
| number of electrical connections: for redundant voltage supply | 1 |
| type of electrical connection: for network components or terminal equipment | M12 interface (8-pole, X-coded), PoE |
| type of electrical connection: for redundant voltage supply | M12 interface (4-pin, L-coded) |
Show all 159 specifications ↓ Show less ↑147 more values in Identification, Memory, Interfaces / wireless, Signal inputs/outputs, Ambient conditions, Design, dimensions and weights, Radio frequencies, Product features, product functions, product components / general, Product functions / management, configuration, engineering, Product functions / diagnostics, Product functions / VLAN, Product functions / DHCP, Product functions / redundancy, Product functions / security, Product functions / time, Standards, specifications, approvals, Standards, specifications, approvals / hazardous environments, Standards, specifications, approvals / Environmental Product Declaration, Declaration of Con- Manufacturer Declara- China RoHS, Logistics.
Identification 10
| Part number | 6GK5766-1GE00-7TA0 |
|---|---|
| Type designation | WAM766-1 EEC |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4047622889930 |
| ETIM class | EC000816 |
| eCl@ss | 19170212 |
Memory 2
| design of the removable storage: CLP | Yes |
|---|---|
| design of the removable storage: CLP iFeatures | Yes |
Interfaces / wireless 6
| number of radio cards / permanently installed | 2 |
|---|---|
| transmission mode / for multiple input multiple output (MIMO) | 2x2 |
| number of spatial streams | 2 |
| number of electrical connections / for external antenna(s) | 2 |
| type of electrical connection / for external antenna(s) | N-Connect (socket) |
| product feature / external antenna can be mounted directly on device | Yes |
Signal inputs/outputs 22
| number of digital inputs | 1 |
|---|---|
| number of digital outputs | 1 |
| type of electrical connection / at the digital inputs/outputs | M12 interface (4-pin, A-coded) |
| input voltage / at digital input / at DC | -30 ... +30 V |
| output voltage / at digital output / at DC / maximum | 24 V; 0,5 A |
| operational current / of the signaling contacts / at DC / at 30 V / maximum supply voltage, current consumption, power loss | 0.008 A |
| type of voltage / of the supply voltage | Redundant 24 V DC Power Supply, M12, L-coded |
| supply voltage: from Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af | 48 V |
| consumed current: at DC / at 24 V | 0.55 A |
| consumed current: at DC / at 24 V / sleep mode / maximum | 0.013 A |
| consumed current: with Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical | 0.27 A |
| power loss [W]: at DC / at 24 V | 13.2 W |
| power loss [W]: at DC / at 24 V / sleep mode / maximum | 0.3 W |
| power loss [W]: with Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical | 12.96 W |
| supply voltage / 1: from M12 power Connector (L-coded) for redundant voltage supply | 24 V |
| supply voltage / 1 / rated value | 24 V |
| type of voltage / 1 / of the supply voltage | DC |
| supply voltage / 2: from M12 power Connector (L-coded) for redundant voltage supply | 24 V |
| supply voltage / 2 / rated value | 24 V |
| type of voltage / 2 / of the supply voltage | DC |
| supply voltage / 3 / rated value | 48 V |
| type of voltage / 3 / of the supply voltage | DC, PoE |
Ambient conditions 5
| ambient temperature: during operation | -30 ... +75 °C |
|---|---|
| ambient temperature: during storage | -40 ... +85 °C |
| ambient temperature: during transport | -40 ... +85 °C |
| relative humidity / at 25 °C / without condensation / during operation / maximum | 90 % |
| protection class IP | IP65/IP67 |
Design, dimensions and weights 13
| width | 150 mm |
|---|---|
| height | 179.5 mm |
| depth | 45 mm |
| width / of the enclosure / without antenna | 150 mm |
| height / of the enclosure / without antenna | 179.5 mm |
| depth / of the enclosure / without antenna | 45 mm |
| product feature / conformal coating | Yes |
| fastening method | wall mounting and assembly on VESA support 75 x 75 mm, mounting on DIN rail with separate mounting adapter. |
| S7-300 rail mounting | Yes |
| S7-1500 rail mounting | Yes |
| 35 mm DIN-rail mounting | Yes |
| wall mounting | Yes |
| VESA mounting | Yes; 75 x 75mm |
Radio frequencies 2
| operating frequency: for WLAN in 2.4 GHz frequency band | 2.41 ... 2.48 GHz; depending on the country approvals |
|---|---|
| operating frequency: for WLAN in 5 GHz frequency band | 4.9 ... 5.8 GHz; depending on the country approvals |
Product features, product functions, product components / general 9
| product function / Access Point Mode | Yes |
|---|---|
| product function / client Mode | Yes |
| number of SSIDs | 8 |
| product function: iPCF Access Point | No; iPCF-2 is not compatible with iPCF. See documentation for function description. |
| product function: iPCF-2 access point | Yes; Only in combination with the 'SCALANCE CLP 2GB W700 AP iFeatures' or 'SCALANCE CLP 2GB W700 Client iFeatures' |
| product function: iPCF client | No |
| product function: iPCF-2 client | Yes; Only in combination with the 'SCALANCE CLP 2GB W700 AP iFeatures' or 'SCALANCE CLP 2GB W700 Client iFeatures' |
| product function: iPCF-MC Access Point | No |
| product function / iPRP | Yes |
Product functions / management, configuration, engineering 19
| number of manageable IP addresses / in client | 2 |
|---|---|
| product function: CLI | Yes |
| product function: web-based management | Yes |
| product function: MIB support | Yes |
| product function: TRAPs via email | Yes |
| product function: configuration with STEP 7 | Yes |
| product function: configuration with STEP 7 in the TIA Portal | Yes |
| product function: WDS | No |
| protocol / is supported: Address Resolution Protocol (ARP) | Yes |
| protocol / is supported: ICMP | Yes |
| protocol / is supported: Telnet | Yes |
| protocol / is supported: HTTP | Yes |
| protocol / is supported: HTTPS | Yes |
| protocol / is supported: TFTP | Yes |
| protocol / is supported: DCP | Yes |
| protocol / is supported: LLDP | Yes |
| identification & maintenance function: I&M0 - device-specific information | Yes |
| identification & maintenance function: I&M1 - higher level designation/location designation | Yes |
| product function / is supported / identification link | Yes; acc. to IEC 61406-1:2022 |
Product functions / diagnostics 5
| product function: PROFINET IO diagnosis | Yes |
|---|---|
| product function: SysLog | Yes |
| protocol / is supported: SNMP v1 | Yes |
| protocol / is supported: SNMP v2 | Yes |
| protocol / is supported: SNMP v3 | Yes |
Product functions / VLAN 2
| product function: function VLAN with IWLAN | Yes |
|---|---|
| number of VLANs / maximum | 24 |
Product functions / DHCP 1
| product function: DHCP client | Yes |
|---|
Product functions / redundancy 4
| protocol / is supported: STP/RSTP | Yes |
|---|---|
| protocol / is supported: MSTP | Yes |
| protocol / is supported: RSTP | Yes |
| product function: redundancy procedure MSTP | Yes |
Product functions / security 10
| product function: management security, ACL-IP based | No |
|---|---|
| product function: IEEE 802.1x (radius) | Yes |
| product function: NAT/NAPT | Yes |
| product function: access protection according to IEEE802.11i | Yes |
| product function: WPA/WPA2 | Yes |
| product function: WPA3 | Yes |
| product function: TKIP/AES | Yes |
| product function: RADIUS client | Yes |
| protocol / is supported: SSH | Yes |
| key length: with SSL | 4096 bit |
Product functions / time 3
| protocol / is supported: NTP | Yes |
|---|---|
| protocol / is supported: SNTP | Yes |
| protocol / is supported: SIMATIC time synchronization (SIMATIC Time) | Yes |
Standards, specifications, approvals 18
| certificate of suitability: EC Declaration of Conformity | Yes |
|---|---|
| certificate of suitability: CE marking | Yes |
| certificate of suitability: E1 approval | Yes |
| certificate of suitability: railway application in accordance with EN 50155 | Yes |
| certificate of suitability: fire protection in accordance with EN 45545-2 | Yes |
| certificate of suitability: Power-over-Ethernet according IEEE802.3at for type 1 and IEEE802.3af | Yes |
| standard for wireless communication: IEEE 802.11a | Yes |
| standard for wireless communication: IEEE 802.11b | Yes |
| standard for wireless communication: IEEE 802.11e | Yes |
| standard for wireless communication: IEEE 802.11g | Yes |
| standard for wireless communication: IEEE 802.11h | Yes |
| standard for wireless communication: IEEE 802.11i | Yes |
| standard for wireless communication: IEEE 802.11n | Yes |
| standard for wireless communication: IEEE 802.11ac | Yes |
| standard for wireless communication: IEEE 802.11ax | Yes |
| standard for wireless communication: IEEE 802.11r | Yes |
| MTBF | 24 a |
| reference temperature | 40 °C |
Standards, specifications, approvals / hazardous environments 2
| standard / for hazardous zone | EN IEC 60079-0 : 2018, EN60079-7:2015 + A1 : 2018; II 3 G Ex ec IIC T4 Gc |
|---|---|
| from CSA and UL | UL121201, CAN/CSA C22.2 No.213, Cl. 1, div. 2, GP. A, B, C, D, T4 / Cl. 1, Zone 2, GP IIC T4, UL File E240480 |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 394.89 kg |
| global warming potential [CO2 eq]: during manufacturing | 33.7 kg |
| global warming potential [CO2 eq]: during operation | 361 kg |
| global warming potential [CO2 eq]: after end of life | 0.19 kg |
Declaration of Con- Manufacturer Declara- China RoHS 2
| formity tion | For use in hazard- |
|---|---|
| General Product Approval | ous locations |
Logistics 7
| Net weight | 0.5 kg |
|---|---|
| Package dimensions | 45 × 140 × 160 mm |
| Country of origin | DE |
| Shipping weight | 1.0 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 31 Oct 2026
Documents
Documents for 6GK5766-1GE00-7TA0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- EC Declaration of Conformity
- CE marking
- E1 approval
- railway application in accordance with EN 50155
- railway application in accordance with EN 50121-4
- fire protection in accordance with EN 45545-2
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11e
- IEEE 8
Quick answers
Questions about the WAM766-1 EEC
What is the HS code of WAM766-1 EEC for customs?
The tariff (HS) code on file for WAM766-1 EEC is 85176200.
What is the EAN of WAM766-1 EEC?
The EAN (GTIN) of WAM766-1 EEC is 4047622889930.
Where does WAM766-1 EEC ship from, and how fast?
WAM766-1 EEC ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
