- Part number
- 6GK5766-1GE00-3DA0
- Model no
- WUM766-1
Siemens 6GK5766-1GE00-3DA0 SCALANCE WUM766-1 IWLAN Client Wi-Fi 6 1201 Mbit/s Industrial WLAN Access Point
SCALANCE WUM766-1 IWLAN client module, Wi-Fi 6, 1201 Mbit/s, PoE M12 Gigabit Ethernet, redundant 24 V DC, IP65.
Description
About the WUM766-1
About the WUM766-1
The Siemens 6GK5766-1GE00-3DA0 SCALANCE WUM766-1 is an IWLAN client module with two permanently installed 2.4/5 GHz radios supporting IEEE 802.11ax (Wi-Fi 6) at up to 1201 Mbit/s gross per radio in 2x2 MIMO. It connects over a PoE-capable M12 Gigabit Ethernet port and takes redundant 24 V DC through an M12 L-coded connector, with an IP65 enclosure rated -30 to +60 degrees C and two N-Connect ports for external antennas.
Certifications & Standards
- EC
- CE
- E1
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11e
- IEEE 802.11g
- IEEE 802.11h
- IEEE 802.11i
- IEEE 802.11n
Selection Notes
This client-only variant carries a single SSID and two N-Connect antenna ports, so it pairs one wired Gigabit segment to one WLAN uplink rather than serving as a multi-client access point. The redundant 24 V DC input plus PoE on the same M12 Gigabit port lets it run from either a local supply or the switch upstream, which matters on machines where the PLC cabinet supplies 24 V but the network cabinet only carries PoE. The IP65 rating and -30 to +60 degrees C range support direct machine-frame or vehicle mounting without an additional enclosure. Choose the access-point variant in the same enclosure family when multiple wireless clients need to associate to one radio instead of a single client uplink.
Specification
Full specification
General 3
| product type designation | WUM766-1 |
|---|---|
| product description | IWLAN client module IWLAN client, SCALANCE WUM766-1 1 radio, 2.4/5 GHz, 2 N-Connect connections, iFeatures support via CLP, IEEE 802.11ax (Wi-Fi 6), 1201 Mbps (gross) per radio, 1x 10/100/1000 Mbps M12 socket X-encoded with PoE, redundant 24 V DC, M12 socket L-encoded; IP65, -30...+60 °C, CLP slot, DI/DQ, A-encoded, observe national approvals! CERT ID: MSAX65-W1-M12-E2, FCC ID: LYHMSAX65V1 operation outside of USA/Israel scope of supply: sealing caps for connections |
| product brand name | SCALANCE |
Transfer rate 2
| transfer rate: with WLAN / maximum | 1201 Mbit/s |
|---|---|
| transfer rate: for Industrial Ethernet | 10, 100, 1000 Mbit/s |
Interfaces 7
| number of electrical/optical connections / for network components or terminal equipment / maximum / note | 1 |
|---|---|
| number of electrical/optical connections / for gigabit Ethernet / maximum | 1 |
| number of electrical connections: for network components or terminal equipment | 1 |
| number of electrical connections: for power supply | 1 |
| number of electrical connections: for redundant voltage supply | 1 |
| type of electrical connection: for network components or terminal equipment | M12 interface (8-pole, X-coded), PoE |
| type of electrical connection: for redundant voltage supply | M12 interface (4-pin, L-coded) |
Show all 154 specifications ↓ Show less ↑142 more values in Identification, Memory, Interfaces / wireless, Signal inputs/outputs, Ambient conditions, Design, dimensions and weights, Radio frequencies, Product features, product functions, product components / general, Product functions / management, configuration, engineering, Product functions / diagnostics, Product functions / VLAN, Product functions / DHCP, Product functions / redundancy, Product functions / security, Product functions / time, Standards, specifications, approvals, Standards, specifications, approvals / hazardous environments, Standards, specifications, approvals / Environmental Product Declaration, Logistics.
Identification 10
| Part number | 6GK5766-1GE00-3DA0 |
|---|---|
| Type designation | WUM766-1 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4047622889947 |
| ETIM class | EC000816 |
| eCl@ss | 19170209 |
Memory 2
| design of the removable storage: CLP | Yes |
|---|---|
| design of the removable storage: CLP iFeatures | Yes |
Interfaces / wireless 6
| number of radio cards / permanently installed | 2 |
|---|---|
| transmission mode / for multiple input multiple output (MIMO) | 2x2 |
| number of spatial streams | 2 |
| number of electrical connections / for external antenna(s) | 2 |
| type of electrical connection / for external antenna(s) | N-Connect (socket) |
| product feature / external antenna can be mounted directly on device | Yes |
Signal inputs/outputs 22
| number of digital inputs | 1 |
|---|---|
| number of digital outputs | 1 |
| type of electrical connection / at the digital inputs/outputs | M12 interface (4-pin, A-coded) |
| input voltage / at digital input / at DC | -30 ... +30 V |
| output voltage / at digital output / at DC / maximum | 24 V; 0,5 A |
| operational current / of the signaling contacts / at DC / at 30 V / maximum supply voltage, current consumption, power loss | 0.008 A |
| type of voltage / of the supply voltage | Redundant 24 V DC Power Supply, M12, L-coded |
| supply voltage: from Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af | 48 V |
| consumed current: at DC / at 24 V | 0.55 A |
| consumed current: at DC / at 24 V / sleep mode / maximum | 0.013 A |
| consumed current: with Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical | 0.27 A |
| power loss [W]: at DC / at 24 V | 13.2 W |
| power loss [W]: at DC / at 24 V / sleep mode / maximum | 0.3 W |
| power loss [W]: with Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical | 12.96 W |
| supply voltage / 1: from M12 power Connector (L-coded) for redundant voltage supply | 24 V |
| supply voltage / 1 / rated value | 24 V |
| type of voltage / 1 / of the supply voltage | DC |
| supply voltage / 2: from M12 power Connector (L-coded) for redundant voltage supply | 24 V |
| supply voltage / 2 / rated value | 24 V |
| type of voltage / 2 / of the supply voltage | DC |
| supply voltage / 3 / rated value | 48 V |
| type of voltage / 3 / of the supply voltage | DC, PoE |
Ambient conditions 5
| ambient temperature: during operation | -30 ... +60 °C |
|---|---|
| ambient temperature: during storage | -40 ... +85 °C |
| ambient temperature: during transport | -40 ... +85 °C |
| relative humidity / at 25 °C / without condensation / during operation / maximum | 90 % |
| protection class IP | IP65 |
Design, dimensions and weights 12
| width | 150 mm |
|---|---|
| height | 179.5 mm |
| depth | 45 mm |
| width / of the enclosure / without antenna | 150 mm |
| height / of the enclosure / without antenna | 179.5 mm |
| depth / of the enclosure / without antenna | 45 mm |
| fastening method | wall mounting and assembly on VESA support 75 x 75 mm, mounting on DIN rail with separate mounting adapter. |
| S7-300 rail mounting | Yes |
| S7-1500 rail mounting | Yes |
| 35 mm DIN-rail mounting | Yes |
| wall mounting | Yes |
| VESA mounting | Yes; 75 x 75mm |
Radio frequencies 2
| operating frequency: for WLAN in 2.4 GHz frequency band | 2.41 ... 2.48 GHz; depending on the country approvals |
|---|---|
| operating frequency: for WLAN in 5 GHz frequency band | 4.9 ... 5.8 GHz; depending on the country approvals |
Product features, product functions, product components / general 9
| product function / Access Point Mode | No |
|---|---|
| product function / client Mode | Yes |
| number of SSIDs | 1 |
| product function: iPCF Access Point | No; iPCF-2 is not compatible with iPCF. See documentation for function description. |
| product function: iPCF-2 access point | No; Only in combination with the 'SCALANCE CLP 2GB W700 AP iFeatures' or 'SCALANCE CLP 2GB W700 Client iFeatures' |
| product function: iPCF client | No |
| product function: iPCF-2 client | Yes; Only in combination with the 'SCALANCE CLP 2GB W700 AP iFeatures' or 'SCALANCE CLP 2GB W700 Client iFeatures' |
| product function: iPCF-MC Access Point | No |
| product function / iPRP | Yes |
Product functions / management, configuration, engineering 19
| number of manageable IP addresses / in client | 2 |
|---|---|
| product function: CLI | Yes |
| product function: web-based management | Yes |
| product function: MIB support | Yes |
| product function: TRAPs via email | Yes |
| product function: configuration with STEP 7 | Yes |
| product function: configuration with STEP 7 in the TIA Portal | Yes |
| product function: WDS | No |
| protocol / is supported: Address Resolution Protocol (ARP) | Yes |
| protocol / is supported: ICMP | Yes |
| protocol / is supported: Telnet | Yes |
| protocol / is supported: HTTP | Yes |
| protocol / is supported: HTTPS | Yes |
| protocol / is supported: TFTP | Yes |
| protocol / is supported: DCP | Yes |
| protocol / is supported: LLDP | Yes |
| identification & maintenance function: I&M0 - device-specific information | Yes |
| identification & maintenance function: I&M1 - higher level designation/location designation | Yes |
| product function / is supported / identification link | Yes; acc. to IEC 61406-1:2022 |
Product functions / diagnostics 5
| product function: PROFINET IO diagnosis | Yes |
|---|---|
| product function: SysLog | Yes |
| protocol / is supported: SNMP v1 | Yes |
| protocol / is supported: SNMP v2 | Yes |
| protocol / is supported: SNMP v3 | Yes |
Product functions / VLAN 2
| product function: function VLAN with IWLAN | Yes |
|---|---|
| number of VLANs / maximum | 24 |
Product functions / DHCP 1
| product function: DHCP client | Yes |
|---|
Product functions / redundancy 4
| protocol / is supported: STP/RSTP | Yes |
|---|---|
| protocol / is supported: MSTP | Yes |
| protocol / is supported: RSTP | Yes |
| product function: redundancy procedure MSTP | Yes |
Product functions / security 10
| product function: management security, ACL-IP based | No |
|---|---|
| product function: IEEE 802.1x (radius) | Yes |
| product function: NAT/NAPT | Yes |
| product function: access protection according to IEEE802.11i | Yes |
| product function: WPA/WPA2 | Yes |
| product function: WPA3 | Yes |
| product function: TKIP/AES | Yes |
| product function: RADIUS client | Yes |
| protocol / is supported: SSH | Yes |
| key length: with SSL | 4096 bit |
Product functions / time 3
| protocol / is supported: NTP | Yes |
|---|---|
| protocol / is supported: SNTP | Yes |
| protocol / is supported: SIMATIC time synchronization (SIMATIC Time) | Yes |
Standards, specifications, approvals 16
| certificate of suitability: EC Declaration of Conformity | Yes |
|---|---|
| certificate of suitability: CE marking | Yes |
| certificate of suitability: E1 approval | Yes |
| certificate of suitability: Power-over-Ethernet according IEEE802.3at for type 1 and IEEE802.3af | Yes |
| standard for wireless communication: IEEE 802.11a | Yes |
| standard for wireless communication: IEEE 802.11b | Yes |
| standard for wireless communication: IEEE 802.11e | Yes |
| standard for wireless communication: IEEE 802.11g | Yes |
| standard for wireless communication: IEEE 802.11h | Yes |
| standard for wireless communication: IEEE 802.11i | Yes |
| standard for wireless communication: IEEE 802.11n | Yes |
| standard for wireless communication: IEEE 802.11ac | Yes |
| standard for wireless communication: IEEE 802.11ax | Yes |
| standard for wireless communication: IEEE 802.11r | Yes |
| MTBF | 24 a |
| reference temperature | 40 °C |
Standards, specifications, approvals / hazardous environments 2
| standard / for hazardous zone | EN IEC 60079-0 : 2018, EN60079-7:2015 + A1 : 2018; II 3 G Ex ec IIC T4 Gc |
|---|---|
| from CSA and UL | UL121201, CAN/CSA C22.2 No.213, Cl. 1, div. 2, GP. A, B, C, D, T4 / Cl. 1, Zone 2, GP IIC T4, UL File E240480 |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 394.89 kg |
| global warming potential [CO2 eq]: during manufacturing | 33.7 kg |
| global warming potential [CO2 eq]: during operation | 361 kg |
| global warming potential [CO2 eq]: after end of life | 0.19 kg |
Logistics 7
| Net weight | 0.5 kg |
|---|---|
| Package dimensions | 45 × 150 × 180 mm |
| Country of origin | DE |
| Shipping weight | 1.0 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 31 Oct 2026
Documents
Documents for 6GK5766-1GE00-3DA0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- EC Declaration of Conformity
- CE marking
- E1 approval
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11e
- IEEE 802.11g
- IEEE 802.11h
- IEEE 802.11i
- IEEE 802.11n
Quick answers
Questions about the WUM766-1
What is the HS code of WUM766-1 for customs?
The tariff (HS) code on file for WUM766-1 is 85176200.
What is the EAN of WUM766-1?
The EAN (GTIN) of WUM766-1 is 4047622889947.
Where does WUM766-1 ship from, and how fast?
WUM766-1 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
