- Part number
- 6GK5763-1AL00-3AA0
- Model no
- WUM763-1
Critical stock
Dispatch
Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days.
· From Türkiye
0
- CE
Siemens 6GK5763-1AL00-3AA0 SCALANCE WUM763-1 IEEE 802.11ax Wi-Fi 6 4-Port IWLAN Access Point
SCALANCE WUM763-1 IWLAN client, IEEE 802.11ax Wi-Fi 6, 1201 Mbit/s, 4x RJ45, redundant 24 V DC, IP30.
Description
About the WUM763-1
About the WUM763-1
The Siemens 6GK5763-1AL00-3AA0 SCALANCE WUM763-1 is an IWLAN client module for connecting Industrial Ethernet devices to a wireless network over IEEE 802.11ax (Wi-Fi 6), delivering up to 1201 Mbit/s gross over 2x2 MIMO with two R-SMA antenna connections. It also provides 4x 10/100/1000 Mbit/s RJ45 ports, redundant 24 V DC supply, and an IP30 enclosure rated for -30...+60 degrees C operation.
Certifications & Standards
- EC
- CE
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11e
- IEEE 802.11g
- IEEE 802.11h
- IEEE 802.11i
- IEEE 802.11n
- IEEE 802.11ac
Selection Notes
The 2x2 MIMO configuration with two spatial streams and dual R-SMA antenna ports lets the WUM763-1 maintain link quality in reflective industrial environments where a single-antenna client would drop packets. iPCF-2 client mode is the relevant setting for handover-sensitive links such as moving equipment, since standard WLAN roaming timing is too slow for continuous control traffic. The CLP slot with iFeatures support means the base unit ships without certain licensed functions active; confirm which iFeatures are required before ordering the CLP separately. Redundant 24 V inputs on the terminal block support a dual power-supply architecture without an external transfer switch, and the IP30 rating means this unit belongs inside a cabinet or enclosure, not directly in a washdown or outdoor area.
Applications
Wireless extension of Industrial Ethernet to distributed I/O, cranes, and other equipment that cannot be hard-wired; client-side connectivity for PROFINET or S7 communication over a SCALANCE W access point infrastructure.
Specification
Full specification
General 3
| product type designation | WUM763-1 |
|---|---|
| product description | IWLAN client module IWLAN client, SCALANCE WUM763-1, 1 radio, 2.4/5GHz 2 R-SMA connections, iFeatures support via CLP, IEEE 802.11ax (Wi-Fi 6), 1201 Mbps (gross), 4x10/100/1000 Mbps RJ45 ports, redundant 24 V DC, terminal block, IP30, - 30..+60 °C, CLP slot observe national approvals! CERT ID: MSAX-W1-RJ-E2-NO FCC ID: LYHMSAXV1 operation outside of USA/Israel scope of supply: cover CLP slot, covers antenna connections, 1x terminal block. |
| product brand name | SCALANCE |
Transfer rate 2
| transfer rate: with WLAN / maximum | 1201 Mbit/s |
|---|---|
| transfer rate: for Industrial Ethernet | 10, 100, 1000 Mbit/s |
Interfaces 7
| number of electrical/optical connections / for network components or terminal equipment / maximum / note | 4 |
|---|---|
| number of electrical/optical connections / for gigabit Ethernet / maximum | 4 |
| number of electrical connections: for network components or terminal equipment | 4 |
| number of electrical connections: for power supply | 1 |
| number of electrical connections: for redundant voltage supply | 1 |
| type of electrical connection: for network components or terminal equipment | RJ45 socket |
| type of electrical connection: for power supply | 5-pole terminal block |
Show all 142 specifications ↓ Show less ↑130 more values in Identification, Memory, Interfaces / wireless, Signal inputs/outputs, Supply voltage, current consumption, power loss, Ambient conditions, Design, dimensions and weights, Radio frequencies, Product features, product functions, product components / general, Product functions / management, configuration, engineering, Product functions / diagnostics, Product functions / VLAN, Product functions / DHCP, Product functions / redundancy, Product functions / security, Product functions / time, Standards, specifications, approvals, Standards, specifications, approvals / hazardous environments, Standards, specifications, approvals / Environmental Product Declaration, Logistics.
Identification 10
| Part number | 6GK5763-1AL00-3AA0 |
|---|---|
| Type designation | WUM763-1 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4047622944721 |
| ETIM class | EC000816 |
| eCl@ss | 19170209 |
Memory 2
| design of the removable storage: CLP | Yes |
|---|---|
| design of the removable storage: CLP iFeatures | Yes |
Interfaces / wireless 6
| number of radio cards / permanently installed | 2 |
|---|---|
| transmission mode / for multiple input multiple output (MIMO) | 2x2 |
| number of spatial streams | 2 |
| number of electrical connections / for external antenna(s) | 2 |
| type of electrical connection / for external antenna(s) | R-SMA (socket) |
| product feature / external antenna can be mounted directly on device | Yes |
Signal inputs/outputs 2
| number of digital inputs | 0 |
|---|---|
| number of digital outputs | 0 |
Supply voltage, current consumption, power loss 11
| type of voltage / of the supply voltage | redundant power supply, 24 V DC, 5-pole terminal block |
|---|---|
| consumed current: at DC / at 24 V | 0.55 A |
| consumed current: at DC / at 24 V / typical | 0.33 A |
| consumed current: at DC / at 24 V / sleep mode / maximum | 0.013 A |
| power loss [W]: at DC / at 24 V | 13.2 W |
| power loss [W]: at DC / at 24 V / typical | 8 W |
| power loss [W]: at DC / at 24 V / sleep mode / maximum | 0.3 W |
| supply voltage / 1 / rated value | 24 V |
| type of voltage / 1 / of the supply voltage | DC |
| supply voltage / 2 / rated value | 24 V |
| type of voltage / 2 / of the supply voltage | DC |
Ambient conditions 5
| ambient temperature: during operation | -30 ... +60 °C |
|---|---|
| ambient temperature: during storage | -40 ... +85 °C |
| ambient temperature: during transport | -40 ... +85 °C |
| relative humidity / at 25 °C / without condensation / during operation / maximum | 90 % |
| protection class IP | IP30 |
Design, dimensions and weights 11
| width | 35 mm |
|---|---|
| height | 157 mm |
| depth | 137 mm |
| width / of the enclosure / without antenna | 35 mm |
| height / of the enclosure / without antenna | 152.5 mm |
| depth / of the enclosure / without antenna | 137 mm |
| fastening method | wall mounting, DIN rail, mounting rail S7-300, mounting rail S7-1500, with adapter: 90° installation on DIN rail |
| S7-300 rail mounting | Yes |
| S7-1500 rail mounting | Yes |
| 35 mm DIN-rail mounting | Yes |
| wall mounting | Yes |
Radio frequencies 2
| operating frequency: for WLAN in 2.4 GHz frequency band | 2.41 ... 2.48 GHz; depending on the country approvals |
|---|---|
| operating frequency: for WLAN in 5 GHz frequency band | 4.9 ... 5.8 GHz; depending on the country approvals |
Product features, product functions, product components / general 9
| product function / Access Point Mode | No |
|---|---|
| product function / client Mode | Yes |
| number of SSIDs | 1 |
| product function: iPCF Access Point | No; iPCF-2 is not compatible with iPCF. See documentation for function description. |
| product function: iPCF-2 access point | No; Only in combination with the 'SCALANCE CLP 2GB W700 AP iFeatures' or 'SCALANCE CLP 2GB W700 Client iFeatures' |
| product function: iPCF client | No |
| product function: iPCF-2 client | Yes; Only in combination with the 'SCALANCE CLP 2GB W700 AP iFeatures' or 'SCALANCE CLP 2GB W700 Client iFeatures' |
| product function: iPCF-MC Access Point | No |
| product function / iPRP | Yes |
Product functions / management, configuration, engineering 19
| number of manageable IP addresses / in client | 2 |
|---|---|
| product function: CLI | Yes |
| product function: web-based management | Yes |
| product function: MIB support | Yes |
| product function: TRAPs via email | Yes |
| product function: configuration with STEP 7 | Yes |
| product function: configuration with STEP 7 in the TIA Portal | Yes |
| product function: WDS | No |
| protocol / is supported: Address Resolution Protocol (ARP) | Yes |
| protocol / is supported: ICMP | Yes |
| protocol / is supported: Telnet | Yes |
| protocol / is supported: HTTP | Yes |
| protocol / is supported: HTTPS | Yes |
| protocol / is supported: TFTP | Yes |
| protocol / is supported: DCP | Yes |
| protocol / is supported: LLDP | Yes |
| identification & maintenance function: I&M0 - device-specific information | Yes |
| identification & maintenance function: I&M1 - higher level designation/location designation | Yes |
| product function / is supported / identification link | Yes; acc. to IEC 61406-1:2022 |
Product functions / diagnostics 5
| product function: PROFINET IO diagnosis | Yes |
|---|---|
| product function: SysLog | Yes |
| protocol / is supported: SNMP v1 | Yes |
| protocol / is supported: SNMP v2 | Yes |
| protocol / is supported: SNMP v3 | Yes |
Product functions / VLAN 2
| product function: function VLAN with IWLAN | Yes |
|---|---|
| number of VLANs / maximum | 24 |
Product functions / DHCP 1
| product function: DHCP client | Yes |
|---|
Product functions / redundancy 4
| protocol / is supported: STP/RSTP | Yes |
|---|---|
| protocol / is supported: MSTP | Yes |
| protocol / is supported: RSTP | Yes |
| product function: redundancy procedure MSTP | Yes |
Product functions / security 10
| product function: management security, ACL-IP based | No |
|---|---|
| product function: IEEE 802.1x (radius) | Yes |
| product function: NAT/NAPT | Yes |
| product function: access protection according to IEEE802.11i | Yes |
| product function: WPA/WPA2 | Yes |
| product function: WPA3 | Yes |
| product function: TKIP/AES | Yes |
| product function: RADIUS client | Yes |
| protocol / is supported: SSH | Yes |
| key length: with SSL | 4096 bit |
Product functions / time 3
| protocol / is supported: NTP | Yes |
|---|---|
| protocol / is supported: SNTP | Yes |
| protocol / is supported: SIMATIC time synchronization (SIMATIC Time) | Yes |
Standards, specifications, approvals 14
| certificate of suitability: EC Declaration of Conformity | Yes |
|---|---|
| certificate of suitability: CE marking | Yes |
| standard for wireless communication: IEEE 802.11a | Yes |
| standard for wireless communication: IEEE 802.11b | Yes |
| standard for wireless communication: IEEE 802.11e | Yes |
| standard for wireless communication: IEEE 802.11g | Yes |
| standard for wireless communication: IEEE 802.11h | Yes |
| standard for wireless communication: IEEE 802.11i | Yes |
| standard for wireless communication: IEEE 802.11n | Yes |
| standard for wireless communication: IEEE 802.11ac | Yes |
| standard for wireless communication: IEEE 802.11ax | Yes |
| standard for wireless communication: IEEE 802.11r | Yes |
| MTBF | 26 a |
| reference temperature | 40 °C |
Standards, specifications, approvals / hazardous environments 2
| standard / for hazardous zone | EN IEC 60079-0 : 2018, EN60079-7:2015 + A1 : 2018; II 3 G Ex ec IIC T4 Gc |
|---|---|
| from CSA and UL | UL121201, CAN/CSA C22.2 No.213, Cl. 1, div. 2, GP. A, B, C, D, T4 / Cl. 1, Zone 2, GP IIC T4, UL File E240480 |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 390.86 kg |
| global warming potential [CO2 eq]: during manufacturing | 29.7 kg |
| global warming potential [CO2 eq]: during operation | 361 kg |
| global warming potential [CO2 eq]: after end of life | 0.16 kg |
Logistics 7
| Net weight | 0.5 kg |
|---|---|
| Package dimensions | 137 × 35 × 157 mm |
| Country of origin | DE |
| Shipping weight | 1.0 kg |
| Ships from | Türkiye |
| Dispatch | 9 Nov |
| Stock | Critical stock |
Source: manufacturer data · Last verified: 31 Oct 2026
Documents
Documents for 6GK5763-1AL00-3AA0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- EC Declaration of Conformity
- CE marking
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11e
- IEEE 802.11g
- IEEE 802.11h
- IEEE 802.11i
- IEEE 802.11n
- IEEE 802.11ac
Quick answers
Questions about the WUM763-1
What is the rated current of WUM763-1?
The rated current of WUM763-1 is 0.55 A.
What is the HS code of WUM763-1 for customs?
The tariff (HS) code on file for WUM763-1 is 85176200.
What is the EAN of WUM763-1?
The EAN (GTIN) of WUM763-1 is 4047622944721.
Where does WUM763-1 ship from, and how fast?
WUM763-1 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
