Siemens 6GK5528-0AR00-2HR2 SCALANCE XR528-6M Layer 3 Managed Switch, Rear Ports

The Siemens SCALANCE XR528-6M (6GK5528-0AR00-2HR2) is a modular Layer 3 managed switch for the 19-inch rack, built around four 1000/10000 Mbit/s SFP+ uplinks and six slots for pluggable 4-port media modules covering electrical, electrical PoE, or optical connections. Rear-facing ports keep the front panel clear for cabinets where cabling enters from behind. It supports up to 180W of PoE budget across the populated modules.

Technical Specifications

Certifications & Standards

• CE
• KC
• RCM
• ATEX
• UKEX
• IECEx
• UL HazLoc
• CCC
• FM
• RoHS

Selection Notes

The 2HR2 variant routes ports through the rear of the enclosure, which matters in cabinets where the patch panel and cable duct sit behind the 19-inch frame - choose the front-port 2AR2 sibling if cabling enters from the front instead. With Layer 3 integrated (static and dynamic IPv4/IPv6 routing, OSPF, RIP, VRRP) this switch is suited as a distribution-layer node rather than a simple access switch, and the six media-module slots let the PoE/optical mix be configured per port group instead of being fixed at the factory.

Applications

The combination of Layer 3 routing, 10 Gbit/s SFP+ uplinks and PoE-capable media modules fits machine-room or plant-backbone deployments where PROFINET IO devices, IP cameras or wireless access points share the same distribution switch.
