Siemens 6GK5524-8GR00-2AR2 SCALANCE XR524-8C 24V DC 24+8 Port Layer 3 Ethernet Switch

The Siemens 6GK5524-8GR00-2AR2 SCALANCE XR524-8C is a 19-inch rack-mount managed Industrial Ethernet switch with integrated Layer 3 routing, powered from 24 V DC. It has 24x 10/100/1000 Mbit/s RJ45 ports plus 8 combo ports switchable to SFP, for up to 24 ports in use, with hot-swappable interface modules and redundancy protocols.

Technical Specifications

Certifications & Standards

• CE
• KC
• RCM
• ATEX
• UKEX
• IECEx
• ULhazloc
• CCC
• FM registration
• RoHS

Selection Notes

This 24 V DC variant has Layer 3 routing (RIPv2, OSPFv2, VRRP) built in with no KEY-PLUG needed, so it suits a control-room rack already run on 24 V DC that must route between PROFINET subnets from day one. Its 1 A max draw at 24 V DC is far lighter than the AC-fed 3AR2 and 4AR2 siblings, which matters when panel power budgets are tight. Pick the AC-powered 3AR2 or 4AR2 variant instead when the rack only has 230 V distribution, or the 8GS00-2AR2 sibling when routing can wait behind a KEY-PLUG XR-500 to defer that cost.
