3RV2The Siemens 3RV2925-5AB is a motor protection circuit breaker from the SENTRON/SIRIUS 3RV2 series. 3-phase supply terminal for 3-phase busbar connection from top Size S00/S0. Supplied by Stoklink for industrial and commercial low-voltage applications.
The Siemens 3RV2925-5AB is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 3RV2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.
| product brand name | SIRIUS |
|---|---|
| product category | Plugs, adapters and terminals |
| product designation | 3-phase supply terminal |
| design of the product | from above, size S0/S00 |
| product type designation | 3RV29 |
| certificate of suitability | CE / UL / CSA / CCC |
|---|---|
| size of the circuit-breaker | S00, S0 |
| insulation voltage with degree of pollution 3 at AC rated value | 690 V |
| protection class IP on the front according to IEC 60529 | IP20 |
| Substance Prohibitance (day/month/year) | 10/01/2009 |
| ampacity maximum | 63 A |
| ambient temperature: during operation | -20 ... +60 °C |
|---|---|
| ambient temperature: during storage | -50 ... +80 °C |
| Part number | 3RV2925-5AB |
|---|---|
| Type designation | 3RV29 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4011209718890 |
| ETIM class | EC002498 |
| eCl@ss | 27371392 |
| protection class IP on the front according to IEC 60529 | IP20 |
|---|---|
| touch protection on the front according to IEC 60529 | finger-safe, for vertical contact from the front |
| height | 39 mm |
|---|---|
| width | 45 mm |
| depth | 27 mm |
| type of electrical connection for main current circuit | screw-type terminals |
|---|---|
| for main contacts: solid | 1x (2.5 ... 16 mm2) |
| for main contacts: stranded | 1x (2.5 ... 25 mm2) |
| for main contacts: finely stranded with core end processing | 1x (2.5 ... 16 mm2) |
| for main contacts: for AWG cables for main contacts | 1x (10 ... 4) |
| connectable conductor cross-section for main contacts: solid or stranded | 2.5 ... 16 mm2 |
| connectable conductor cross-section for main contacts: stranded | 2.5 ... 25 mm2 |
| connectable conductor cross-section for main contacts: finely stranded with core end processing | 2.5 ... 16 mm2 |
| AWG number as coded connectable conductor cross section for main contacts | 10 ... 4 |
| Environmental Product Declaration: global warming potential [CO2 eq] / during manufacturing | 0.161 kg |
|---|
| Net weight | 0.045 kg |
|---|---|
| Package dimensions | 45 × 25 × 38 mm |
| Country of origin | DE |
| Shipping weight | 0.545 kg |
| Ships from | Türkiye |
| Dispatch | 11 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 31 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe EAN (GTIN) of 3RV29 is 4011209718890.
3RV29 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
