Harmony XPESchneider Electric XPEM510 Preventa XPE Foot Switch Metal Blue With Cover Trigger 1NO 1NC Control Station
Preventa XPE single foot switch, metal, blue, with cover and trigger mechanism, 1NO+1NC.
Description
About the XPEM
About the XPEM
The Schneider Electric XPEM510 is a Preventa XPE single foot switch with a blue metal housing, a protective cover, and a trigger mechanism requiring positive action to operate the pedal, wired 1 NC + 1 NO. Rated IP66, it suits bending, stamping and cutting machines where guarding against accidental activation is required.
Certifications & Standards
- IEC 60947-5-1
- FIMKO
- CSA
Selection Notes
The trigger mechanism forces a deliberate hand or heel action before the pedal can be depressed, which is the reason to specify this over the uncovered XPEM110 wherever accidental stepping could cause an unwanted machine cycle. For the same guarded function in orange rather than blue, the XPER510 is the equivalent.
Specification
Full specification
Main 10
| Range of product | Harmony XPE |
|---|---|
| Product or component type | Foot switch |
| Material | Metal |
| Foot switch type | Single foot switch |
| Device short name | XPEM |
| Provided equipment | Cover |
| Trigger mechanism | With trigger mechanism |
| Contact operation | 1 step |
| Contacts type and composition | 1 NC + 1 NO |
| Colour | Blue |
Complementary 11
| Positive opening | With conforming to IEC 60947-5-1 appendix K |
|---|---|
| Connections - terminals | Screw clamp terminal, <= 1 x 2.5 mm² with or without cable end, Screw clamp terminal, <= 2 x 1.5 mm² with or without cable end |
| cable entry | 2 entries tapped for Pg 16 cable gland |
| Mechanical durability | 15000000 cycles |
| [Ie] rated operational current | 3 A, 240 V, AC-15, A300, 0.27 A, 250 V, DC-13, Q300 conforming to IEC 60947-5-1 appendix A |
| [Ui] rated insulation voltage | 500 V (pollution degree 3) conforming to IEC 60947-1, 500 V (pollution degree 3) conforming to NF C 20-040 group C, 500 V (pollution degree 3) conforming to VDE 0110 group C, 300 V conforming to UL 508, 300 V conforming to CSA C22.2 No 14 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-1 |
| Maximum resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Short-circuit protection | 10 A cartridge fuse type gG conforming to IEC 60947-5-1, 10 A cartridge fuse type gG conforming to VDE 0660-200 |
| Rated operational power in W | 10 W DC-13, operating rate <60 cyc/mn, 5000000 cycles, 24 V, load factor: 0.5 conforming to IEC 60947-5-1 appendix C, 4 W DC-13, operating rate <60 cyc/mn, 5000000 cycles, 120 V, load factor: 0.5 conforming to IEC 60947-5-1 appendix C, 7 W DC-13, operating rate <60 cyc/mn, 5000000 cycles, 48 V, load factor: 0.5 conforming to IEC 60947-5-1 appendix C |
| Net weight | 2.57 kg |
Environment 9
| Standards | NF E 09-031 |
|---|---|
| Product certifications | CSA, FIMKO |
| Protective treatment | TC |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -40…70 °C |
| Vibration resistance | 15 gn (f= 10…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 150 gn conforming to NF E 09-031, 20 gn conforming to IEC 60068-2-27 |
| Overvoltage category | Class I conforming to IEC 61140, Class I conforming to NF C 20-030 |
| IP degree of protection | IP66 conforming to IEC 60529 |
Show all 54 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.
Identification 7
| Part number | XPEM510 |
|---|---|
| Type designation | XPEM |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 16
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 21.200 cm |
| Package 1 Width | 21.500 cm |
| Package 1 Length | 21.500 cm |
| Package 1 Weight | 2.649 kg |
| Unit Type of Package 2 | S06 |
| Number of Units in Package 2 | 30 |
| Package 2 Height | 75.000 cm |
| Package 2 Width | 60.000 cm |
| Package 2 Length | 80.000 cm |
| Package 2 Weight | 93.070 kg |
| Shipping weight | 2.57 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for XPEM510
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CSA
- NF E 09-031
Quick answers
Questions about the XPEM
What is the HS code of XPEM for customs?
The tariff (HS) code on file for XPEM is 853650.
Where does XPEM ship from, and how fast?
XPEM ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
