Schneider Electric XB5FVM4 Harmony XB5 Pilot Light Red 30 mm 24V DC/AC Universal LED Pilot Light

% $-17.84
Schneider Electric XB5FVM4 Harmony XB5 Red Pilot Light – 230...240 V AC Universal LED
Schneider Electric XB5FVM4 Harmony XB5 Red Pilot Light – 230...240 V AC Universal LED

Schneider Electric XB5FVM4 Harmony XB5 Pilot Light Red 30 mm 24V DC/AC Universal LED Pilot Light

Brand: Schneider Electric
Reference No: XB5FVM4
Catalog No: XB5FVM4
Series: Harmony XB5
Tariff Code (HS): 853661
Rated Voltage: 230...240 V AC
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$17.84

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric XB5FVM4 is a red pilot light from the Harmony XB5 range, flush-mounted in a 30.5 mm panel cutout with a plain lens and an integral universal LED rated for 230...240 V AC supply. Steady signalling, screw-clamp terminals and IP66/IP67/IP69/IP69K sealing make it suitable for washdown and dusty environments.

Technical Specifications

SKU / Reference XB5FVM4
Brand Schneider Electric
Range of Product Harmony XB5
Product Type Pilot light
Device Short Name XB5F
Bezel Material Dark grey plastic
Fixing Collar Material Plastic
Head Type Built-in-flush
Mounting Diameter 30.5 mm
Cap/Lens Colour Red
Operator Additional Information With plain lens
Light Source Universal LED (integral)
Signalling Type Steady
[Us] Rated Supply Voltage 230...240 V AC
Supply Voltage Limits 195…264 V AC
Current Consumption 14 mA
Service Life 100,000 h at rated voltage and 25 °C
[Ui] Rated Insulation Voltage 250 V
Dimensions (H x W x D) 42 mm x 36.6 mm x 55 mm
Net Weight 0.038 kg
IP Degree of Protection IP66 | IP67 | IP69 | IP69K
Enclosure Type UL type 4X/13

Certifications & Standards

  • UL Listed
  • CSA
  • IEC 60947-1
  • UL 508
  • JIS C8201-5-1
  • IEC 60947-5-1
  • ISO 21702
  • ISO 22196:2011

Selection Notes

At 18 mA (24 V) / 14 mA (230 V), the XB5FVM4 draws little enough current to run off the same control circuit as the contact it is monitoring, without a dedicated supply. Pick the 230...240 V AC variant to match the control transformer already in the cabinet — the red lens is a status colour choice only and does not change the electrical rating against the other colours in this series.

Technical Details

Short Description
Schneider Electric XB5FVM4, Harmony XB5 red pilot light, universal LED, 230...240 V AC.
Rated Voltage (VAC)
230...240 V AC
Mounting Type
Panel flush mount, 30.5 mm cutout
Protection Type
IP66/IP67/IP69/IP69K
Catalog No
XB5FVM4
Delivery Date (Days)
30 days
Model Number
XB5F
Tariff Code
853661
