Harmony XALKSchneider Electric XALK01 Harmony XALK Empty Control Station Yellow Lid 1 Cut-out 22 mm Control Station
Harmony XALK empty control station, yellow lid, 1 cut-out, IP66/IP67/IP69/IP69K.
Description
About the XALK
About the XALK
The Schneider Electric XALK01 is an empty Harmony XALK control station enclosure with 1 cut-out and a yellow cover over a light grey base, intended for emergency stop or emergency switching off functions. Molded in polycarbonate and rated IP66/IP67/IP69/IP69K, it accepts Harmony XB5 22 mm push buttons, switches and pilot lights for customer assembly.
Certifications & Standards
- IEC 60947-5-1
- IEC 60947-5-4
- IEC 60947-5-5
- UL 508
- CSA C22.2 No 14
- JIS C8201-1
- JIS C8201-5-1
Selection Notes
Sold without an operator unit, this enclosure is the base for building a custom emergency-stop station from separately ordered XB5 mushroom buttons and contact blocks. For a factory-assembled equivalent that arrives ready to wire, the complete XALK178 series covers the same yellow IP69K housing with the mushroom head already fitted.
Specification
Full specification
Main 11
| Range of Product | Harmony XALK |
|---|---|
| Product or Component Type | Empty control station |
| Device short name | XALK |
| Product destination | For XB5 Ø 22 mm control and signalling units |
| Control station application | Emergency stop function, Emergency switching off function |
| Number of cut-out | 1 cut-out |
| Colour of base of enclosure | Light grey RAL 7035) |
| Colour of cover | Yellow RAL 1021) |
| Material | Polycarbonate |
| Cable entry | 1 knock-out for cable entry 0.6 in (14 mm), 2 knock-outs for Pg 13 cable gland and ISO M20 0.5 in (12 mm) |
| IP degree of protection | IP66 IEC 60529, IP67, IP69, IP69K |
Complementary 9
| Assembly style | For customer assembly |
|---|---|
| Number of horizontal rows | 1 |
| Number of vertical rows | 1 |
| Net Weight | 0.300 lb(US) (0.136 kg) |
| Resistance to high pressure washer | 1015.3 psi (7000000 Pa) 131 °F (55 °C) 0.1 m |
| Mounting of block | Front mounting, Rear mounting |
| electrical composition code | SR1, SF1, MR1, MF1 |
| Main group | 1 cut-out |
| Group of product | Standard yellow |
Environment 7
| Protective treatment | TH |
|---|---|
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -40…158 °F (-40…70 °C) |
| Overvoltage category | Class II conforming to IEC 60536 |
| NEMA degree of protection | NEMA 13, NEMA 4X |
| IK degree of protection | IK03 conforming to IEC 62262 |
| Standards | IEC 60947-5-5, UL 508, IEC 60947-5-4, JIS C8201-5-1, CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, JIS C8201-1 |
Show all 58 specifications ↓ Show less ↑31 more values in Identification, Contractual warranty, Logistics.
Identification 8
| Part number | XALK01 |
|---|---|
| Type designation | XALK |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3389110115826 |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 22
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 2.677 in (6.800 cm) |
| Package 1 Width | 2.953 in (7.500 cm) |
| Package 1 Length | 2.677 in (6.800 cm) |
| Package weight(Lbs) | 4.021 oz (114.000 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 60 |
| Package 2 Height | 11.811 in (30.000 cm) |
| Package 2 Width | 11.811 in (30.000 cm) |
| Package 2 Length | 15.748 in (40.000 cm) |
| Package 2 Weight | 16.111 lb(US) (7.308 kg) |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 480 |
| Package 3 Height | 29.528 in (75.000 cm) |
| Package 3 Width | 23.622 in (60.000 cm) |
| Package 3 Length | 31.496 in (80.000 cm) |
| Package 3 Weight | 162.534 lb(US) (73.724 kg) |
| Shipping weight | 0.136 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for XALK01
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- IEC 60947-5-5
- UL 508
- IEC 60947-5-4
- JIS C8201-5-1
- CSA C22.2 No 14
- IEC 60947-1
- IEC 60947-5-1
- JIS C8201-1
Quick answers
Questions about the XALK
What is the HS code of XALK for customs?
The tariff (HS) code on file for XALK is 853650.
What is the EAN of XALK?
The EAN (GTIN) of XALK is 3389110115826.
Where does XALK ship from, and how fast?
XALK ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
