- Part number
- MCSESM123F2LG0
Description
About the MCSESM123F2LG0
About the MCSESM123F2LG0
The Schneider Electric MCSESM123F2LG0 is a Modicon Networking managed Ethernet switch pairing 8 copper 10/100BASE-TX ports with 4 Gigabit SFP fiber ports for high-bandwidth uplinks. It runs Ethernet TCP/IP with SNMP, HTTPS, Modbus TCP and OPC UA management, supports RSTP, MRP and HiPER Ring redundancy, and draws 9 W from a 12...24 V DC supply (plus 1 W per active SFP port) on a 35 mm DIN rail.
Certifications & Standards
- CE
- UL
- RCM
- DNV
- ATEX
- EAC
- UKCA
- CSA C22.2 No. 213
- UKEX
- FCC Part 15 Class A
- CCC Ex
- UL 61010-2-201
- EN/IEC 61131-2
- IEC 61850-3
- IEC 62443-4-2
- EN 50121-4
Selection Notes
The MCSESM123F2LG0 is the Gigabit SFP variant of the Modicon Networking managed switch line — choose it over the 100 Mbps duplex-SC fiber variants (053/063/093/103 families) when the application needs Gigabit uplinks or the flexibility to fit copper or fiber SFP transceivers matched to the run. 4 SFP cages give more uplink or ring ports than the fixed 1–2 fiber ports on the other managed switches, at the cost of an extra 1 W per populated SFP port.
Specification
Full specification
Main 6
| Range of Product | Modicon Networking |
|---|---|
| Product or Component Type | Ethernet TCP/IP managed switch |
| Communication Port Protocol | Ethernet TCP/IP, SSH, HTTP, HTTPS, SNMP, SFTP, SCP, LLDP, Telnet, SNTP, Modbus TCP, OPC UA, IEC 61850 MMS Server |
| Port Ethernet | 10/100BASE-TX - 8 copper cable, 100/1000 SFP - 4 |
| Maximum number of switches in cascade | Unlimited |
| Cybersecurity | Port hardening, IP-based port security, MAC-based port security, Port-based access control, Role-based access control, RADIUS assignment, HTTPS, DoS prevention, VLAN-based ACL, Audit trail, SNMP logging, Pre-login banner, TACACS+ |
Complementary 24
| Integrated connection type | Shielded RJ45 copper cable, SFP port fiber optic (Gbit) |
|---|---|
| Transmission support medium | Twisted shielded pairs cable CAT 5E copper cable, Fiber optic cable fiber optic (Gbit) |
| Maximum cable distance between devices | 328.08 ft (100 m) copper cable |
| Ethernet service | Configuration via web server, VLAN, Multicast filtering, Data stream control, IGMP Snooping, SNMP-Traps and SYSLOG |
| Communication Service | TFTP, Quality of Service (QoS), Port monitoring, Port mirroring, Address conflict detection |
| Diagnostics run time | Signal contact, Self test, MAC notification, RSPAN, SFLOW |
| Maximum number of switches in a ring | 50 |
| Redundancy | HiPER ring, RSTP, Link aggregation, Link backup, Redundant network coupling, MRP, Redundant coupling protocol, MSTP |
| [Us] rated supply voltage | 12...24 V |
| Supply voltage limits | 9.6…32 V DC SELV |
| Power Consumption in W | 9 W |
| Electrical connection | Removable connector 6 ways power supply |
| Mounting Support | 35 mm symmetrical DIN rail |
| Marking | CE, CULus, RCM |
| Function Available | Security status, Alarms (Traps), System information, Report |
| Local signalling | 1 dual colour LED (green/yellow) for P1 P2 power supplies, 1 dual colour LED (green/red) for device status, 1 dual colour LED (green/yellow) for memory key status, 1 dual colour LED (green/yellow) for channel diagnostic |
| Alarm output | 1 voltfree contact 1 A |
| Alarm function | Power supply fault, Data link status, Switch fault, Temperature threshold, Redundancy ring fault, Incorrect configuration, External memory removed |
| Ethernet cabling system | TF switches |
| MTBF reliability | 4326692 H |
| Width | 2.9 in (73 mm) |
| Height | 5.6 in (142.8 mm) |
| Depth | 4.6 in (117.6 mm) |
| Net Weight | 1.26 lb(US) (0.57 kg) |
Environment 6
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
|---|---|
| Relative Humidity | 1…95 % non-condensing |
| IP Degree of Protection | IP30 |
| Directives | 2014/35/EU - low voltage directive, 2014/30/EU - electromagnetic compatibility |
| Standards | UL 61010-2-201, EN/IEC 61131-2, IEC 61850-3, IEC 62443-4-2, EN 50121-4 |
| Product certifications | CE, UL, RCM, DNV, ATEX, EAC, UKCA, CSA C22-2 No 213, UKEX, FCC part 15 class A, CCC Ex |
Show all 49 specifications ↓ Show less ↑13 more values in Identification, Contractual warranty, Logistics.
Identification 7
| Part number | MCSESM123F2LG0 |
|---|---|
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3606481463449 |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 5
| Country of origin | DE |
|---|---|
| Shipping weight | 0.57 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for MCSESM123F2LG0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- UL
- CSA
- CE
- UKCA
- CCC
- EAC
- UL 61010-2-201
- EN/IEC 61131-2
- IEC 61850-3
- IEC 62443-4-2
- EN 50121-4
Quick answers
Questions about the MCSESM123F2LG0
What is the HS code of MCSESM123F2LG0 for customs?
The tariff (HS) code on file for MCSESM123F2LG0 is 851762.
What is the EAN of MCSESM123F2LG0?
The EAN (GTIN) of MCSESM123F2LG0 is 3606481463449.
Where does MCSESM123F2LG0 ship from, and how fast?
MCSESM123F2LG0 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
