Schneider Electric LUALB1 TeSys U Current Limiter Disconnector 32 A 130 kA Motor Starter Module

% $-214.94
Schneider Electric LUALB1 TeSys U current limiter disconnector - 32 A
Schneider Electric LUALB1 TeSys U current limiter disconnector - 32 A

Schneider Electric LUALB1 TeSys U Current Limiter Disconnector 32 A 130 kA Motor Starter Module

Brand: Schneider Electric
Reference No: LUALB1
Catalog No: LUALB1
Series: TeSys Ultra
Tariff Code (HS): 853650
Rated Current: 32 A
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$214.94

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric LUALB1 is a TeSys U current limiter disconnector rated 32 A, mounted directly on the upstream terminals of a TeSys U power base. It raises the starter controller's short-circuit withstand from 50 kA to 130 kA at 400 V by activating at a 50 kA threshold, ahead of a LUB or LU2B power base.

Technical Specifications

Reference LUALB1
Brand Schneider Electric
Range TeSys
Range of Product TeSys Ultra
GTIN 785901291817
Device Short Name LUA
Product or Component Type Limiter disconnector
Product Compatibility Power base LUB, LU2B
Conventional Free Air Thermal Current (Ith) 32 A
Activation Threshold 50 kA
Breaking Capacity 70 kA at 690 V, 130 kA at ≤ 440 V
Rated Insulation Voltage (Ui) 690 V
Mounting Mode Direct
Tightening Torque 1.9-2.5 N.m, flat or Philips No 2 screwdriver
Net Weight 0.31 kg
Country of Origin Mexico

Selection Notes

Fitting the LUALB1 ahead of a power base lifts the assembly's short-circuit rating from the base's own 50 kA to 130 kA at up to 440 V (70 kA at 690 V), which matters when the starter sits on a feeder with higher prospective fault current than the bare base can withstand alone. It includes its own limiter cartridge LUALF1 and connects upstream of exactly one power base - it cannot be shared between two starter controllers.

Technical Details

Short Description
TeSys U current limiter disconnector, 32 A, 130 kA at 440 V, 70 kA at 690 V
Rated Current (Ampere)
32 A
Mounting Type
Direct, upstream of power base
Catalog No
LUALB1
Delivery Date (Days)
30 days
Model Number
LUA
Tariff Code
853650
