Part number
LTMTPBD
Model no
LTMT
$688.03 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric LTMTPBD TeSys Tera Profibus DP 24 V DC Motor Controller Motor Starter Module

TeSys Tera main controller, Profibus DP, 24 V DC supply, motor protection and monitoring

Communication
Profibus DP
EAN
3606482184725
Description

About the LTMT

The Schneider Electric LTMTPBD is a TeSys Tera main motor management controller communicating over Profibus DP, powered at 24 V DC, providing full protection, control and monitoring of single-phase and three-phase AC induction motors when paired with a TeSys Tera sensor module and a contactor.

Certifications & Standards

  • UL
  • IEC
  • cUL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1

Selection Notes

The PBD is the Profibus DP variant on a 24 V DC supply; choose the PFM sibling instead for a 100-240 V AC/DC supply, or the EBD/EFM/MBD variants for Ethernet TCP/IP or Modbus RTU networks.

Specification

Full specification

58 values · Last verified 30 Oct 2026

Main 10

Range TeSys
Product name TeSys Tera
Device short name LTMT
Product or Component Type Motor controller
Device Application Equipment monitoring and control
[Us] rated supply voltage 24 V DC
Current Consumption 56...127 mA
Supply voltage limits 18…30 V DC
Communication Port Protocol Profibus DP
Bus type Profibus DP 2-wire RS 485 1...125 9.6 kbit/s...12 Mbit/s, SUB-D 9 2 shielded twisted pairs, Profibus DP 2-wire RS 485 1...125 1.5 Mbit/s, terminal block 2 shielded twisted pairs

Complementary 26

[Ui] rated insulation voltage 24 V DC IEC 60185
Short-circuit withstand 100 kA
Pollution degree 3
Overvoltage category III
[Uimp] rated impulse withstand voltage 0.8 kV
Associated fuse rating 0.5 A gG control circuit
Protection Type Overload protection, Stalled rotor, Locked rotor, Short-circuit, Undercurrent, Overcurrent, Current unbalance, Phase reversal, Phase loss, Earth fault protection internal, Earth fault protection external, Excessive starting time, Max number of start, Undervoltage, Overvoltage, Voltage unbalance, Underfrequency, Overfrequency, Reacceleration, Temperature protection, Analog input protection, Communication failure, Fail to stop, Under power, Over power, Power factor variation, Anti-backspin timer, Block output, DI interlock protection
Network and machine diagnosis type Motor statistics, Motor status, Event recording, Running hours counter/operating time, Number of starts and stops, Running hours /stop hours counter, Start curve showing motor start record, Pre-alarms, Trip history information, Alarm counters
Logic input number 4
Input current 2.5 mA 24 V
Current state 0 guaranteed Digital input 0...12 V 5 mA 10 ms
Current state 1 guaranteed Digital input 18...30 V 5 mA 10 ms
maximum output switching frequency 2 Hz
Load current 10 A 250 V AC/DC, 5 A 30 V DC
Permissible power 480 VA AC-15), Ie = 2 A, 500000 cycles output), 30 W DC-13), Ie = 1.25 A, 500000 cycles output)
maximum operating rate 1800 cyc/h
Contacts type and composition 2 NO fault signal, 1 NO + 1 NC fault signal
Metering type Thermal memory, Line, phase and average current, Line to line and average voltage, Motor temperature input, Ground fault current Ig, Active and reactive power, Active and reactive energy, Frequency, Total voltage harmonic distortion THD (V), Total voltage harmonic distortion THD (U), Total current harmonic distortion THD (I), Phase sequence
Measurement accuracy 1 % current 0.3...3 A), 1 % current 2.5...25 A), 3 % current 7...70 A), 3 % current 10...100 A), 1 % voltage 110...690 V), +/- 2.5 % earth fault current external measurement, +/- 3...5 % earth fault current internal measurement current > 0.03 A in the 0.3...3 A range), +/- 3...5 % earth fault current internal measurement current > 0.25 A in the 2.5...25 A range), +/- 3...5 % earth fault current internal measurement current > 0.7 A in the 7...70 A range), +/- 3...5 % earth fault current internal measurement current > 1 A in the 10...100 A range), +/- 2 % Temperature, +/- 2 % THD measurement, +/- 3...6 % power factor, +/- 2...5 % active and reactive energy, +/- 30 min/year internal clock
Connection pitch 0.3 in (7.5 mm) for supply voltage, 0.2 in (5.0 mm) for others
Connections - terminals Control circuit connector 1 0.0003…0.004 in² (0.2…2.5 mm²) 24 AWG...14 AWG)flexible without cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1.5 mm²) 24 AWG...14 AWG)flexible without cable end, Control circuit connector 1 0.0004…0.004 in² (0.25…2.5 mm²) 24 AWG...14 AWG)flexible with ferrule with cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1.5 mm²) 24 AWG...14 AWG)flexible with ferrule with cable end, Control circuit connector 1 0.0004…0.004 in² (0.25…2.5 mm²) 24 AWG...14 AWG)flexible stranded with cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1.5 mm²) 24 AWG...14 AWG)flexible stranded with cable end, Control circuit connector 1 0.0003…0.004 in² (0.2…2.5 mm²) 24 AWG...14 AWG)solid with cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1 mm²) 24 AWG...14 AWG)solid with cable end
Tightening torque Control circuit 4.4 lbf.in (0.5 N.m) flat 0.1 in (3 mm)
Width 4.4 in (112 mm)
Height 1.8 in (45 mm)
Depth 3.5 in (90 mm)
Web services Web server

Environment 8

Standards EN/IEC 60947-4-1, UL/CSA 60947-4-1
Product Certifications UL, IEC, cUL
Fire resistance 1202 °F (650 °C) IEC 60947-1, 1760 °F (960 °C) UL 94
Ambient air temperature for operation -4…158 °F (-20…70 °C)
Ambient Air Temperature for Storage -40…176 °F (-40…80 °C)
Operating altitude <= 6561.68 ft (2000 m) without derating
Mechanical robustness Vibrations mounted on symmetrical rail1 Gn, 5...300 Hz EN/IEC 60068-2-27, Vibrations plate mounted4 Gn, 5...300 Hz EN/IEC 60068-2-6, Shocks half sine wave acceleration15 Gn for 11 ms EN/IEC 60068-2-27
IP Degree of Protection IP20
Show all 58 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.

Identification 8

Part number LTMTPBD
Type designation LTMT
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3606482184725

Contractual warranty 1

Warranty (in months) 18

Logistics 5

Country of origin IN
Shipping weight 0.296 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for LTMTPBD

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1
