Part number
LTMTEFM
Model no
LTMT
$890.59 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric LTMTEFM TeSys Tera Ethernet TCP/IP 100-240 V AC/DC Motor Controller Motor Starter Module

TeSys Tera main controller, Ethernet TCP/IP, 100-240 V AC/DC supply, motor protection and monitoring

Rated operational voltage
100–240–DC V DC
Communication
Ethernet TCP/IP
EAN
3606482184770
Description

About the LTMT

The Schneider Electric LTMTEFM is a TeSys Tera main motor management controller communicating over Ethernet TCP/IP, powered at 100-240 V AC/DC, providing full protection, control and monitoring of single-phase and three-phase AC induction motors when paired with a TeSys Tera sensor module and a contactor.

Certifications & Standards

  • UL
  • IEC
  • cUL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1

Selection Notes

The EFM is the Ethernet TCP/IP variant on a wide 100-240 V AC/DC supply; choose the EBD sibling instead where a 24 V DC control supply is already available, or the MBD/PBD/PFM variants for Modbus RTU or Profibus DP networks.

Specification

Full specification

57 values · Last verified 30 Oct 2026

Main 10

Range TeSys
Product name TeSys Tera
Device short name LTMT
Product or Component Type Motor controller
Device Application Equipment monitoring and control
[Us] rated supply voltage 100...240 V AC/DC 50/60 Hz
Current Consumption 8...62.8 mA
Supply voltage limits 85…265 V AC/DC
Communication Port Protocol Ethernet TCP/IP
Bus type Ethernet IEEE 802.3 0...159 10...100 Mbit/s, 2xRJ45 4 shielding pairs cable

Complementary 25

[Ui] rated insulation voltage 690 V AC IEC 60185
Short-circuit withstand 100 kA
Pollution degree 3
Overvoltage category III
[Uimp] rated impulse withstand voltage 4 kV
Associated fuse rating 0.5 A gG control circuit
Protection Type Overload protection, Stalled rotor, Locked rotor, Short-circuit, Undercurrent, Overcurrent, Current unbalance, Phase reversal, Phase loss, Earth fault protection internal, Earth fault protection external, Excessive starting time, Max number of start, Undervoltage, Overvoltage, Voltage unbalance, Underfrequency, Overfrequency, Reacceleration, Temperature protection, Analog input protection, Communication failure, Fail to stop, Under power, Over power, Power factor variation, Anti-backspin timer, Block output, DI interlock protection
Network and machine diagnosis type Motor statistics, Motor status, Event recording, Running hours counter/operating time, Number of starts and stops, Running hours /stop hours counter, Start curve showing motor start record, Pre-alarms, Trip history information, Alarm counters
Logic input number 4
Input current 3 mA 100...240 V
Current state 0 guaranteed Digital input 0...12 V 5 mA 10 ms
Current state 1 guaranteed Digital input 85...265 V 5 mA 10 ms
maximum output switching frequency 2 Hz
Load current 10 A 250 V AC/DC, 5 A 30 V DC
Permissible power 480 VA AC-15), Ie = 2 A, 500000 cycles output), 30 W DC-13), Ie = 1.25 A, 500000 cycles output)
maximum operating rate 1800 cyc/h
Contacts type and composition 2 NO fault signal, 1 NO + 1 NC fault signal
Metering type Thermal memory, Line, phase and average current, Line to line and average voltage, Motor temperature input, Ground fault current Ig, Active and reactive power, Active and reactive energy, Frequency, Total voltage harmonic distortion THD (V), Total voltage harmonic distortion THD (U), Total current harmonic distortion THD (I), Phase sequence
Measurement accuracy 1 % current 0.3...3 A), 1 % current 2.5...25 A), 3 % current 7...70 A), 3 % current 10...100 A), 1 % voltage 110...690 V), +/- 2.5 % earth fault current external measurement, +/- 3...5 % earth fault current internal measurement current > 0.03 A in the 0.3...3 A range), +/- 3...5 % earth fault current internal measurement current > 0.25 A in the 2.5...25 A range), +/- 3...5 % earth fault current internal measurement current > 0.7 A in the 7...70 A range), +/- 3...5 % earth fault current internal measurement current > 1 A in the 10...100 A range), +/- 2 % Temperature, +/- 2 % THD measurement, +/- 3...6 % power factor, +/- 2...5 % active and reactive energy, +/- 30 min/year internal clock
Connection pitch 0.3 in (7.5 mm) for supply voltage, 0.2 in (5.0 mm) for others
Connections - terminals Control circuit connector 1 0.0003…0.004 in² (0.2…2.5 mm²) 24 AWG...14 AWG)flexible without cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1.5 mm²) 24 AWG...14 AWG)flexible without cable end, Control circuit connector 1 0.0004…0.004 in² (0.25…2.5 mm²) 24 AWG...14 AWG)flexible with ferrule with cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1.5 mm²) 24 AWG...14 AWG)flexible with ferrule with cable end, Control circuit connector 1 0.0004…0.004 in² (0.25…2.5 mm²) 24 AWG...14 AWG)flexible stranded with cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1.5 mm²) 24 AWG...14 AWG)flexible stranded with cable end, Control circuit connector 1 0.0003…0.004 in² (0.2…2.5 mm²) 24 AWG...14 AWG)solid with cable end, Control circuit connector 2 0.0003…0.002 in² (0.2…1 mm²) 24 AWG...14 AWG)solid with cable end
Width 4.4 in (112 mm)
Height 1.8 in (45 mm)
Depth 3.5 in (90 mm)
Web services Web server

Environment 8

Standards EN/IEC 60947-4-1, UL/CSA 60947-4-1
Product Certifications UL, IEC, cUL
Fire resistance 1202 °F (650 °C) IEC 60947-1, 1760 °F (960 °C) UL 94
Ambient air temperature for operation -4…158 °F (-20…70 °C)
Ambient Air Temperature for Storage -40…176 °F (-40…80 °C)
Operating altitude <= 6561.68 ft (2000 m) without derating
Mechanical robustness Vibrations mounted on symmetrical rail1 Gn, 5...300 Hz EN/IEC 60068-2-27, Vibrations plate mounted4 Gn, 5...300 Hz EN/IEC 60068-2-6, Shocks half sine wave acceleration15 Gn for 11 ms EN/IEC 60068-2-27
IP Degree of Protection IP20
Show all 57 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.

Identification 8

Part number LTMTEFM
Type designation LTMT
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3606482184770

Contractual warranty 1

Warranty (in months) 18

Logistics 5

Country of origin IN
Shipping weight 0.302 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for LTMTEFM

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1
Quick answers

Questions about the LTMT

Which supply voltage is LTMT rated for?

The rated operational voltage of LTMT is 100–240–DC V DC.

What is the HS code of LTMT for customs?

The tariff (HS) code on file for LTMT is 853650.

What is the EAN of LTMT?

The EAN (GTIN) of LTMT is 3606482184770.

Where does LTMT ship from, and how fast?

LTMT ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
