Part number
LTMTCTV3T
Model no
LTMT
$235.11 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric LTMTCTV3T TeSys Tera CTVT Horizontal 0.3-3 A Sensor Module Automation Component

TeSys Tera CTVT sensor module, 0.3-3 A, horizontal mount, 690 V insulation

Range
TeSys
Product name
TeSys Tera
Device short name
LTMT
Product or component type
Sensor
Device application
Motor protection
Description

About the LTMT

The Schneider Electric LTMTCTV3T is a TeSys Tera horizontal-mount sensor module measuring 0.3-3 A current and phase-to-phase voltage for a TeSys Tera motor management system, with a 100 kA short-circuit withstand rating and an integral input for ground-fault CT.

Certifications & Standards

  • IEC
  • UL
  • cUL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1

Selection Notes

Match the sensor's 0.3-3 A current range to the motor's full-load current rather than to the frame size of the breaker or contactor ahead of it; choose a CTV-coded module over the plain CT when the application also needs phase voltage, undervoltage/overvoltage or power-factor monitoring from the TeSys Tera controller.

Specification

Full specification

55 values · Last verified 30 Oct 2026

Main 5

Range TeSys
Product name TeSys Tera
Device short name LTMT
Product or component type Sensor
Device application Motor protection

Complementary 18

[Ui] rated insulation voltage 690 V conforming to EN/IEC 60947-1
Overvoltage category III
Pollution degree 3
[In] rated current 0.3…3 A at 60...690 V, AC 45...65 Hz
[Uimp] rated impulse withstand voltage 6 kV current or voltage measurement circuit
Protection type Overload protection, Stalled rotor, Locked rotor, Short-circuit, Undercurrent, Overcurrent, Current unbalance, Phase reversal, Phase loss, Earth fault protection internal, Earth fault protection external, Excessive starting time, Max number of start, Undervoltage, Overvoltage, Voltage unbalance, Underfrequency, Overfrequency, Reacceleration, Communication failure, Fail to stop, Under power, Over power, Power factor variation, Anti-backspin timer, Block output
Short-circuit withstand 100 kA conforming to EN/IEC 60947-4-1
Measurement accuracy +/- 1 % voltage, +/- 1 % current
Mounting mode Horizontal
Connection pitch 5.0 mm
Connections - terminals Voltage circuit: connector0.2…2.5 mm² (12 AWG...24 AWG)
Input type Analog
Sensor type Current sensor, Voltage sensor
Electromagnetic compatibility Immunity to radiated electromagnetic interference (in open air), level 3, 10 Vrms, conforming to EN/IEC 61000-4-3, Resistance to electrostatic discharge (in open air), level 3, 8 kV, conforming to EN/IEC 61000-4-2, Digital output: resistance to electrostatic discharge (on contact), level 3, 6 kV, conforming to EN/IEC 61000-4-2, Digital output: immunity to shock waves (common mode), 4 kV, conforming to EN/IEC 61000-4-5, 24 V DC sensors: immunity to shock waves (common mode), 1 kV, conforming to EN/IEC 61000-4-5, 100...240 V inputs: immunity to shock waves (common mode), 2 kV, conforming to EN/IEC 61000-4-5, Communication: immunity to shock waves (common mode), 2 kV, conforming to EN/IEC 61000-4-5, Temperature sensor: immunity to shock waves (common mode), 1 kV, conforming to EN/IEC 61000-4-5, Digital output: immunity to shock waves (serial mode), 2 kV, conforming to EN/IEC 61000-4-5, 24 V DC sensors: immunity to shock waves (serial mode), level 3, 1 kV, conforming to EN/IEC 61000-4-5, 100...240 V inputs: immunity to shock waves (serial mode), 1 kV, conforming to EN/IEC 61000-4-5, Temperature sensor: immunity to shock waves (serial mode), 0.5 kV, conforming to EN/IEC 61000-4-5, Immunity to radiated radio-electrical interference, level 3, 10 Vrms, conforming to EN/IEC 61000-4-6
Depth 60.5 mm
Height 74.7 mm
Width 110.3 mm
Tightening torque Control circuit: 0.5 N.m - with screwdriver flat 3 mm

Environment 8

Product certifications IEC, UL, cUL
Standards EN/IEC 60947-4-1, UL/CSA 60947-4-1
Fire resistance 650 °C conforming to EN/IEC 60695-2-12, 960 °C conforming to UL 94
Protective treatment 12 x 24 hour cycles conforming to EN/IEC 60068-2-30
Ambient air temperature for storage -40…80 °C
Operating altitude <= 2000 m without derating
Mechanical robustness Shocks half sine wave acceleration: 15 Gn for 11 ms conforming to EN/IEC 60068-2-27, Vibrations mounted on symmetrical rail: 1 Gn, 5...300 Hz conforming to EN/IEC 60068-2-6, Vibrations plate mounted: 4 Gn, 5...300 Hz conforming to EN/IEC 60068-2-6
Ambient air temperature for operation -20…70 °C
Show all 55 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.

Identification 7

Part number LTMTCTV3T
Type designation LTMT
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 16

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 7.000 cm
Package 1 Width 9.000 cm
Package 1 Length 14.000 cm
Package 1 Weight 339.000 g
Unit Type of Package 2 S01
Number of Units in Package 2 2
Package 2 Height 15.000 cm
Package 2 Width 15.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 930.000 g
Shipping weight 0.339 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for LTMTCTV3T

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1
Quick answers

Questions about the LTMT

What is the HS code of LTMT for customs?

The tariff (HS) code on file for LTMT is 853890.

Where does LTMT ship from, and how fast?

LTMT ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
