The Schneider Electric LE1M35Q706 is a TeSys LE enclosed direct-on-line starter with a built-in LC1K contactor and LR2K thermal overload relay, pre-wired for 0.37 kW motors at 400 V with a thermal setting range of 0.8-1.2 A and a 380 V AC control circuit. A yellow operating LED gives local run status, and the compact enclosure suits small fractional-kW motors.
The Q706 is the 380 V AC control-voltage variant for a 0.37 kW motor — select it where the control supply is 380 V rather than 415 V or 240 V, matching the N- and U-coded siblings only in enclosure and current range, not coil voltage.
| Range | TeSys |
|---|---|
| Product name | TeSys LE |
| Device short name | LE1M |
| Product or Component Type | Enclosed DOL starter |
| Device Application | Standard |
| Utilisation category | AC-3 |
| Device composition | Contactor, Earth terminal, Neutral terminal, Thermal overload relay |
| Thermal protection adjustment range | 0.8…1.2 A |
| Motor power kW | 0.18 kW 240 V AC 50/60 Hz, 0.37 kW 415 V AC 50/60 Hz, 0.18 kW 220/230 V AC 50/60 Hz, 0.37 kW 380/400 V AC 50/60 Hz |
| [Uc] control circuit voltage | 380 V AC 50/60 Hz |
| Control type | Push-button start Green I, Push-button stop/reset Red O |
| Local signalling | Operating LED Yellow) |
|---|---|
| Cable entry number | 2 ISO20 top, 2 ISO25 top, 2 Pg 13 top, 2 Pg 21 top, 2 ISO20 bottom, 2 ISO25 bottom, 2 Pg 13 bottom, 2 Pg 21 bottom, 2 Pg 16 top, 2 Pg 16 bottom |
| Width | 3.07 in (78 mm) |
| Height | 6.3 in (160 mm) |
| Depth | 4.3 in (108 mm) |
| Net Weight | 1.3 lb(US) (0.6 kg) |
| Material | ABS (acrylonitrile butadiene-styrene) |
|---|---|
| IP degree of protection | IP65 IEC 60529 |
| Standards | IEC 60947-4-1 |
| Ambient air temperature for operation | 23…104 °F (-5…40 °C) |
| Environmental characteristic | Standard environment |
| Product Certifications | UKCA |
| Part number | LE1M35Q706 |
|---|---|
| Type designation | LE1M |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3389110765731 |
| Warranty (in months) | 18 |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 3.150 in (8.000 cm) |
| Package 1 Width | 4.528 in (11.500 cm) |
| Package 1 Length | 6.496 in (16.500 cm) |
| Package weight(Lbs) | 20.282 oz (575.000 g) |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 5.906 in (15.000 cm) |
| Package 2 Width | 11.811 in (30.000 cm) |
| Package 2 Length | 15.748 in (40.000 cm) |
| Package 2 Weight | 8.142 lb(US) (3.693 kg) |
| Shipping weight | 0.6 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe rated current of LE1M is 1.2 A.
The rated operational voltage of LE1M is 380 V AC.
The rated motor power of LE1M is 0.37 kW.
The tariff (HS) code on file for LE1M is 853710.
The EAN (GTIN) of LE1M is 3389110765731.
LE1M ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
