Schneider Electric LAD4RCE TeSys Deca RC Suppressor Module 24-48 V AC for LC1D09-D38 Contactor Accessory

Name: Schneider Electric LAD4RCE TeSys Deca RC Suppressor Module 24-48 V AC for LC1D09-D38 Contactor Accessory
Brand: Schneider Electric
SKU: LAD4RCE
Price: 9.6 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Schneider Electric

Reference No: LAD4RCE

Catalog No: LAD4RCE

Tariff Code (HS): 853690

Rated Voltage: 24-48 V AC

Poles: 3P

Stock: 0

Delivery time: 30 business day(s)

Shipping Origin: Türkiye EXW

$9.60

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Schneider Electric LAD4RCE is a TeSys Deca RC suppressor module for 24-48 V AC control circuits, clip-mounted on the side of LC1D09-D38 3-pole and LC1DT20-DT40 4-pole contactors, and also fits CAD control relays. It limits the coil-switching transient voltage to 3 Uc maximum without changing the overall contactor size.

Technical Specifications

SKU	LAD4RCE
GTIN	3389110385199
Brand	Schneider Electric
Range	TeSys Deca
Device short name	LAD4
Product type	Suppressor module
Product compatibility	3P LC1D09-D38, 4P LC1DT20-DT40, 4P LC1D098-D258, CAD32, CAD50
Suppressor technology	RC circuit
Control circuit voltage Uc	24-48 V AC
Maximum peak voltage	3 Uc
Mounting	Side, by clips
IP degree of protection	IP2X
Net weight	0.012 kg
Ambient temperature, operation	-25 to 55 °C
Country of origin	France

Certifications & Standards

UL
CSA
IEC 60947-5-1
EN 60947-5-1
CSA C22.2 No 60947-5-1
UL 60947-5-1
GB/T 14048.5

Selection Notes

The LAD4RCE covers 24-48 V AC coils on the smaller LC1D09-D38/LC1DT20-DT40 frame and CAD control relays; for 110-250 V AC coils on the same compatibility range, use the LAD4RCU instead. Side mounting in the contactor's cavity, rather than the front-clip LAD4RC3E/U parts for the larger LC1D40A-D80A frame, keeps the unit out of the way of the operating handle.

Technical Details

Short Description

TeSys Deca RC suppressor module, 24-48 V AC coil, for LC1D09-D38 (3P) / LC1DT20-DT40 (4P) contactors and CAD relays.

Rated Voltage (VAC)

24-48 V AC

Mounting Type

Side, by clips

Protection Type

IP2X

Catalog No

LAD4RCE

Number of Poles

Delivery Date (Days)

30 days

Model Number

LAD4RCE

Tariff Code

853690
