The Schneider Electric LA9G3102 is a TeSys Giga cable memory kit for 3-pole LC1G265-500 contactors, holding field cables in place when a contactor is replaced so reinstallation is faster. It is sold as a set of 2.
The LA9G3102 is sized for the LC1G265-500 frame; the smaller LC1G115-225 frame uses the LA9G3101 cable memory kit instead. It is a mechanical aid for maintenance swaps, not a connection-carrying part, so it adds no current or voltage rating of its own.
| Product or Component Type | Terminal extension |
|---|---|
| Product Compatibility | LC1G265...500 |
| Poles description | 3P |
|---|---|
| Height | 4.09 in (104 mm) |
| Width | 5.5 in (140 mm) |
| Depth | 2.2 in (56.4 mm) |
| Net Weight | 1.3 lb(US) (0.6 kg) |
| Quantity per Set | Set of 2 |
| Pollution degree | 3 IEC 60947-1 |
|---|---|
| Operating altitude | 9842.52 ft (3000 m) without derating, 5000 m with derating factor |
| Standards | EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, GB/T 14048.4 |
| Product Certifications | CE, UKCA, cULus |
| Part number | LA9G3102 |
|---|---|
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3606481916358 |
| Warranty (in months) | 18 |
|---|
| Country of origin | CN |
|---|---|
| Shipping weight | 0.6 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe tariff (HS) code on file for LA9G3102 is 853690.
The EAN (GTIN) of LA9G3102 is 3606481916358.
LA9G3102 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
