Part number
GV4P80S
Model no
GV4P
$717.20 On request Dispatch — · From TürkiyeGet a Quote
TeSys GV4

Schneider Electric GV4P80S TeSys GV4 3P 80 A 100 kA Thermal-Magnetic Motor Protection Circuit Breaker (MPCB)

Schneider Electric GV4P80S TeSys GV4 MPCB, 3P 80 A, 100 kA Icu at 400 V, thermal-magnetic trip unit.

Rated current
80 A
Rated operational voltage
690 V AC
Motor power
22–37 kW
Poles
3P
EAN
3606481386854
Description

About the GV4P

The Schneider Electric GV4P80S is a 3-pole TeSys GV4 motor circuit breaker rated 80 A continuous current with a 100 kA breaking capacity (Icu) at 380-415 V AC. It provides thermal-magnetic protection for 3-phase motors from 22-37 kW at 400 V, with a 40-80 A thermal setting range and rotary handle start-stop control.

Certifications & Standards

  • IEC 60947-2
  • IEC 60947-4-1
  • UL 60947-4-1
  • CSA C22.2 No 60947-4-1
  • CCC
  • EAC
  • ATEX
  • EU-RO MR

Selection Notes

Fixed thermal-magnetic protection covers overload and short-circuit tripping; there is no electronic adjustment beyond the 40-80 A thermal dial and the fixed instantaneous pickup at 17 x In. The trailing S in the catalog number identifies the breaking-capacity class Schneider assigns within the GV4 range (B/N/S step up from economy to high short-circuit withstand); this unit falls in the high 100 kA tier, so it should be matched to the prospective short-circuit current at the installation point rather than swapped for a lower class to save cost on a feeder with higher fault levels. For the 80 A frame, internal mounting positions accept OF/SD auxiliary contact blocks and MN/MX voltage trip units without changing the breaker's footprint, which keeps a panel design consistent across the motor power range it covers.

Specification

Full specification

58 values · Last verified 30 Oct 2026

Main 7

Range TeSys Deca
Range of Product TeSys GV4
Device short name GV4P
Product name TeSys GV4
Product or Component Type Motor circuit breaker
Device Application Motor protection
Trip unit technology Thermal-magnetic, Electronic

Complementary 27

Poles description 3P
Utilisation category Category A IEC 60947-2, AC-3 IEC 60947-4-1
Operating position Any position
Motor power kW 37 kW 400...415 V AC 50/60 Hz, 45 kW 500 V AC 50/60 Hz, 22 kW 400...415 V AC 50/60 Hz, 30 kW 500 V AC 50/60 Hz, 37 kW 660...690 V AC 50/60 Hz, 45 kW 660...690 V AC 50/60 Hz, 55 kW 660...690 V AC 50/60 Hz, 30 kW 400...415 V AC 50/60 Hz, 37 kW 500 V AC 50/60 Hz
Breaking capacity 120 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2, 100 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2, 70 kA Icu 440 V AC 50/60 Hz IEC 60947-2, 30 kA Icu 500 V AC 50/60 Hz IEC 60947-2, 18 kA Icu 525 V AC 50/60 Hz IEC 60947-2, 100 kA 208Y/120 V AC 50/60 Hz UL 60947, 100 kA 240 V AC 50/60 Hz UL 60947, 65 kA 480Y/277 V AC 50/60 Hz UL 60947, 10 kA Icu 660...690 V AC 50/60 Hz IEC 60947-2, 25 kA 600Y/347 V AC 50/60 Hz UL 60947
Control Type Rotary handle
Line Rated Current 80 A
Magnetic tripping current 1360 A
[Ue] rated operational voltage 690 V AC 50/60 Hz IEC 60947-2
[Ui] rated insulation voltage 800 V AC 50/60 Hz IEC 60947-2
[Ith] conventional free air thermal current 115 A IEC 60947-4-1
[Uimp] rated impulse withstand voltage 8 kV IEC 60947-2
Power dissipation per pole 4.6 W
Mechanical durability 40000 cycles
Electrical durability 5000 cycles AC-3 415 V opening, 5000 cycles AC-3 415 V closing
maximum operating rate 25 cyc/h
Rated duty Continuous IEC 60947-4-1
Connections - terminals EverLink BTR screw connectors (top): 1 cable(s) 0.002…0.1 in² (1.5…70 mm²) - solid, EverLink BTR screw connectors (top): 1 cable(s) 0.002…0.08 in² (1.5…50 mm²) - flexible, EverLink BTR screw connectors (bottom): 1 cable(s) 0.004…0.1 in² (2.5…95 mm²) - solid, EverLink BTR screw connectors (bottom): 1 cable(s) 0.004…0.1 in² (2.5…70 mm²) - flexible
Tightening torque 79.7 lbf.in (9 N.m) 0.02…0.1 in² (16…95 mm²), 44.3 lbf.in (5 N.m) 0.002…0.02 in² (1.5…10 mm²)
Mechanical robustness Vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6, Vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6, Shocks 15 gn 11 ms IEC 60068-2-27
Phase failure sensitivity Yes IEC 60947-4-1
Height 6.1 in (155 mm)
Width 3.2 in (81 mm)
Depth 6.5 in (165 mm)
Net Weight 3.5 lb(US) (1.6 kg)
color Gray RAL 7016)
Suitability for isolation Yes IEC 60947-1

Environment 10

Standards CSA C22.2 No 60947-4-1, UL 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-2
Product Certifications IEC, UL, CSA, CCC, EAC, ATEX, EU-RO MR
Climatic withstand IACS E10
IK degree of protection IK07 IEC 62262
Pollution degree 3
IP degree of protection IP40 IEC 60529
Ambient Air Temperature for Storage -58…185 °F (-50…85 °C)
Fire resistance 1760 °F (960 °C) IEC 60695-2-11
Operating altitude 5000 m
Ambient air temperature for operation -13…158 °F (-25…70 °C)
Show all 58 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.

Identification 8

Part number GV4P80S
Type designation GV4P
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3606481386854

Contractual warranty 1

Warranty (in months) 18

Logistics 5

Country of origin PL
Shipping weight 1.6 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for GV4P80S

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • CSA
  • CCC
  • EAC
  • CSA C22.2 No 60947-4-1
  • UL 60947-4-1
  • EN/IEC 60947-4-1
  • EN/IEC 60947-2
Quick answers

Questions about the GV4P

What is the rated current of GV4P?

The rated current of GV4P is 80 A.

Which supply voltage is GV4P rated for?

The rated operational voltage of GV4P is 690 V AC.

What motor power is GV4P rated for?

The rated motor power of GV4P is 22–37 kW.

What is the HS code of GV4P for customs?

The tariff (HS) code on file for GV4P is 853620.

What is the EAN of GV4P?

The EAN (GTIN) of GV4P is 3606481386854.

Where does GV4P ship from, and how fast?

GV4P ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
