Part number
GV4P25N
Model no
GV4P
$563.72 On request Dispatch — · From TürkiyeGet a Quote
TeSys GV4

Schneider Electric GV4P25N TeSys GV4 3P 25 A 50 kA Thermal-Magnetic Motor Protection Circuit Breaker (MPCB)

TeSys GV4 motor circuit breaker, 3P, 25 A, Icu 50 kA at 400 V, 5.5-11 kW

Rated current
25 A
Rated operational voltage
690 V AC
Motor power
5.5–11 kW
Poles
3P
EAN
3606481310354
Description

About the GV4P

The Schneider Electric GV4P25N is a TeSys GV4 three-pole motor circuit breaker rated 25 A, providing thermal-magnetic protection for 3-phase motors from 5.5-11 kW at 400 V with a breaking capacity Icu of 50 kA at 400/415 V. A rotary handle gives local start-stop control, and EverLink BTR screw terminals keep contact resistance stable over repeated torque cycles.

Certifications & Standards

  • IEC 60947-2
  • IEC 60947-4-1
  • UL 60947-4-1
  • CSA C22.2 No. 60947-4-1
  • CCC
  • EAC
  • ATEX
  • EU-RO MR

Selection Notes

The 25N covers 5.5-11 kW motors at 400 V, one frame size up from the 12N; move to the 115 A frame (115B/115N/115S) once motor power exceeds this unit's 25 A thermal setting ceiling.

Applications

Use for direct-on-line motor protection in panels where thermal overload, short-circuit and phase-loss protection must sit in a single rotary-handle device ahead of a GV4P-compatible contactor.

Specification

Full specification

69 values · Last verified 30 Oct 2026

Main 7

Range TeSys Deca
Range of Product TeSys GV4
Device short name GV4P
Product name TeSys GV4
Product or Component Type Motor circuit breaker
Device Application Motor protection
Trip unit technology Electronic, Thermal-magnetic

Complementary 27

Poles description 3P
Utilisation category Category A IEC 60947-2, AC-3 IEC 60947-4-1
Operating position Any position
Motor power kW 7.5 kW 660...690 V AC 50/60 Hz, 5.5 kW 400...415 V AC 50/60 Hz, 7.5 kW 500 V AC 50/60 Hz, 9 kW 660...690 V AC 50/60 Hz, 11 kW 660...690 V AC 50/60 Hz, 7.5 kW 400...415 V AC 50/60 Hz, 9 kW 400...415 V AC 50/60 Hz, 11 kW 400...415 V AC 50/60 Hz, 9 kW 500 V AC 50/60 Hz, 11 kW 500 V AC 50/60 Hz, 15 kW 500 V AC 50/60 Hz, 15 kW 660...690 V AC 50/60 Hz, 18.5 kW 660...690 V AC 50/60 Hz
Breaking capacity 100 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2, 50 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2, 50 kA Icu 440 V AC 50/60 Hz IEC 60947-2, 15 kA Icu 525 V AC 50/60 Hz IEC 60947-2, 65 kA 208Y/120 V AC 50/60 Hz UL 60947, 65 kA 240 V AC 50/60 Hz UL 60947, 35 kA 480Y/277 V AC 50/60 Hz UL 60947, 8 kA Icu 660...690 V AC 50/60 Hz IEC 60947-2, 25 kA Icu 500 V AC 50/60 Hz IEC 60947-2, 18 kA 600Y/347 V AC 50/60 Hz UL 60947
Control Type Rotary handle
Line Rated Current 25 A
Magnetic tripping current 425 A
[Ue] rated operational voltage 690 V AC 50/60 Hz IEC 60947-2
[Ui] rated insulation voltage 800 V AC 50/60 Hz IEC 60947-2
[Ith] conventional free air thermal current 115 A IEC 60947-4-1
[Uimp] rated impulse withstand voltage 8 kV IEC 60947-2
Power dissipation per pole 4.6 W
Mechanical durability 40000 cycles
Electrical durability 5000 cycles AC-3 415 V opening, 5000 cycles AC-3 415 V closing
maximum operating rate 25 cyc/h
Rated duty Continuous IEC 60947-4-1
Connections - terminals EverLink BTR screw connectors (top): 1 cable(s) 0.002…0.1 in² (1.5…70 mm²) - solid, EverLink BTR screw connectors (top): 1 cable(s) 0.002…0.08 in² (1.5…50 mm²) - flexible, EverLink BTR screw connectors (bottom): 1 cable(s) 0.004…0.1 in² (2.5…95 mm²) - solid, EverLink BTR screw connectors (bottom): 1 cable(s) 0.004…0.1 in² (2.5…70 mm²) - flexible
Tightening torque 79.7 lbf.in (9 N.m) 0.02…0.1 in² (16…95 mm²), 44.3 lbf.in (5 N.m) 0.002…0.02 in² (1.5…10 mm²)
Mechanical robustness Vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6, Vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6, Shocks 15 gn 11 ms IEC 60068-2-27
Phase failure sensitivity Yes IEC 60947-4-1
Height 6.1 in (155 mm)
Width 3.2 in (81 mm)
Depth 6.5 in (165 mm)
Net Weight 3.5 lb(US) (1.6 kg)
color Gray RAL 7016)
Suitability for isolation Yes IEC 60947-1

Environment 10

Standards CSA C22.2 No 60947-4-1, UL 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-2
Product Certifications IEC, UL, CSA, CCC, EAC, ATEX, EU-RO MR
Climatic withstand IACS E10
IK degree of protection IK07 IEC 62262
Pollution degree 3
IP degree of protection IP40 IEC 60529
Ambient Air Temperature for Storage -58…185 °F (-50…85 °C)
Fire resistance 1760 °F (960 °C) IEC 60695-2-11
Operating altitude 5000 m
Ambient air temperature for operation -13…158 °F (-25…70 °C)
Show all 69 specifications ↓ Show less ↑25 more values in Identification, Contractual warranty, Logistics.

Identification 8

Part number GV4P25N
Type designation GV4P
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3606481310354

Contractual warranty 1

Warranty (in months) 18

Logistics 16

Unit Type of Package 1 PCE
Nbr. of units in pkg. 1
Package 1 Height 4.9 in (12.5 cm)
Package 1 Width 8.2 in (20.8 cm)
Package 1 Length 8.7 in (22.0 cm)
Package weight(Lbs) 4.06 lb(US) (1.84 kg)
Unit Type of Package 2 S03
Number of Units in Package 2 3
Package 2 Height 11.8 in (30.0 cm)
Package 2 Width 11.8 in (30.0 cm)
Package 2 Length 15.7 in (40.0 cm)
Package 2 Weight 14.3 lb(US) (6.5 kg)
Shipping weight 1.6 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for GV4P25N

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • CSA
  • CCC
  • EAC
  • CSA C22.2 No 60947-4-1
  • UL 60947-4-1
  • EN/IEC 60947-4-1
  • EN/IEC 60947-2
Quick answers

Questions about the GV4P

What is the rated current of GV4P?

The rated current of GV4P is 25 A.

Which supply voltage is GV4P rated for?

The rated operational voltage of GV4P is 690 V AC.

What motor power is GV4P rated for?

The rated motor power of GV4P is 5.5–11 kW.

What is the HS code of GV4P for customs?

The tariff (HS) code on file for GV4P is 853620.

What is the EAN of GV4P?

The EAN (GTIN) of GV4P is 3606481310354.

Where does GV4P ship from, and how fast?

GV4P ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
