CA3KN31ED is Schneider Electric's TeSys K control relay in a 3NO+1NC arrangement, built around a 48 V DC coil with electronic surge suppression and rated 10 A Ith at up to 690 V. It is rated for AC-15/DC-13 duty, used to control and duplicate pilot signals in motor control and interlocking circuits, and connects via screw clamp terminals on DIN rail or a mounting plate.
Choose the 3NO+1NC version when the application needs three make contacts for parallel command signals alongside one break contact for interlocking or indication. The 48 V DC coil variant fits control circuits already wired at that voltage, so the contactor coil can be driven directly without an additional transformer tap. The DC coil has no inrush surge and a longer 30–40 ms closing time than the AC-coil CA2Kseries, which electronic surge suppression trades for lower steady-state power draw — relevant when the relay is driven from a PLC transistor output or a current-limited 24 V DC rail.
| Range | TeSys |
|---|---|
| Product name | TeSys CAK |
| Product or Component Type | Control relay |
| Device short name | CA3K |
| Contactor application | Control circuit |
| Utilisation category | DC-13, AC-15 |
| Pole contact composition | 3 NO + 1 NC |
| [Ue] rated operational voltage | <= 690 V <= 400 Hz |
| Control circuit type | DC standard |
| [Uc] control circuit voltage | 48 V DC |
| [Ith] conventional free air thermal current | 10 A (at 122 °F (50 °C)) |
|---|---|
| Irms rated making capacity | 110 A IEC 60947 |
| Associated fuse rating | 10 A gG conforming to IEC 60947, 10 A gG conforming to VDE 0660 |
| [Ui] rated insulation voltage | 690 V IEC 60947, 750 V VDE 0110 group C, 690 V BS 5424, 600 V CSA C22.2 No 14 |
| Mounting Support | Plate, Rail |
| Connections - terminals | screw clamp terminals 1 0.002…0.006 in² (1.5…4 mm²)solid, screw clamp terminals 2 0.002…0.006 in² (1.5…4 mm²)solid, screw clamp terminals 1 0.001…0.006 in² (0.75…4 mm²)flexible with cable end, screw clamp terminals 2 0.001…0.006 in² (0.75…4 mm²)flexible without cable end, screw clamp terminals 1 0.0005…0.002 in² (0.34…1.5 mm²)flexible with cable end, screw clamp terminals 2 0.0005…0.002 in² (0.34…1.5 mm²)flexible without cable end |
| Tightening torque | 11.5 lbf.in (1.3 N.m) screw clamp terminals flat Ø 6 mm, 11.5 lbf.in (1.3 N.m) screw clamp terminals Philips No 2 0.2 in (6 mm), 11.5 lbf.in (1.3 N.m) screw clamp terminals pozidriv No 2 |
| Control circuit voltage limits | Operational: 0.8...1.15 Uc (at <122 °F (50 °C)), Drop-out: 0.1...0.75 Uc (at <122 °F (50 °C)) |
| Operating time | 10 ms coil de-energisation and NO opening, 30...40 ms coil energisation and NO closing, 15 ms coil de-energisation and NC closing, 25...35 ms coil energisation and NC opening |
| Mechanical durability | 20 Mcycles |
| Maximum operating rate | 10000 cyc/h |
| Immunity to microbreaks | 2 ms |
| Inrush power in W | 3 W 68 °F (20 °C)) |
| Hold-in power consumption in W | 3 W 68 °F (20 °C) |
| Heat dissipation | 3 W |
| Minimum switching voltage | 17 V |
| Minimum switching current | 5 mA |
| Non overlap distance | 0.02 in (0.5 mm) |
| Insulation resistance | > 10 MOhm |
| Height | 2.3 in (58 mm) |
| Width | 1.8 in (45 mm) |
| Depth | 2.2 in (57 mm) |
| Net Weight | 0.496 lb(US) (0.225 kg) |
| Standards | EN/IEC 60947-5-1, GB/T 14048.5, UL 60947-5-1, CSA C22.2 No 60947-5-1, JIS C8201-5-1 |
|---|---|
| Product Certifications | CB Scheme, CCC, UL, CSA, EAC, CE, UKCA |
| IP degree of protection | IP2X |
| Protective treatment | TC IEC 60068 |
| Ambient Air Temperature for Operation | -13…122 °F (-25…50 °C) |
| Ambient Air Temperature for Storage | -58…176 °F (-50…80 °C) |
| Operating altitude | 6561.68 ft (2000 m) without derating |
| Flame retardance | V1 conforming to UL 94, Requirement 2 conforming to NF F 16-101, Requirement 2 conforming to NF F 16-102 |
| Mechanical robustness | Vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6, Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6, Shocks contactor open10 Gn for 11 ms IEC 60068-2-27, Shocks contactor closed15 Gn for 11 ms IEC 60068-2-27 |
| Part number | CA3KN31ED |
|---|---|
| Type designation | CA3K |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3389110484304 |
| Warranty (in months) | 18 |
|---|
| Country of origin | ID |
|---|---|
| Shipping weight | 0.225 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe rated current of CA3K is 10 A.
The rated operational voltage of CA3K is 48 V DC.
The tariff (HS) code on file for CA3K is 853650.
The EAN (GTIN) of CA3K is 3389110484304.
CA3K ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
