Part number
BLRCH335A401B44
$144.84 On request Dispatch — · From TürkiyeGet a Quote
PowerLogic

Schneider Electric BLRCH335A401B44 VarPlus Can HDuty 33.5 kvar 440 V 50 Hz Power Factor Correction Capacitor

Schneider Electric BLRCH335A401B44 — VarPlus Can HDuty power factor correction capacitor, 33.5 kvar at 440 V, 50 Hz.

Rated operational voltage
440 V AC
Description

About the BLRCH335A401B44

The Schneider Electric BLRCH335A401B44 is a VarPlus Can HDuty power factor correction capacitor rated 33.5 kvar at 440 V, 50 Hz (40.1 kvar at 60 Hz). Built with a metallized polypropylene film dielectric and a 1.8× In continuous overcurrent rating for networks with up to 20% harmonic content, it connects through a clamptite terminal in a 136 mm diameter, IP20 enclosure weighing 3.2 kg.

Certifications & Standards

  • IEC 60831-1
  • IEC 60831-2

Selection Notes

HDuty (heavy duty) construction gives the BLRCH335A401B44 a 1.8× In continuous overcurrent capacity, so it stays within rating on networks where variable-speed drives or rectifiers push harmonic distortion toward the 20% ceiling — a standard-duty capacitor sized only for the fundamental would overheat under the same load. At 440 V the unit delivers 33.5 kvar on a 50 Hz network or 40.1 kvar on a 60 Hz network from the same can, useful when the same bank design serves both European and North American sites. Pick this variant to match bus voltage directly rather than relying on a transformer tap; the 136 mm x 242 mm can and clamptite terminal keep the footprint compact for panel-mounted power factor correction banks.

Specification

Full specification

61 values · Last verified 30 Oct 2026

Main 11

Range PowerLogic
Range of product PowerLogic
Product or component type Heavy duty capacitor
Product name PowerLogic PFC Capacitor
Network frequency 50/60 Hz
Series name HDuty
Network harmonic content <= 20 %
Electrical parameters 33.5 kvar 440 V 50 Hz, 40.1 kvar 440 V 60 Hz
Maximum permissible voltage 1.1 x Un (8 hours over 24 hours)
continuous overcurrent capacity 1.8 x In
Rated voltage 440 V AC 50/60 Hz

Complementary 15

Dielectric losses < 0.2 W/kvar
Power losses < 0.5 W/kVAr
Capacitance tolerance - 5 % to 10 %
Voltage test 2.15 x Un AC between terminals for 10 s, <= 660 V - 3 kV AC between terminal and container for 10 s, >= 660 V - 6 kV AC between terminal and container for 10 s
Inrush current 250 x In
Maximum switching operation per year 7000
Service life in hours 130000 h
Dielectric material Metallized polypropylene film with Zn/Al alloy, special resistivity & profile, special edge (wave cut)
Impregnation material Non-PCB dry PUR resin, Biodegradable
Type of installation Indoor installation
Connections - terminals ClampTite terminal
Mounting mode Upright/horizontal
Diameter 136 mm
Height 242 mm
Net weight 3.2 kg

Environment 6

Standards IEC 60831-1, IEC 60831-2
IP degree of protection IP20
Operating altitude 2000 m
Temperature class D
Ambient air temperature for operation -25…55 °C
Relative humidity 95 %
Show all 61 specifications ↓ Show less ↑29 more values in Identification, Contractual warranty, Logistics.

Identification 6

Part number BLRCH335A401B44
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 22

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 28 cm
Package 1 Width 18 cm
Package 1 Length 18 cm
Package 1 Weight 3.84 kg
Unit Type of Package 2 S04
Number of Units in Package 2 3
Package 2 Height 30 cm
Package 2 Width 40 cm
Package 2 Length 60 cm
Package 2 Weight 11.52 kg
Unit Type of Package 3 S06
Number of Units in Package 3 15
Package 3 Height 73.5 cm
Package 3 Width 60 cm
Package 3 Length 80 cm
Package 3 Weight 57.6 kg
Shipping weight 3.2 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for BLRCH335A401B44

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • IEC 60831-1
  • IEC 60831-2
Quick answers

Questions about the BLRCH335A401B44

Which supply voltage is BLRCH335A401B44 rated for?

The rated operational voltage of BLRCH335A401B44 is 440 V AC.

What is the HS code of BLRCH335A401B44 for customs?

The tariff (HS) code on file for BLRCH335A401B44 is 853210.

Where does BLRCH335A401B44 ship from, and how fast?

BLRCH335A401B44 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
