Part number
83046
Model no
Mureva socket
$108.16 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric 83046 Unika Interlocked Wall Socket 32 A 3P+E 380-415 V IP44 Industrial Socket

Unika interlocked socket, 32 A, 3P+E, 380-415 V AC, IP44.

Rated current
32 A
Rated operational voltage
380–415 V AC
Description

About the Mureva socket

The Schneider Electric 83046 is a Unika interlocked industrial socket rated 32 A for 3P+E networks at 380-415 V AC, 50/60 Hz. Its mechanical interlock blocks the plug from being inserted or withdrawn while the integral switch is live, and it is wall-mounted with IP44 (IK09) protection, a 750 C fire resistance rating and a red voltage-identification ring on its grey (ral 7035) housing.

Certifications & Standards

  • IEC 60309-1
  • IEC 60309-2

Selection Notes

Choose the 83046 over a straight (non-interlocked) socket of the same rating when the circuit must be de-energised before the plug can be removed; its 3P+E configuration suits three-phase loads such as motors that do not require a neutral conductor. IP44 covers splash protection for sheltered indoor or covered outdoor panel locations, and the wall mounting with its own back box keeps the 32 A rating consistent with the captive-screw terminal sizing listed above.

Specification

Full specification

57 values · Last verified 30 Oct 2026

Main 7

Range Mureva
Product or component type Interlocked socket
Device short name Mureva socket
Plug, socket category Low voltage
Poles description 3P + E
Network type AC
Outlet standard Industrial

Complementary 20

Mounting mode Wall-mounted
[In] rated current 32 A
[Ue] rated operational voltage 380...415 V
Network frequency 50/60 Hz
Ground lug clockwise position 6 h
Protection type Without protection
Plug, socket material Housing: self-extinguishing engineering polymer
Contacts material Sleeves: nickel plated brass
Connections - terminals Captive screws
Maximum cable cross section 10 mm²
Maximum cable outer diameter 25 mm
cable entry Cable gland
Thread type Pg 21
Net weight 1.127 kg
Base dimension 103 x 255 mm
Height 255 mm
Width 103 mm
Depth 151 mm
Colour Grey (RAL 7035)
Voltage colour Red

Environment 6

Standards IEC 60309-2, IEC 60309-1
IP degree of protection IP44 conforming to IEC 60529
IK degree of protection IK09 conforming to EN 62262
Fire resistance 750 °C conforming to IEC 60695-2-11
Relative humidity 50 % at 40 °C, 70 % at 30 °C, 90 % at 20 °C
Ambient air temperature for operation 35 °C ( 86400 s ), -25…40 °C
Show all 57 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.

Identification 7

Part number 83046
Type designation Mureva socket
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 16

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 11.000 cm
Package 1 Width 26.500 cm
Package 1 Length 17.000 cm
Package 1 Weight 1.115 kg
Unit Type of Package 2 S03
Number of Units in Package 2 5
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 6.062 kg
Shipping weight 1.127 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 83046

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • IEC 60309-2
  • IEC 60309-1
Quick answers

Questions about the Mureva socket

What is the rated current of Mureva socket?

The rated current of Mureva socket is 32 A.

Which supply voltage is Mureva socket rated for?

The rated operational voltage of Mureva socket is 380–415 V AC.

What is the HS code of Mureva socket for customs?

The tariff (HS) code on file for Mureva socket is 853669.

Where does Mureva socket ship from, and how fast?

Mureva socket ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
