ABB 7TCA085400R0383 OVR SL30/I 30V 750mA 4P Surge Protective Device (SPD)

% $-269.05
ABB 7TCA085400R0383 OVR SL30/I Surge Protective Device – 30V, 4P, isolated screen
ABB 7TCA085400R0383 OVR SL30/I Surge Protective Device – 30V, 4P, isolated screen

ABB 7TCA085400R0383 OVR SL30/I 30V 750mA 4P Surge Protective Device (SPD)

Brand: ABB
Reference No: 7TCA085400R0383
Catalog No: OVR SL30/I
Series: ABB OVR data & signal protection
Tariff Code (HS): 853540
Rated Voltage: 30 V
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$269.05

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 7TCA085400R0383 (OVR SL30/I) is a slim-line, 4-pole surge protective device for 30 V signal lines carrying up to 750 mA, with an isolated screen connection for shielded cabling. It discharges up to 10 kA (8/20 µs) and holds the protection level to 45.4 V, guarding multi-wire data circuits against lightning and switching transients.

Technical Specifications

Catalog Designation OVR SL30/I
SKU 7TCA085400R0383
Brand ABB
Series ABB OVR data & signal protection
EAN 5415022374827
Nominal AC Voltage of System (Uo) 30 V
Maximum Continuous Operating Voltage (Uc) 36.7 V
Discharge Current (I max, 8/20 µs) 10 kA
Voltage Protection Level (Up) 45.4 V
Rated Current (In) 750 mA
Rated Frequency (f) 45 MHz
Number of Protected Poles 4
Connection Type Screw Clamp
Serial Resistance 1 Ω
Wire Stripping Length 9.5 mm
Ambient Air Temperature (Operation) -40 to +80 °C
Net Width 106.5 mm
Net Height 104.6 mm
Net Depth 7 mm
Net Weight 0.08 kg

Certifications & Standards

  • IEC 61643-21

Selection Notes

Four protected poles let the SL30/I cover a full shielded 4-wire line plus isolated screen in a single slim housing, rather than stacking single-pair modules. The isolated screen connection keeps cable shield grounding separate from the signal-line earth reference, which matters on installations where screen and chassis ground are not at the same potential. At 7 mm thick, the slim-line body saves panel width on cabinets already packed with other DIN-rail protection.

Technical Details

Short Description
ABB OVR SL30/I slim-line 30V surge protective device, 4-pole, 750mA, isolated screen connection, screw-clamp terminals.
Rated Voltage (VAC)
30 V
Mounting Type
DIN-Rail
Catalog No
OVR SL30/I
Number of Poles
4P
Standards
IEC 61643-21
Delivery Date (Days)
30 days
Model Number
OVR SL30/I
Tariff Code
853540
