ABB 7TCA085400R0368 OVR SL30L 30V 750mA 3P Surge Protective Device (SPD)

% $-254.45
ABB 7TCA085400R0368 OVR SL30L Surge Protective Device – 30V, 3P, LED status
ABB 7TCA085400R0368 OVR SL30L Surge Protective Device – 30V, 3P, LED status

ABB 7TCA085400R0368 OVR SL30L 30V 750mA 3P Surge Protective Device (SPD)

Brand: ABB
Reference No: 7TCA085400R0368
Catalog No: OVR SL30L
Series: ABB OVR data & signal protection
Tariff Code (HS): 853540
Rated Voltage: 30 V
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$254.45

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 7TCA085400R0368 (OVR SL30L) is a slim-line, 3-pole surge protective device for 30 V signal lines rated up to 750 mA, with an integrated LED that shows protection status at a glance. It discharges up to 10 kA (8/20 µs) and limits the voltage protection level to 45.4 V, shielding multi-wire data circuits against lightning and switching surges.

Technical Specifications

Catalog Designation OVR SL30L
SKU 7TCA085400R0368
Brand ABB
Series ABB OVR data & signal protection
EAN 5415022374865
Nominal AC Voltage of System (Uo) 30 V
Maximum Continuous Operating Voltage (Uc) 36.7 V
Discharge Current (I max, 8/20 µs) 10 kA
Voltage Protection Level (Up) 45.4 V
Rated Current (In) 750 mA
Rated Frequency (f) 45 MHz
Number of Protected Poles 3
Connection Type Screw Clamp
Serial Resistance 1 Ω
Wire Stripping Length 9.5 mm
Ambient Air Temperature (Operation) -40 to +80 °C
Net Width 106.5 mm
Net Height 104.6 mm
Net Depth 7 mm
Net Weight 0.08 kg

Certifications & Standards

  • IEC 61643-21

Selection Notes

Three protected poles size the SL30L for a standard 3-wire signal pair plus common, without the extra isolated-screen terminal of the screened variants in the same slim-line family. The onboard LED status indicator lets a technician confirm protection is intact from a visual panel check instead of a multimeter test, useful on cabinets with many stacked SPD modules. At 750 mA and a 45.4 V protection level, it suits standard data and control-signal loops rather than low-current telecom lines.

Technical Details

Short Description
ABB OVR SL30L slim-line 30V surge protective device, 3-pole, 750mA, LED status indication, screw-clamp terminals.
Rated Voltage (VAC)
30 V
Mounting Type
DIN-Rail
Catalog No
OVR SL30L
Number of Poles
3P
Standards
IEC 61643-21
Delivery Date (Days)
30 days
Model Number
OVR SL30L
Tariff Code
853540
