ABB 2CTB812052R1500 OVR PV T1-T2 5-1500 C QS 40kA 2P Solar Surge Protective Device (SPD)

% $-78.13
ABB 2CTB812052R1500 OVR PV T1-T2 5-1500 C QS Solar Surge Protective Device – 1500V DC, 40kA
ABB 2CTB812052R1500 OVR PV T1-T2 5-1500 C QS Solar Surge Protective Device – 1500V DC, 40kA

ABB 2CTB812052R1500 OVR PV T1-T2 5-1500 C QS 40kA 2P Solar Surge Protective Device (SPD)

Brand: ABB
Reference No: 2CTB812052R1500
Catalog No: OVR PV T1-T2 5-1500 C QS
Series: Surge Protective Devices SPD Class I
Tariff Code (HS): 853540
Breaking Type: Type 1+2 (Class I+II) combined arrester, plug-in cartridge
Poles: 2P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$78.13

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 2CTB812052R1500 (OVR PV T1-T2 5-1500 C QS) is a combined Type 1+2 surge protective device for 1500 V DC photovoltaic strings, supplied as the plug-in protection cartridge (C) for the QS base. It discharges up to 40 kA (8/20 µs) with a 5 kV voltage protection level across 2 protected poles, safeguarding higher-voltage PV strings against lightning-induced DC surges.

Technical Specifications

Catalog Designation OVR PV T1-T2 5-1500 C QS
SKU 2CTB812052R1500
Brand ABB
Series Surge Protective Devices SPD Class I
EAN 4053546034714
Voltage Rating DC 1500 V
Maximum Power Point (MPP) Voltage 1500 V
Rated Voltage (Ur) 1500 V DC
Arrester Class I / II
Discharge Current, Nominal (8/20 µs) 20 kA
Discharge Current, Max (8/20 µs) 40 kA
Total Discharge Current (10/350 µs) 5 kA
Rated Service Short-Circuit Breaking Capacity (Ics) 11 kA
Voltage Protection Level (Up) 5 kV
Number of Protected Poles 2
Number of Conductors 2
Version Plug-in Cartridge
Status Indicator Yes
Degree of Protection IP20
Max Conductor Cross-Section, Solid/Stranded 35 mm²
Max Conductor Cross-Section, Flexible 25 mm²
Net Width 24 mm
Net Height 45 mm
Net Depth 74 mm
Net Weight 0.087 kg
Mounting Type DIN-Rail

Certifications & Standards

  • IEC 61643-11
  • EN 50539-11

Selection Notes

This 1500 V-rated cartridge steps up from the 1000 V part to match higher-voltage PV string architectures common on utility-scale arrays, where stringing more modules per string reduces balance-of-system cabling costs. The 5 kV protection level, against 3.8 kV on the 1000 V-rated cartridge, reflects the higher system voltage it must withstand without breaking down. As the 'C' cartridge, it drops into an existing QS base once the original module reaches end-of-life, without rewiring the base terminals.

Technical Details

Short Description
ABB OVR PV T1-T2 5-1500 C QS solar SPD cartridge, 1500V DC, Type 1+2, 40kA discharge, 2-pole, plug-in.
Mounting Type
DIN-Rail
Protection Type
IP20
Catalog No
OVR PV T1-T2 5-1500 C QS
Number of Poles
2P
Standards
IEC 61 643-11 / EN 50539-11
Delivery Date (Days)
30 days
Model Number
OVR PV T1-T2 5-1500 C QS
Tariff Code
853540
