ABB 2CDS274011R0404 SH204M-C40 4P 40A C-Curve 10kA Miniature Circuit Breaker (MCB)

% $-45.14
ABB SH204M-C40 2CDS274011R0404 4P 40A type C miniature circuit breaker - 10kA 400V
ABB SH204M-C40 2CDS274011R0404 4P 40A type C miniature circuit breaker - 10kA 400V

ABB 2CDS274011R0404 SH204M-C40 4P 40A C-Curve 10kA Miniature Circuit Breaker (MCB)

Brand: ABB
Reference No: 2CDS274011R0404
Catalog No: SH204M-C40
Series: SH200M
Tariff Code (HS): 853620
Rated Current: 40
Breaking Capacity: 10 kA
Breaking Type: Type C
Rated Voltage: 400 V
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$45.14

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

Rated 40 A with 10 kA breaking capacity at 400 V AC, the ABB SH204M-C40 (SKU 2CDS274011R0404) is the four-pole, higher-current member of the SH200M miniature circuit breaker series. Its type C tripping characteristic trips instantaneously between 5 and 10 times In, which tolerates the inrush of small motors or transformers on three-phase-plus-neutral circuits, and it mounts on standard DIN rail in a 4-module, 70 mm wide housing.

Technical Specifications

SKU 2CDS274011R0404
Brand ABB
Series SH200M
Catalog Designation SH204M-C40
EAN 4016779703055
Number of Poles 4P
Tripping Characteristic Type C
Rated Current (In) 40 A
Rated Operational Voltage 400 V (IEC 60898-1)
Rated Insulation Voltage (Ui) 440 V
Rated Impulse Withstand Voltage (Uimp) 4 kV
Rated Short-Circuit Capacity 10 kA at 400 V AC
Energy Limiting Class 3
Overvoltage Category III
Degree of Protection IP20 (IP40 with cover)
Pollution Degree 2
Connecting Capacity Flexible 0.75-16 mm² / Rigid 0.75-25 mm²
Width 70 mm (4 modules)
Net Weight 0.44 kg
Mounting Type DIN-Rail (TH35-15 / TH35-7.5)

Certifications & Standards

  • IEC/EN 60898-1

Selection Notes

At In 40 A and 4P, the SH204M-C40 protects three-phase-plus-neutral circuits carrying more current than the lower-current, 2-pole members of the SH200M series, while keeping the same type C instantaneous-trip band (5-10× In) that tolerates motor and transformer inrush. Its 10 kA breaking capacity at 400 V AC covers typical distribution fault levels for this current rating without needing a current-limiting device upstream. Choose the 4-pole format specifically when the neutral conductor must be switched along with the three phases, not just protected.

Technical Details

Short Description
ABB SH204M-C40 4P type C miniature circuit breaker, In 40 A, 10 kA breaking capacity at 400 V AC, DIN-rail mounted.
Rated Current (Ampere)
40
Breaking Capacity (kA)
10 kA
Rated Voltage (VAC)
400 V
Mounting Type
DIN-Rail
Protection Type
IP20
Catalog No
SH204M-C40
Number of Poles
4P
Standards
IEC/EN 60898-1
Delivery Date (Days)
30 days
Model Number
SH204M-C40
Tariff Code
853620
