Part number
2CDS272011R0204
Model no
SH202M-C20
$28.57 In stock · 19 Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye

ABB 2CDS272011R0204 SH202M-C20 2P 20A 10kA Miniature Circuit Breaker

Rated current
20 A
Poles
2P
EAN
4016779700719
Other ratings in ABB SH200 All 8 ratings ↓
Neighbouring ratings in the same series
Motor power kW Rated current In (A) Part number Stock Price
6 2CDS272011R0064 In stock $34.27
16 2CDS272011R0164 Low stock $28.57
20 2CDS272011R0204This part In stock $28.57
25 2CDS272011R0254 Low stock $28.57
32 2CDS272011R0324 In stock $35.70
Description

About the SH202M-C20

The ABB SH202M-C20 (SKU: 2CDS272011R0204) is a 2-pole miniature circuit breaker (MCB) from the SH200M series, rated at 20 A with a 10 kA breaking capacity at 400V AC. Designed for reliable overcurrent and short-circuit protection in residential, commercial, and light industrial distribution boards, the SH202M-C20 delivers consistent performance in a compact 35 mm × 88 mm × 69 mm DIN rail-mountable format.

Certifications & Standards

  • IEC 60898-1: International standard for household and similar installations — overcurrent protection
  • EN 60898-1: European harmonised standard for miniature circuit breakers
  • IEC/EN 60898-1: Combined IEC and EN compliance for MCB performance and safety
  • IEC 60898: Core IEC framework for circuit breaker ratings and testing
  • IEC 60068-2: Environmental testing standard — climatic and mechanical durability
  • EN 60664: Insulation coordination for equipment within low-voltage systems
  • EN 45555: General methods for assessing the energy efficiency of networked standby
  • RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
  • REACH: EU chemicals regulation compliance — no substances of very high concern
  • WEEE: Waste Electrical and Electronic Equipment Directive — proper end-of-life disposal compliance

Applications & Use Cases

The ABB SH202M-C20 miniature circuit breaker is well suited for protecting final circuits in residential distribution boards, commercial fit-outs, and light industrial control panels. The C-curve tripping characteristic makes it ideal for resistive and moderately inductive loads such as lighting circuits, socket outlets, and small motor applications where moderate inrush currents are present. Its compact DIN rail footprint simplifies panel layout and reduces overall enclosure size for engineers and panel builders.

Specification

Full specification

72 values · Last verified 30 Oct 2026

Technical 18

Dielectric Test Voltage 50 / 60 Hz - 1 min 2 kV
Power Supply Connection Arbitrary
Contact Position Indication ON / OFF
Energy Limiting Class 3
Electrical Endurance 20000 AC cycle
Mechanical Endurance 20000 cycle
Number of Protected Poles 2
Number of Poles 2P
Tightening Torque 2 N·m
Screw Terminal Type Cage Terminal
Actuator Marking I / O
Actuator Material Insulation Group II, Black, Sealable
Recommended Screw Driver Pozidriv 2
Accessories Available Yes
Connecting Capacity Conductor 25 / 25 mm², Flexible with Ferrule 0.75 ... 16 mm², Flexible 0.75 ... 16 mm², Rigid 0.75 ... 25 mm², Stranded 0.75 ... 25 mm²
Installation Size acc. to DIN 43880 1
Terminal Type Screw Terminals
Actuator Type Toggle

Electrical 11

Tripping Characteristic C
Rated Operational Voltage acc. to IEC 60898-1 400 V
Operational Voltage Maximum (Incl. Tolerance) 440 V AC, Minimum 12 V AC
Rated Insulation Voltage (Ui) acc. to IEC/EN 60664-1 440 V
Rated Impulse Withstand Voltage (Uimp) 4 kV, at 2000 m 5 kV, at Sea Level 6.2 kV
Input Voltage Type AC
Rated Current (In) 20 A
Rated Short-Circuit Capacity (AC) 10 kA, (400 V AC) 10 kA, (400 V) 10 kA
Rated Frequency (f) 50 / 60 Hz
Power Loss 5 W, at Rated Operating Conditions per Pole 2.5 W
Overvoltage Category III

Design 1

Housing Material Insulation Group II, RAL 7035
Show all 72 specifications ↓ Show less ↑42 more values in Identification, Material Compliance, Environmental, Dimensions, Installation, External Classifications and Standards, Logistics.

Identification 11

Part number 2CDS272011R0204
Type designation SH202M-C20
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 4016779700719
ETIM class EC000042
eCl@ss 27141901
Package Level 1 Units carton 5 piece
Package Level 1 Gross Weight 1.09 kg

Material Compliance 6

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date 20260312
REACH Information False - does not contain substances > 0.1 mass percentage
REACH Date 20260312
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B Business To Business

Environmental 7

Ambient Air Temperature Operation -25 ... +55 °C, Storage -40 ... +70 °C
Reference Ambient Air Temperature 30 °C
Degree of Protection IP20, Enclosure with Cover IP40
Pollution Degree 2
Environmental Conditions 28 cycles, with 55 °C / 90-96 %, and 25 °C / 95-100 %
Resistance to Vibrations 20 Cycles with Load 0.8 In: 5g 5 ... 150 ... 5 Hz
Resistance to Shock acc. to IEC 60068-2-27 25g 2 shocks 13 ms

Dimensions 7

Width in Number of Modular Spacings 2
Product Net Width 35 mm
Product Net Height 88 mm
Product Net Depth / Length 69 mm
Product Net Weight 0.21 kg
Pole Net Weight 0.125 kg
Built-In Depth (t2) 69 mm

Installation 2

Mounting on DIN Rail TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Mounting Position any

External Classifications and Standards 5

ETIM 10 EC000042 - Miniature circuit breaker (MCB)
UNSPSC 39121603
eClass V11.0 : 27141901
Standards IEC/EN 60898-1
Certification Agency EN, IEC

Logistics 4

Shipping weight 0.21 kg
Ships from Türkiye
Dispatch 17 Nov
Stock In stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 2CDS272011R0204

No documents are on file for this part yet.

Ask us for the datasheet
Other ratings

All 8 ratings in ABB SH200

ABB ABB SH200 series page →
Other ratings in the same series
Motor power Rated current Part number Model no Stock Dispatch Price Add to cart
6 A 2CDS272011R0064 SH202M-C6 In stock $34.27
16 A 2CDS272011R0164 SH202M-C16 Low stock $28.57
20 A 2CDS272011R0204 This part SH202M-C20 In stock $28.57
25 A 2CDS272011R0254 SH202M-C25 Low stock $28.57
32 A 2CDS272011R0324 SH202M-C32 In stock $35.70
40 A 2CDS272011R0404 SH202M-C40 Low stock $37.12
50 A 2CDS272011R0504 SH202M-C50 Low stock $42.83
63 A 2CDS272011R0634 SH202M-C63 Low stock $48.51
Certifications

Certifications and standards

  • RoHS
  • IEC/EN 60898-1
Quick answers

Questions about the SH202M-C20

What is the rated current of SH202M-C20?

The rated current of SH202M-C20 is 20 A.

What is the HS code of SH202M-C20 for customs?

The tariff (HS) code on file for SH202M-C20 is 853620.

What is the EAN of SH202M-C20?

The EAN (GTIN) of SH202M-C20 is 4016779700719.

Where does SH202M-C20 ship from, and how fast?

SH202M-C20 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
