ABB 2CCF019586R0001 S804PV-SP5 4P 5A 1500V DC 5kA High Performance Circuit Breaker

% $-426.32
ABB 2CCF019586R0001 S804PV-SP5 4-pole 5A 1500V DC high performance circuit breaker
ABB 2CCF019586R0001 S804PV-SP5 4-pole 5A 1500V DC high performance circuit breaker

ABB 2CCF019586R0001 S804PV-SP5 4P 5A 1500V DC 5kA High Performance Circuit Breaker

Brand: ABB
Reference No: 2CCF019586R0001
Catalog No: S804PV-SP5
Series: High Performance Circuit Breakers HPCBs - S800
Tariff Code (HS): 853620
Rated Current: 5
Breaking Type: SP (thermal + electromechanical)
Rated Voltage: 1500 V DC
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$426.32

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 2CCF019586R0001 is an S804PV-SP5 four-pole high performance circuit breaker rated 5 A at up to 1500 V DC, sized for protecting small photovoltaic string circuits. Its SP tripping characteristic provides both overload and short-circuit sensing, and it carries a 5 kA breaking capacity for DC fault currents on individual strings.

Technical Specifications

Catalog No S804PV-SP5
SKU 2CCF019586R0001
Brand ABB
Series High Performance Circuit Breakers HPCBs - S800
Rated Current (In) 5 A
Number of Poles 4P
Tripping / Release Characteristic SP
Rated Operational Voltage 1500 V DC (IEC 60947-2)
Rated Ultimate Short-Circuit Breaking Capacity (Icu) 5 kA at 1500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics) 5 kA at 1500 V DC
Energy Limiting Class 3
Rated Insulation Voltage (Ui) 1500 V
Rated Impulse Withstand Voltage (Uimp) 8 kV
Overvoltage Category III
Pollution Degree 2
Degree of Protection IP20
Power Loss 6 W total / 1.5 W per pole
Connecting Capacity Flexible 0-50 mm², Rigid 0-70 mm²
Ambient Temperature -40 to +70 degrees C operation
Width 105 mm (6 modules)
Height 99 mm
Depth 111 mm
Net Weight 0.98 kg
EAN 7612271452124

Certifications & Standards

  • IEC/EN 60947-2

Selection Notes

Rated 5 A, the 2CCF019586R0001 is the smallest breaker in the S804PV-SP range covered here, matching a single low-output PV string. Its SP tripping characteristic still provides both thermal overload and electromechanical short-circuit protection, operating within the shared 5 kA breaking capacity at 1500 V DC. Strings built from higher-output modules need the next size up in the same frame rather than this 5 A unit.

Technical Details

Short Description
ABB S804PV-SP5 4-pole, 5 A, 1500 V DC high performance circuit breaker, SP trip, 5 kA breaking capacity, small PV strings.
Rated Current (Ampere)
5
Rated Voltage (VAC)
1500 V DC
Mounting Type
DIN-Rail
Protection Type
IP20
Catalog No
S804PV-SP5
Number of Poles
4P
Standards
IEC/EN 60947-2
Delivery Date (Days)
30 days
Model Number
S804PV-SP5
Tariff Code
853620
