ABB 1TNE968901R3102 TA563-11 11-Pole Screw Front Cable-Side Terminal Block PLC Connection Module

% $-5.75
ABB 1TNE968901R3102 TA563-11 11-pole screw terminal block, cable-side, S500-eCo PLC
ABB 1TNE968901R3102 TA563-11 11-pole screw terminal block, cable-side, S500-eCo PLC

ABB 1TNE968901R3102 TA563-11 11-Pole Screw Front Cable-Side Terminal Block PLC Connection Module

Brand: ABB
Reference No: 1TNE968901R3102
Catalog No: TA563-11
Series: Accessories
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$5.75

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1TNE968901R3102 (TA563-11) is an 11-pole screw-front terminal block with cable-side wiring for the AC500-eCo S500-eCo I/O system. It terminates field wiring away from the module front, keeping the wiring harness on the side of the DIN-rail assembly rather than underneath it. ABB packages TA563-11 in boxes of 6 and requires orders in multiples of 6, so single-unit purchasing is not available.

Technical Specifications

Order code 1TNE968901R3102
Type code TA563-11
Brand ABB
Series AC500-eCo accessories
EAN 6943747170305
Function Screw front, cable side, 11-pole
Accessory Type Electrical: Plug
Degree of Protection IP20
Minimum Order Quantity 6 (multiples of 6)
Net Weight 0.021 kg
Dimensions (L x H x W) 40 x 250 x 150 mm

Selection Notes

TA563-11's cable-side screw entry keeps field wiring off the module front, the same approach as the 9-pole version of this terminal block, but with two extra poles for I/O modules that need the additional terminations. Pick TA563-11 over the lower pole-count block specifically when the module side being wired exposes 11 or more field connections rather than 9. ABB sells it only in boxes of 6, so plan spares in that unit size rather than ordering single blocks.

Technical Details

Short Description
ABB TA563-11 11-pole screw-front terminal block, cable-side wiring, for AC500-eCo S500-eCo I/O modules. Sold in packs of 6.
Mounting Type
Terminal unit
Protection Type
IP20
Catalog No
TA563-11
Delivery Date (Days)
30 days
Model Number
TA563-11
Tariff Code
853890
