CM single-phase monitorsABB 1SVR730841R1200 CM-SRS.11S Current Monitoring Relay 1C/O 3mA-1A RMS 220-240V AC Single-Phase
Description
About the CM-SRS.11S
About the CM-SRS.11S
The ABB CM-SRS.11S current monitoring relay (SKU: 1SVR730841R1200) is a single-phase current monitoring device designed to protect motors, pumps, and industrial loads from under-current and over-current faults. With a wide monitoring range of 3mA to 1A RMS and a rated supply voltage of 220–240V AC, the CM-SRS.11S delivers reliable protection in compact DIN-rail-mountable form — measuring just 22.5mm wide — making it ideal for space-constrained control panels in industrial automation and building services applications.
Certifications & Standards
- CE: Complies with applicable EU directives for electrical equipment
- UKCA: UK Conformity Assessed for the Great Britain market
- cULus: Listed to UL and CSA standards for the North American market
- UL 508: Standard for Industrial Control Equipment
- CCC: China Compulsory Certification for the Chinese market
- CSA / CAN/CSA C22.2 No.14: Canadian standard for industrial control equipment
- IEC/EN 60255-27: Measuring relays and protection equipment — product safety requirements
- IEC/EN 63000: Technical documentation for the assessment of electrical and electronic products with respect to the restriction of hazardous substances
- IEC/EN 61000-6-2: Electromagnetic compatibility — generic immunity standard for industrial environments
- IEC/EN 61000-6-3: Electromagnetic compatibility — generic emission standard for residential, commercial, and light-industrial environments
- IEC 60715: Dimensions of low-voltage switchgear and controlgear — standardised mounting on rails
- REACH: Compliant with EU REACH regulation on chemical substances
- RoHS: Restriction of Hazardous Substances compliant
Applications & Use Cases
- Motor under-current and over-current protection in pumping stations and HVAC systems
- Load monitoring and broken-belt or dry-run detection in conveyor and pump applications
- Process current monitoring in industrial automation and control panels
- Machine protection in manufacturing and packaging lines
- Building services electrical distribution boards requiring compact single-phase monitoring
Specification
Full specification
| Part number | 1SVR730841R1200 |
|---|---|
| Catalog no | CM-SRS.11S |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 4016779852326 |
| Rated current | 1 A |
|---|---|
| Rated operational voltage | 220–240 V AC |
| Setting range | 0.003–1 A |
| Dimensions (W × H × D) | 22.5mm × 85.6mm × 103.7mm |
|---|---|
| Shipping weight | 0.183 kg |
| HS code | 85364900 |
|---|---|
| Ships from | Türkiye |
| Dispatch | 13 Nov |
| Stock | Critical stock |
| Series | CM Single-Phase Monitors |
|---|---|
| Product Type | Current Monitoring Relay |
| Output Contact | 1 C/O (SPDT) |
| Current Monitoring Range | 3 mA – 1 A RMS |
| Weight | 0.161 kg |
From the manufacturer description; the values above take precedence.
Documents
Documents for 1SVR730841R1200
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- RoHS
- CCC
Quick answers
Questions about the CM-SRS.11S
What is the rated current of CM-SRS.11S?
The rated current of CM-SRS.11S is 1 A.
Which supply voltage is CM-SRS.11S rated for?
The rated operational voltage of CM-SRS.11S is 220–240 V AC.
What is the HS code of CM-SRS.11S for customs?
The tariff (HS) code on file for CM-SRS.11S is 85364900.
What is the EAN of CM-SRS.11S?
The EAN (GTIN) of CM-SRS.11S is 4016779852326.
Where does CM-SRS.11S ship from, and how fast?
CM-SRS.11S ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
