CMABB 1SVR550871R9500 CM-PVE Phase Monitoring Relay 1NO 320-460V AC 3-Phase
Description
About the CM-PVE
About the CM-PVE
The ABB CM-PVE (SKU: 1SVR550871R9500) is a 3-phase monitoring relay designed to protect electrical equipment against phase failures, phase asymmetry, and incorrect phase sequences. The CM-PVE monitors supply voltages in the range of 320–460 V AC and provides a 1NO (normally open) output contact, making it a reliable choice for motor protection and industrial control panel applications.
Certifications & Standards
- CE: Compliant with European directives for safety and market access
- UKCA: UK Conformity Assessed mark for the UK market
- UL 508: Listed for industrial control equipment (USA)
- cUL: Canadian UL listing for industrial control equipment
- CSA: Canadian Standards Association certification
- CSA C22.2 No.14: Industrial control equipment standard (Canada)
- CCC: China Compulsory Certification for the Chinese market
- IEC/EN 63000: Technical documentation for RoHS assessment of electrical and electronic equipment
- EN 63000: European harmonised standard aligned with IEC 63000
- IEC/EN 61000-6: Electromagnetic compatibility (EMC) generic standards
- EN 61000-6: European EMC generic standard for industrial environments
- IEC 60715: Dimensions of low-voltage switchgear and controlgear — DIN rail mounting
- REACH: Compliant with EU regulation on chemicals (SVHC)
- RoHS: Restriction of Hazardous Substances compliant
Applications & Use Cases
The ABB CM-PVE phase monitoring relay is widely used in industrial automation and motor protection applications where 3-phase power quality is critical. Typical installations include:
- Protection of 3-phase motors against phase loss, phase reversal, and asymmetry
- Control panel integration for manufacturing and process automation
- HVAC systems and pump stations requiring continuous phase supervision
- Machine tool and compressor protection circuits
- Building automation and industrial drive protection
Specification
Full specification
Dimensions 4
| Product Net Width | 22.5 mm |
|---|---|
| Product Net Height | 78 mm |
| Product Net Depth / Length | 78.5 mm |
| Product Net Weight | 0.066 kg |
Technical 25
| Function | Phase failure detection, Over- and undervoltage monitoring |
|---|---|
| Sub-Function | Phase loss |
| Sub-Function 2 | 02 Over- and undervoltage (fixed) |
| Measuring Range | (L-L) 320 ... 460 V AC |
| Time Range | Tripping Delay (ON or OFF) 500 ms |
| Rated Control Supply Voltage (Us) | (L-L) 320 ... 460 V AC |
| Rated Frequency (f) | Supply Circuit 50/60 Hz |
| Output | 1 N/O Contact |
| Terminal Type | Screw Terminals |
| Rated Operational Current AC-12 (Ie) | (230 V) 4 A |
| Rated Operational Current AC-15 (Ie) | (230 V) 3 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 4 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2 A |
| Rated Impulse Withstand Voltage (Uimp) | Input Circuit 4 kV |
| Rated Insulation Voltage (Ui) | Input Circuit / Output Circuit 400 V |
| Degree of Protection | Housing IP50, Terminals IP20 |
| Overvoltage Category | III |
| Pollution Degree | 3 |
| Short-Circuit Protective Devices | Output Circuit NC - F Type Fuses 10 A, Output Circuit NO - F Type Fuses 10 A |
| Connecting Capacity | Flexible with Ferrule 2x 0.75 ... 1.5 mm², Flexible 2x 1 ... 1.5 mm², Rigid 2x 0.75 ... 1.5 mm² |
| Tightening Torque | 0.6 ... 0.8 N·m |
| Wire Stripping Length | 10 mm |
| Mounting Position | 1 ... 6 |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| Standards | CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 508 |
Technical UL/CSA 5
| Maximum Operating Voltage UL/CSA | Output Circuit 250 V AC |
|---|---|
| Contact Rating UL/CSA | B300 |
| Connecting Capacity UL/CSA | Flexible with Ferrule 2x 18-16 AWG, Flexible 2x 18-16 AWG, Rigid 2x 18-16 AWG |
| Tightening Torque UL/CSA | 7.08 in·lb |
| Pilot Duty UL/CSA | B300 |
Show all 64 specifications ↓ Show less ↑30 more values in Identification, Environmental, Material Compliance, External Classifications and Standards, Logistics.
Identification 10
| Part number | 1SVR550871R9500 |
|---|---|
| Type designation | CM-PVE |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 4013614348112 |
| eCl@ss | 27371803 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85364900 |
Environmental 2
| Ambient Air Temperature | Operation -20 ... +60 °C, Storage -40 ... +85 °C |
|---|---|
| Maximum Operating Altitude Permissible | Without Derating 2000 m |
Material Compliance 4
| REACH Declaration | 1SVD981001-4501 |
|---|---|
| RoHS Declaration | 1SVD981001-4401 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006536 |
External Classifications and Standards 3
| ETIM 7 | EC001441 - Phase monitoring relay |
|---|---|
| eClass | V11.0 : 27371803 |
| UNSPSC | 39122332 |
Logistics 11
| Package Level 1 Units | box 1 piece |
|---|---|
| Package Level 1 Width | 23 mm |
| Package Level 1 Depth / Length | 82 mm |
| Package Level 1 Height | 82 mm |
| Package Level 1 Gross Weight | 0.078 kg |
| Package Level 1 EAN | 4013614348112 |
| Package Level 2 EAN | 4013614580789 |
| Shipping weight | 0.078 kg |
| Ships from | Türkiye |
| Dispatch | 11 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SVR550871R9500
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- CSA
- RoHS
- UKCA
- CCC
- CAN/CSA C22.2 No.14
- IEC/EN 63000
- IEC/EN 61000-6-2
- IEC/EN 61000-6-3
- UL 508
Quick answers
Questions about the CM-PVE
Which supply voltage is CM-PVE rated for?
The rated operational voltage of CM-PVE is 320–460 V AC.
What is the HS code of CM-PVE for customs?
The tariff (HS) code on file for CM-PVE is 85364900.
What is the EAN of CM-PVE?
The EAN (GTIN) of CM-PVE is 4013614348112.
Where does CM-PVE ship from, and how fast?
CM-PVE ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
