- Part number
- 1SVR405622R3000
- Model no
- CR-U230AC3
In stock · 50+
Dispatch
Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days.
· From Türkiye
0
- CE
- RoHS
- VDE
CR-UABB 1SVR405622R3000 CR-U230AC3 Pluggable Interface Switching Relay 3C/O 230VAC Coil 250V/10A DIN Rail
Description
About the CR-U230AC3
About the CR-U230AC3
The ABB CR-U230AC3 (SKU: 1SVR405622R3000) is a pluggable interface switching relay from the CR-U series, designed for reliable control and signal switching in industrial automation and control panel applications. Featuring 3 changeover contacts rated at 250V/10A with a 230VAC coil voltage, the CR-U230AC3 mounts directly on standard DIN rail and offers a compact footprint of 35mm × 54.4mm × 35mm — making it an efficient choice for dense panel builds. Its pluggable design simplifies installation and replacement without rewiring, reducing maintenance downtime in demanding industrial environments.
Certifications & Standards
- CE: Conforms to European Union safety, health, and environmental requirements
- UKCA: UK Conformity Assessed marking for the Great Britain market
- UL 508: UL certified for industrial control equipment (USA)
- CSA / CAN/CSA C22.2 No.14: Canadian Standards Association certification for industrial control equipment
- IEC/EN 61810-1: Electromechanical elementary relays — general and safety requirements
- IEC/EN 63000 / EN 63000: Technical documentation for assessment of electrical and electronic products with respect to restriction of hazardous substances
- VDE: Tested and certified by VDE (Verband der Elektrotechnik), Germany
- CCC: China Compulsory Certification for the Chinese market
- EAC: Eurasian Conformity mark for Customs Union markets
- RoHS: Compliant with Restriction of Hazardous Substances Directive
- REACH: Compliant with EU REACH regulation on chemical substances
Applications & Use Cases
- Signal isolation and level shifting between control circuits in industrial automation
- PLC output amplification and load switching in control panels
- Interface relay for HVAC, building automation, and machine control systems
- Motor control, solenoid switching, and indicator lamp control
- General-purpose switching in DIN rail-mounted relay panels
Specification
Full specification
Dimensions 4
| Product Net Width | 35 mm |
|---|---|
| Product Net Height | 54.4 mm |
| Product Net Depth / Length | 35 mm |
| Product Net Weight | 0.083 kg |
Technical 16
| Function | Pluggable universal interface relay CR-U |
|---|---|
| Sub-Function | Relay w/o built in LED |
| Rated Control Supply Voltage (Us) | 230 V AC |
| Rated Operational Voltage | 250 V AC |
| Rated Frequency (f) | 50 / 60 Hz |
| Output | 3 C/O (SPDT) Contacts |
| Output Signal | 250 V / 10 A |
| Terminal Type | Pin |
| Rated Operational Current AC-12 (Ie) | (230 V) 10 A |
| Rated Operational Current AC-15 (Ie) | (120 V) 3 A, (230 V) 1.5 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 10 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2 A, (250 V) 0.1 A |
| Rated Insulation Voltage (Ui) | 250 V |
| Degree of Protection | IP40 |
| Mounting Position | 1 |
| Standards | CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61810-1, UL 508 |
Technical UL/CSA 4
| Maximum Operating Voltage UL/CSA | 300 V AC |
|---|---|
| Contact Rating UL/CSA | B300 |
| Pilot Duty UL/CSA | B300 |
| Flammability According to UL94 | HB |
Show all 54 specifications ↓ Show less ↑30 more values in Identification, Environmental, Material Compliance, External Classifications and Standards, Logistics.
Identification 10
| Part number | 1SVR405622R3000 |
|---|---|
| Type designation | CR-U230AC3 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 4013614498619 |
| eCl@ss | 27371601 |
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85364900 |
Environmental 2
| Ambient Air Temperature | Operation -40 ... +55 °C, Storage -40 ... +85 °C |
|---|---|
| Maximum Operating Altitude Permissible | Without Derating 2000 m |
Material Compliance 4
| REACH Declaration | 1SVD981001-4501 |
|---|---|
| RoHS Declaration | 1SVD981001-4401 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006536 |
External Classifications and Standards 4
| ETIM 7 | EC001437 - Switching relay |
|---|---|
| eClass | V11.0 : 27371601 |
| UNSPSC | 39122331 |
| E-Number (Sweden) | 4005425 |
Logistics 10
| Package Level 1 Units | box 10 piece |
|---|---|
| Package Level 1 Width | 182 mm |
| Package Level 1 Depth / Length | 77 mm |
| Package Level 1 Height | 76 mm |
| Package Level 1 Gross Weight | 0.87 kg |
| Package Level 1 EAN | 4013614374258 |
| Shipping weight | 0.87 kg |
| Ships from | Türkiye |
| Dispatch | 11 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SVR405622R3000
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- RoHS
- VDE
- CAN/CSA C22.2 No.14
- IEC/EN 63000
- IEC/EN 61810-1
- UL 508
Quick answers
Questions about the CR-U230AC3
What is the rated current of CR-U230AC3?
The rated current of CR-U230AC3 is 10 A.
Which supply voltage is CR-U230AC3 rated for?
The rated operational voltage of CR-U230AC3 is 250 V AC.
What is the HS code of CR-U230AC3 for customs?
The tariff (HS) code on file for CR-U230AC3 is 85364900.
What is the EAN of CR-U230AC3?
The EAN (GTIN) of CR-U230AC3 is 4013614498619.
Where does CR-U230AC3 ship from, and how fast?
CR-U230AC3 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Reviews
Customer reviews
Series
ABB CR-U
- Brand
- ABB
- Series
- CR-U
