- Part number
- 1SVR405622R0000
- Model no
- CR-U024AC3
Description
About the CR-U024AC3
About the CR-U024AC3
The ABB CR-U024AC3 (SKU: 1SVR405622R0000) is a pluggable interface switching relay from the CR-U series, featuring 3 changeover (C/O) contacts rated at 250V/10A with a 24VAC control coil. Designed for DIN rail mounting, the CR-U024AC3 delivers reliable signal switching and interface isolation in industrial control panels, PLC output stages, and automation systems. Its compact 35mm × 54.4mm × 35mm footprint and plug-in design simplify installation and field replacement without rewiring.
Certifications & Standards
- CE: Conformité Européenne — meets EU safety, health, and environmental requirements
- UKCA: UK Conformity Assessed — approved for Great Britain market
- UL 508: UL-listed for industrial control equipment (North America)
- CAN/CSA C22.2 No.14: Canadian Standards Association — industrial control equipment
- CSA C22.2: CSA certification for electrical safety compliance
- CSA: General CSA product safety certification
- IEC/EN 61810-1: Electromechanical elementary relays — general and safety requirements
- EN 61810: European standard for electromechanical relays
- IEC/EN 63000: Technical documentation for assessment of electrical and electronic equipment with respect to RoHS
- VDE: German electrical engineering certification (Verband der Elektrotechnik)
- RoHS: Restriction of Hazardous Substances — EU Directive 2011/65/EU compliant
- REACH: EU chemical safety regulation compliance (ECHA)
- CCC: China Compulsory Certification for the Chinese market
- EAC: Eurasian Conformity mark for Russia/CIS markets
Applications & Use Cases
- PLC digital output interface and signal isolation in industrial automation panels
- Machine control cabinets requiring compact, plug-in relay solutions
- HVAC, building automation, and process control switching
- Motor control and auxiliary switching circuits in industrial environments
- Field bus interface and I/O expansion modules
Frequently Asked Questions
What does the "C/O" designation mean?
C/O stands for changeover contact (also known as SPDT — Single Pole Double Throw). Each of the 3 contacts includes a normally open (NO) and normally closed (NC) connection sharing a common terminal, providing maximum switching flexibility.
Is the CR-U024AC3 plug-in or soldered?
The CR-U024AC3 is a pluggable relay designed to seat into a compatible CR-U series relay socket, allowing fast field replacement without disturbing panel wiring.
What coil voltage does this relay require?
This model is energised by a 24VAC supply connected across terminals A1 and A2.
Specification
Full specification
Dimensions 4
| Product Net Width | 35 mm |
|---|---|
| Product Net Height | 54.4 mm |
| Product Net Depth / Length | 35 mm |
| Product Net Weight | 0.083 kg |
Technical 16
| Function | Pluggable universal interface relay CR-U |
|---|---|
| Sub-Function | Relay w/o built in LED |
| Rated Control Supply Voltage (Us) | 24 V AC |
| Rated Operational Voltage | 250 V AC |
| Rated Frequency (f) | 50 / 60 Hz |
| Output | 3 C/O (SPDT) Contacts |
| Output Signal | 250 V / 10 A |
| Terminal Type | Pin |
| Rated Operational Current AC-12 (Ie) | (230 V) 10 A |
| Rated Operational Current AC-15 (Ie) | (120 V) 3 A, (230 V) 1.5 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 10 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2 A, (250 V) 0.1 A |
| Rated Insulation Voltage (Ui) | 250 V |
| Degree of Protection | IP40 |
| Mounting Position | 1 |
| Standards | CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61810-1, UL 508 |
Technical UL/CSA 4
| Maximum Operating Voltage UL/CSA | 300 V AC |
|---|---|
| Contact Rating UL/CSA | B300 |
| Pilot Duty UL/CSA | B300 |
| Flammability According to UL94 | HB |
Show all 54 specifications ↓ Show less ↑30 more values in Identification, Environmental, Material Compliance, External Classifications and Standards, Logistics.
Identification 10
| Part number | 1SVR405622R0000 |
|---|---|
| Type designation | CR-U024AC3 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 4013614498558 |
| eCl@ss | 27371601 |
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85364900 |
Environmental 2
| Ambient Air Temperature | Operation -40 ... +55 °C, Storage -40 ... +85 °C |
|---|---|
| Maximum Operating Altitude Permissible | Without Derating 2000 m |
Material Compliance 4
| REACH Declaration | 1SVD981001-4501 |
|---|---|
| RoHS Declaration | 1SVD981001-4401 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006536 |
External Classifications and Standards 4
| ETIM 7 | EC001437 - Switching relay |
|---|---|
| eClass | V11.0 : 27371601 |
| UNSPSC | 39122331 |
| E-Number (Sweden) | 4005420 |
Logistics 10
| Package Level 1 Units | box 10 piece |
|---|---|
| Package Level 1 Width | 182 mm |
| Package Level 1 Depth / Length | 77 mm |
| Package Level 1 Height | 76 mm |
| Package Level 1 Gross Weight | 0.87 kg |
| Package Level 1 EAN | 4013614374180 |
| Shipping weight | 0.87 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SVR405622R0000
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- RoHS
- VDE
- CAN/CSA C22.2 No.14
- IEC/EN 63000
- IEC/EN 61810-1
- UL 508
Quick answers
Questions about the CR-U024AC3
What is the rated current of CR-U024AC3?
The rated current of CR-U024AC3 is 10 A.
Which supply voltage is CR-U024AC3 rated for?
The rated operational voltage of CR-U024AC3 is 250 V AC.
What is the HS code of CR-U024AC3 for customs?
The tariff (HS) code on file for CR-U024AC3 is 85364900.
What is the EAN of CR-U024AC3?
The EAN (GTIN) of CR-U024AC3 is 4013614498558.
Where does CR-U024AC3 ship from, and how fast?
CR-U024AC3 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
