Part number
1SVR405613R6000
Model no
CR-M048DC4
$7.08 In stock · 13 Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye
CR-M

ABB 1SVR405613R6000 CR-M048DC4 4-Pole 6A 250V 48VDC Coil Pluggable Interface Switching Relay DIN Rail

Rated current
6 A
Rated operational voltage
250 V AC
Poles
4P
EAN
4013614497834
Description

About the CR-M048DC4

The ABB CR-M048DC4 (SKU: 1SVR405613R6000) is a pluggable interface switching relay from the CR-M series, featuring 4 changeover contacts rated at 250V/6A with a 48VDC coil voltage. Designed for DIN rail installation in control panels and industrial automation applications, the CR-M048DC4 delivers reliable signal switching in a compact 21.2 × 35.6 × 27.5 mm housing — ideal for PLC output interfaces, machine control, and building automation systems.

Certifications & Standards

  • CE: Conformité Européenne — meets EU safety, health, and environmental requirements
  • UL 508: UL certification for industrial control equipment (USA)
  • CAN/CSA C22.2 No.14: Canadian Standards Association certification for industrial control equipment
  • CSA C22.2: CSA standard for electrical equipment in Canada
  • CSA: CSA Group certified for safety in North American markets
  • IEC/EN 61810-1: Electromechanical elementary relays — general and safety requirements
  • EN 61810: European standard for electromechanical elementary relays
  • IEC/EN 63000: Technical documentation for the assessment of electrical and electronic products with respect to the restriction of hazardous substances
  • VDE: Verband der Elektrotechnik — German electrical engineering certification
  • REACH: EU regulation on Registration, Evaluation, Authorisation and Restriction of Chemicals
  • RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
  • CCC: China Compulsory Certification for the Chinese market
  • UKCA: UK Conformity Assessed marking for Great Britain market
  • EAC: Eurasian Conformity mark for the Eurasian Economic Union

Applications & Use Cases

  • PLC and controller output interface isolation in industrial automation panels
  • Machine control signal switching and amplification
  • Building automation and HVAC control systems
  • Process control and instrumentation panels
  • Motor starter auxiliary circuits and interlocking
  • General-purpose signal relay in control cabinets
Specification

Full specification

52 values · Last verified 30 Oct 2026

Dimensions 4

Product Net Width 21.2 mm
Product Net Height 35.6 mm
Product Net Depth / Length 27.5 mm
Product Net Weight 0.033 kg

Technical 15

Function Pluggable miniature interface relay CR-M
Sub-Function Relay w/o built in LED
Rated Control Supply Voltage (Us) 48 V DC
Rated Operational Voltage 250 V AC
Output 4 C/O (SPDT) Contacts
Output Signal 250 V / 6 A
Terminal Type Flat-Pin Connections
Rated Operational Current AC-12 (Ie) (230 V) 6 A
Rated Operational Current AC-15 (Ie) (120 V) 1.5 A, (230 V) 1 A
Rated Operational Current DC-12 (Ie) (24 V) 6 A
Rated Operational Current DC-13 (Ie) (24 V) 2 A, (250 V) 0.1 A
Rated Insulation Voltage (Ui) 250 V
Degree of Protection IP40
Mounting Position 1
Standards CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61810-1, UL 508

Technical UL/CSA 4

Maximum Operating Voltage UL/CSA 300 V AC
Contact Rating UL/CSA B300
Pilot Duty UL/CSA B300
Flammability According to UL94 HB
Show all 52 specifications ↓ Show less ↑29 more values in Identification, Environmental, Material Compliance, External Classifications and Standards, Logistics.

Identification 10

Part number 1SVR405613R6000
Type designation CR-M048DC4
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 4013614497834
eCl@ss 27371601
Minimum Order Quantity 10 piece
Customs Tariff Number 85364900

Environmental 2

Ambient Air Temperature Operation -40 ... +70 °C, Storage -40 ... +85 °C
Maximum Operating Altitude Permissible Without Derating 2000 m

Material Compliance 4

REACH Declaration 1SVD981001-4501
RoHS Declaration 1SVD981001-4401
RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA 2CMT2023-006536

External Classifications and Standards 3

ETIM 7 EC001437 - Switching relay
eClass V11.0 : 27371601
UNSPSC 39122331

Logistics 10

Package Level 1 Units box 10 piece
Package Level 1 Width 114 mm
Package Level 1 Depth / Length 50 mm
Package Level 1 Height 61 mm
Package Level 1 Gross Weight 0.35 kg
Package Level 1 EAN 4013614373527
Shipping weight 0.35 kg
Ships from Türkiye
Dispatch 17 Nov
Stock In stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SVR405613R6000

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • CE
  • RoHS
  • VDE
  • CAN/CSA C22.2 No.14
  • IEC/EN 63000
  • IEC/EN 61810-1
  • UL 508
Quick answers

Questions about the CR-M048DC4

What is the rated current of CR-M048DC4?

The rated current of CR-M048DC4 is 6 A.

Which supply voltage is CR-M048DC4 rated for?

The rated operational voltage of CR-M048DC4 is 250 V AC.

What is the HS code of CR-M048DC4 for customs?

The tariff (HS) code on file for CR-M048DC4 is 85364900.

What is the EAN of CR-M048DC4?

The EAN (GTIN) of CR-M048DC4 is 4013614497834.

Where does CR-M048DC4 ship from, and how fast?

CR-M048DC4 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
