Part number
1SVR405601R6000
Model no
CR-P048DC2
$14.66 Low stock Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye
CR-P

ABB 1SVR405601R6000 CR-P048DC2 2C/O 48VDC Coil 250V 8A Pluggable Switching Relay

Rated current
8 A
Rated operational voltage
250 V AC
Degree of protection
IP67
EAN
4013614498282
Description

About the CR-P048DC2

The ABB CR-P048DC2 (SKU: 1SVR405601R6000) is a pluggable interface switching relay from the CR-P series, featuring a 2-changeover (2C/O) contact configuration with a 48VDC coil voltage and a rated switching capacity of 250V/8A. Designed for PCB and pluggable mounting, it delivers reliable signal switching in control panels, PLC output interfaces, and industrial automation systems. Its compact 12.7 × 15.7 × 29 mm footprint makes it ideal for space-constrained installations.

Certifications & Standards

  • IEC 61810-1: International standard for electromechanical elementary relays
  • EN 61810-1: European harmonized standard for elementary relays
  • IEC/EN 61810-1: Combined IEC and EN compliance for elementary relays
  • CSA: Canadian Standards Association certification for North American markets
  • REACH: EU regulation compliance for chemical substances in electrical components
  • RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
  • CCC: China Compulsory Certification for the Chinese market
  • CE: Conformité Européenne — meets EU safety and EMC requirements
  • UKCA: UK Conformity Assessed marking for Great Britain market
  • EAC: Eurasian Conformity marking for Russia and EAEU countries
  • VDE: Verband der Elektrotechnik — German electrical engineering certification

Applications & Use Cases

  • PLC output signal switching and isolation in industrial control panels
  • Interface relay applications in building automation and HVAC controls
  • Machine control circuits requiring reliable 48VDC coil actuation
  • Signal conditioning between low-voltage control circuits and load circuits up to 250V/8A
  • DIN rail systems with pluggable relay socket bases for easy maintenance and replacement
Specification

Full specification

53 values · Last verified 30 Oct 2026

Dimensions 4

Product Net Width 12.7 mm
Product Net Height 15.7 mm
Product Net Depth / Length 29 mm
Product Net Weight 0.014 kg

Technical 16

Function Pluggable pcb interface relay CR-P
Sub-Function Relay w/o built in LED
Rated Control Supply Voltage (Us) 48 V DC
Rated Operational Voltage 400 V AC
Rated Frequency (f) 50 / 60 Hz
Output 2 C/O Contacts
Output Signal 250 V / 8 A
Terminal Type Soldering Pins
Rated Operational Current AC-12 (Ie) (230 V) 8 A
Rated Operational Current AC-15 (Ie) (120 V) 3 A, (230 V) 1.5 A
Rated Operational Current DC-12 (Ie) (24 V) 8 A
Rated Operational Current DC-13 (Ie) (24 V) 2 A, (250 V) 0.1 A
Rated Insulation Voltage (Ui) 400 V
Degree of Protection IP67
Mounting Position 1
Standards IEC/EN 61810-1

Technical UL/CSA 4

Maximum Operating Voltage UL/CSA 300 V AC
Contact Rating UL/CSA B300
Pilot Duty UL/CSA B300
Flammability According to UL94 V-0
Show all 53 specifications ↓ Show less ↑29 more values in Identification, Environmental, Material Compliance, External Classifications and Standards, Logistics.

Identification 10

Part number 1SVR405601R6000
Type designation CR-P048DC2
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 4013614498282
eCl@ss 27371601
Minimum Order Quantity 10 piece
Customs Tariff Number 85364900

Environmental 2

Ambient Air Temperature Operation -40 ... +85 °C, Storage -40 ... +85 °C
Maximum Operating Altitude Permissible Without Derating 2000 m

Material Compliance 4

REACH Declaration 1SVD981001-4501
RoHS Declaration 1SVD981001-4401
RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA 2CMT2023-006536

External Classifications and Standards 3

ETIM 7 EC001437 - Switching relay
eClass V11.0 : 27371601
UNSPSC 39122331

Logistics 10

Package Level 1 Units box 10 piece
Package Level 1 Width 332 mm
Package Level 1 Depth / Length 17 mm
Package Level 1 Height 28 mm
Package Level 1 Gross Weight 0.157 kg
Package Level 1 EAN 4013614373022
Shipping weight 0.014 kg
Ships from Türkiye
Dispatch 18 Nov
Stock Low stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SVR405601R6000

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • CE
  • RoHS
  • VDE
  • IEC/EN 61810-1
Quick answers

Questions about the CR-P048DC2

What is the rated current of CR-P048DC2?

The rated current of CR-P048DC2 is 8 A.

Which supply voltage is CR-P048DC2 rated for?

The rated operational voltage of CR-P048DC2 is 250 V AC.

What is the HS code of CR-P048DC2 for customs?

The tariff (HS) code on file for CR-P048DC2 is 85364900.

What is the EAN of CR-P048DC2?

The EAN (GTIN) of CR-P048DC2 is 4013614498282.

Where does CR-P048DC2 ship from, and how fast?

CR-P048DC2 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
