ABB 1SEP408149R0003 CT-ZLBM123-400/5-1-BB 5VA Rear-Side Current Transformer

% $-147.95
ABB 1SEP408149R0003 CT-ZLBM123 400-5A Current Transformer Switch Accessory
ABB 1SEP408149R0003 CT-ZLBM123 400-5A Current Transformer Switch Accessory

ABB 1SEP408149R0003 CT-ZLBM123-400/5-1-BB 5VA Rear-Side Current Transformer

Brand: ABB
Reference No: 1SEP408149R0003
Catalog No: CT-ZLBM123-400/5-1-BB
Series: Fuse Switch Disconnectors Accessories
Tariff Code (HS): 850431
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$147.95

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SEP408149R0003 CT-ZLBM123-400/5-1-BB is a rear-side current transformer for the ZLBM123 Inline fuse switch disconnector, rated 400/5 A at class 1 accuracy with a 5 VA burden. Its compact 45 x 55 x 27 mm body mounts directly behind the switch terminals, avoiding a separate split-core CT and conduit run. Net weight is 1.3 kg.

Technical Specifications

SKU 1SEP408149R0003
Brand ABB
Series Fuse Switch Disconnectors Accessories
Catalog designation CT-ZLBM123-400/5-1-BB
EAN 7025840021001
Accessory Type Current transformer
CT Ratio (Primary/Secondary) 400/5 A
Rated Burden 5 VA
Accuracy Class 1
Net Width 45 mm
Net Height 55 mm
Net Depth / Length 27 mm
Net Weight 1.3 kg

Selection Notes

At 400/5 A this kit sits mid-range in the ZLBM123 CT family; pick the 200/5 version instead if the switch is lightly loaded, since an undersized secondary current from an oversized ratio reduces meter accuracy near the low end of the scale. The class 1 accuracy is adequate for billing-grade panel ammeters but not for differential protection schemes, which need a protection-class CT.

Technical Details

Short Description
ABB 1SEP408149R0003 CT-ZLBM123-400/5-1-BB, 400/5A class 1 rear-side current transformer, EAN 7025840021001.
Mounting Type
Rear-side installation kit
Catalog No
CT-ZLBM123-400/5-1-BB
Delivery Date (Days)
30 days
Model Number
CT-ZLBM123-400/5-1-BB
Tariff Code
850431
